Kramer VS-1616D Manuel utilisateur

USER MANUAL

MODEL:

VS-1616D

2x2 to 16x16 Modular Multi-Format Digital Matrix

Switcher

P/N: 2900-000727 Rev 7 www.kramerAV.com

VS-1616D – Contents i

Contents

1Introduction 1

2Getting Started 3

2.1 Achieving the Best Performance 3

2.2 Safety Instructions AC 3

2.3 Safety Instructions (Laser) 4

2.4 Recycling Kramer Products 4

2.5 About Fast Switching 4

2.6 About HDBaseT™ Technology 5

3Overview 6

3.1 Defining the VS-1616D 2x2 to 16x16 Modular Multi-Format Digital Matrix Switcher 8

3.2 Using the IR Transmitter 11

4Installing in a Rack 12

5Connecting the VS-1616D 13

5.1 Port Numbering 14

5.2 Connecting to the VS-1616D via RS-232 16

5.3 Connecting to the VS-1616D via Ethernet 16

6Operating Your Video Matrix Switcher 21

6.1 Startup Display 21

6.2 Using the Selector Buttons 22

6.3 Confirming Actions 23

6.4 Switching Actions 24

6.5 Locking the Front Panel Buttons 27

7Using the Configuration Menus 28

7.1 Using the Setup Menu 29

7.2 Using the Config Menu 34

8Using the Test Video Plus Analog Audio Card 45

8.1 Defining the Test Video Plus Analog Audio Card 45

8.2 Setting the Resolution of the Generated Video 47

8.3 Setting the Pattern of the Generated Video 47

8.4 Installing the Test Module 48

9Using the Input / Output Cards 49

9.1 Defining the AAD-IN2-F16 / AAD-OUT2-F16 49

9.2 Defining the DGKat-IN2-F16 / DGKat-OUT2-F16 51

9.3 Defining the DL-IN1-F16 / DL-OUT1-F16 54

9.4 Defining the DVI-IN2-F16 / DVI-OUT2-F16 55

9.5 Defining the F610-IN2-F16 / F610-OUT2-F16 56

9.6 Defining the F670-IN2-F16 / F670-OUT2-F16 57

9.7 Defining the HH-IN2-F16 / HH-OUT2-F16 59

9.8 Defining the HAA-IN2-F16 / HAA-OUT2-F16 60

9.9 Defining the HAD-IN2-F16 / HAD-OUT2-F16 62

9.10 Defining the HDBT-IN2-F16 / HDBT-OUT2-F16 64

9.11 Defining the HDBT7-IN2-F16 / HDBT7-OUT2-F16 67

9.12 Defining the HDCP-IN2-F16 / HDCP-OUT2-F16 70

9.13 Defining the SDIA-IN2-F16 71

9.14 Defining the UHD-IN2-F16 / UHD-OUT2-F16 74

9.15 Defining the UHDA-IN2-F16 / UHDA-OUT2-F16 76

9.16 Defining the VGA-IN2-F16 / VGA-OUT2-F16 78

ii VS-1616D – Contents

9.17 Defining the VGAA-OUT2-F16 / VGAA-IN2-F16 80

9.18 Defining the HS-OUT2-F16 84

10 Configuring the Number of Installed Input and Output Ports 86

11 Using the Test Module to Troubleshoot Video and Audio Problems 87

11.1 Troubleshooting Video Problems 87

11.2 Troubleshooting Audio Problems 89

12 Input / Output Card Hardware Installation Instructions 92

13 Upgrading the VS-1616D Firmware 95

14 Technical Specifications 96

15 Default Settings 97

15.1 Default Communication Parameters 97

15.2 Factory Default EDID 97

16 Protocol 3000 125

16.1 Understanding Protocol 3000 Commands 126

16.2 Protocol 3000 Syntax 127

16.3 Protocol 3000 Commands 128

16.4 Using the Packet Protocol 154

17 Protocol 2000 155

Figures

Figure 1: VS-1616D Front Panel 8

Figure 2: VS-1616D Front Panel Numeric Keypad 9

Figure 3: VS-1616D Rear Panel Showing DVI cards 10

Figure 4: Connecting the VS-1616D 14

Figure 5: Sample Port Numbering 15

Figure 6: EDID Numbering Assignment 16

Figure 7: Local Area Connection Properties Window 17

Figure 8: Internet Protocol Version 4 Properties Window 18

Figure 9: Internet Protocol Version 6 Properties Window 19

Figure 10: Internet Protocol Properties Window 20

Figure 11: Default Startup Status Display Sequence 21

Figure 12: Menu Tree 28

Figure 13: Resolution DIP-switch 47

Figure 14: DGKat Card Serial Data Transmission 53

Figure 15: Connecting IR Emitter / Receiver 67

Figure 16: Accessing Audio over VGA 81

Figure 17: Signal Paths for Isolating Video Problems 88

Figure 18: Signal Paths for Isolating Audio Problems 90

Figure 19: Inserting the Card into a Slot 92

Figure 20: Card Handles 93

VS-1616D – Introduction 1

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 14 groups that are clearly defined by

function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11:

Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio; and

GROUP 14: Collaboration.

Congratulations on purchasing your Kramer VS-1616D 2x2 to 16x16 Modular Multi-

Format Digital Matrix Switcher. This product, which incorporates HDMI™

technology, is ideal for:

•Professional display systems requiring video signal routing

•Broadcast, presentation and production facilities, as well as monitoring in

large duplication systems

•Rental/staging applications

Throughout this user manual the chassis configuration is shown with 16

DVI inputs and 16 DVI outputs as a representation only.

The following cards are available and may be mixed in the same chassis:

•AAD-IN2-F16 / AAD-OUT2-F16 (see Section 9.1)

•DGKat-IN2-F16 / DGKat-OUT2-F16 (see Section 9.2)

•DL-IN1-F16 / DL-OUT1-F16 (see Section 9.3)

•DVI-IN2-F16 / DVI-OUT2-F16 (see Section 9.4)

•F610-IN2-F16 / F610-OUT2-F16 (see Section 9.5)

2 VS-1616D – Introduction

•F670-IN2-F16 / F670-OUT2-F16 (see Section 9.6)

•HH-IN2-F16 / HH-OUT2-F16 (see Section 9.7)

•HAA-IN2-F16 / HAA-OUT2-F16 (see Section 9.8)

•HAD-IN2-F16 / HAD-OUT2-F16 (see Section 9.9)

•HDBT-IN2-F16 / HDBT-OUT2-F16 (see Section 9.10)

•HDBT7-IN2-F16 / HDBT7-OUT2-F16 (see Section 9.11)

•HDCP-IN2-F16 / HDCP-OUT2-F16 (see Section 9.12)

•SDIA-IN2-F16 (see Section 9.13)

•UHD-IN2-F16 / UHD-OUT2-F16 (see Section 9.14)

•UHDA-IN2-F16 / UHDA-OUT2-F16 (see Section 9.15)

•VGA-IN2-F16 / VGA-OUT2-F16 (see Section 9.16)

•VGAA-IN2-F16 / VGAA-OUT2-F16 (see Section 9.17)

•HS-OUT2-F16 (see Section 9.18)

The F670-IN2/OUT2-F16 cards are fully compatible with the Kramer

670T/670R and 671T/671R HDMI/DVI transmitters and receivers for non-

HDCP content.

VS-1616D – Getting Started 3

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

•Review the contents of this user manual

Go to www.kramerav.com/downloads/vs-1616D to check for up-to-date

user manuals, application pr

ograms, and to check if firmware upgrades are

available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

•Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

•Do not secure the cables in tight bundles or roll the slack into tight coils

•Avoid interference from neighbouring electrical appliances that may adversely

influence signal quality

•Position your VS-1616D away from moisture, excessive sunlight and dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

Kramer engineers have developed special twisted pair cables to best match our

digital twisted pair products; Kramer’s BC-UNIKat shielded twisted pair (U/FTP)

cables. These specially built cables significantly outperform regular CAT 6 and

CAT 7a cables.

2.2 Safety Instructions AC

Caution:

There are no operator serviceable parts inside the unit

Warning:

Use only the power cord that is supplied with the unit
