Kramer VP-450 Manuel utilisateur

Kramer Electronics, Ltd.

USER MANUAL

Model:

VP-450

1:4 High Resolution UXGA DA

Contents

Introduction 1

Getting Started 1

Overview 1

Your VP-450 1:4 High Resolution UXGA DA 2

Connecting Your VP-450 1:4 High Resolution UXGA DA 5

Technical Specifications 7

Figures

Figure 1: VP-450 1:4 High Resolution UXGA DA 2

Figure 2: VP-450 1:4 High Resolution UXGA DA – Top and Lower Side Panels 3

Figure 3: VP-450 1:4 High Resolution UXGA DA Underside 4

Figure 4: Connecting the VP-450 6

Tables

Table 1: Features and Functions of the VP-450 1:4 High Resolution UXGA DA 3

Table 2: VP-450 1:4 High Resolution UXGA DA Underside Features 4

Table 3: Technical Specifications of the VP-450 1:4 High Resolution UXGA DA 7

2900-

9999992 A1

ADDENDUM (this data is included at the end of the Overview section)

This addendum adds the following information to the user manual:

Caution – No operator-serviceable parts inside unit.

Warning – Use only the Kramer Electronics input power

wall adapter that is provided with this unit

Warning – Disconnect power and unplug unit from wall

before installing or removing device or servicing unit.

1 For example: model number AD2512C, part number 2535-000251

Introduction

1 Introduction

Welcome to Kramer Electronics (since 1981): a world of unique, creative and

affordable solutions to the infinite range of problems that confront the video, audio

and presentation professional on a daily basis. In recent years, we have redesigned

and upgraded most of our line, making the best even better! Our 350-plus different

models now appear in 8 Groups

, which are clearly defined by function.

Congratulations on purchasing your Kramer TOOLS VP-450 1:4 High

Resolution UXGA DA which is ideal for:

 Multi monitor applications or presentation systems requiring local

monitors and large screen display devices such as a projector

 Rental and staging systems

 Schools, churches, corporate applications

The package includes the following items:

 VP-450 1:4 High Resolution UXGA DA

 Power adapter (12V DC Input)

 This user manual

2 Getting Started

We recommend that you:

 Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

 Review the contents of this user manual

 Use Kramer high performance high resolution cables

3 Overview

The Kramer VP-450 is a high performance 1:4 distribution amplifier for

UXGA and higher resolution signals.

1 GROUP 1: Distribution Amplifiers; GROUP 2: Video and Audio Switchers, Matrix Switchers and Controllers; GROUP 3:

Video, Audio, VGA/XGA Processors; GROUP 4: Interfaces and Sync Processors; GROUP 5: Twisted Pair Interfaces;

GROUP 6: Accessories and Rack Adapters; GROUP 7: Scan Converters and Scalers; and GROUP 8: Cables and Connectors

2 Download up-to-date Kramer user manuals from our Web site: http://www.kramerelectronics.com

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your VP-450 1:4 High Resolution UXGA DA

The VP-450:

 Accepts one input, provides correct buffering and isolation, and then distributes

the signal to 4 identical outputs on high-density 15-pin HD connectors

 Has a video bandwidth exceeding 400MHz, ensuring that the machine

remains transparent even at high-resolution graphics modes such as

UXGA (1600x1200)

 Accepts analog or digital syncs

and provides ID Bit control

 Can output video signals that are DC or AC coupled for maximum

flexibility (selected via red, green and blue coupling buttons)

To achieve the best performance:

 Connect only good quality connection cables, thus avoiding interference,

deterioration in signal quality due to poor matching, and elevated noise

levels (often associated with low quality cables)

 Avoid interference from neighboring electrical appliances that may

adversely influence signal quality and position your Kramer VP-450 away

from moisture, excessive sunlight and dust

4 Your VP-450 1:4 High Resolution UXGA DA

Figure 1, Figure 2 and Table 1 define the VP-450 unit:

Top Side Panel

Lower Side Panel

Figure 1: VP-450 1:4 High Resolution UXGA DA

1 The polarity is determined via a pair of underside switches. Note that both the Hs (horizontal sync) switch and the Vs

(vertical sync) switch should be set identically

2 Via an underside switch. Sometimes notebook computers refuse to output a VGA signal to an external VGA monitor. By

setting the ID BIT to ON, the notebook will output to an external VGA monitor

Your VP-450 1:4 High Resolution UXGA DA

Top Side Panel

Lower Side Panel

Figure 2: VP-450 1:4 High Resolution UXGA DA – Top and Lower Side Panels

Table 1: Features and Functions of the VP-450 1:4 High Resolution UXGA DA

# Feature Function

1 OUTPUT 2 HD15F Connector Connect to the UXGA acceptor 2

2 OUTPUT 1 HD15F Connector Connect to the UXGA acceptor 1

3 12V DC +12V DC connector for powering the unit

4 INPUT HD15F Connector Connect to the UXGA source

5 OUTPUT 3 HD15F Connector Connect to the UXGA acceptor 3

6 ON LED Illuminates when receiving power

7 OUTPUT 4 HD15F Connector Connect to the UXGA acceptor 4

Figure 3 and Table 2 define the switches on the underside of the VP-450:

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Your VP-450 1:4 High Resolution UXGA DA

Figure 3: VP-450 1:4 High Resolution UXGA DA Underside

Table 2: VP-450 1:4 High Resolution UXGA DA Underside Features

# Feature Function

1 BLUE DC-AC Switch

2 GREEN DC-AC Switch

COUPLING

RED DC-AC Switch

Switch to DC to select DC coupling

, switch to AC to select AC

coupling (removing the DC offset of the input signal)

4 Hs (Horizontal Sync) Switch

5 Vs (Vertical Sync) Switch

Set both switches

to Hi-Z (TTL

) if the source is, for example, a

digital graphics card. Set both switches to 75(ANALOG) if the

source is analog based, for example, an RGBHV source with coaxial

cable for sync

6 ID Bit Switch Slide to the left to set to ON

; to the right to set to OFF

1 Achieving the best linearity and signal fidelity

2 Both the Hs and the Vs switches should be set identically – since graphics cards do not have mixed (TTL and ANALOG)

syncs. (No harm will occur to the graphics source if the switches are set to the wrong direction)

3 “Transistor-Transistor Logic” for syncs with digital logic levels

4 Enabling the notebook or laptop to output a VGA signal to an external VGA monitor

Connecting Your VP-450 1:4 High Resolution UXGA DA

5 Connecting Your VP-450 1:4 High Resolution UXGA DA

To output a UXGA

signal from a computer graphics card to 4 monitors, as the

example in Figure 4 illustrates, do the following:

1. Connect a UXGA

source (for example, a computer graphics card) to the

INPUT HD15F connector.

2. Connect the OUTPUT HD15F connectors to up to 4 acceptors, as follows:

 Connect the OUTPUT 1 connector to an acceptor (for example,

Display 1)

 Connect the OUTPUT 2 connector to an acceptor (for example,

Display 2)

 Connect the OUTPUT 3 connector to an acceptor (for example,

Display 3)

 Connect the OUTPUT 4 connector to an acceptor (for example,

Display 4)

3. On the underside of the VP-450:

 Set both the Hs and Vs switches to Hi-Z (TTL)

 Slide the ID Bit switch to the left to set to ON

 Set the RED, BLUE and GREEN COUPLING switches either to DC

or AC, according to the output requirements

4. Connect the 12V DC power adapter to the power socket and connect the

adapter to the mains electricity.

1 Or any resolution, such as VGA, SVGA, XGA, and so on

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Connecting Your VP-450 1:4 High Resolution UXGA DA

Computer

Graphics Source

Display 1

Display 4



Figure 4: Connecting the VP-450

Technical Specifications

6 Technical Specifications

Table 3 includes the technical specifications:

Table 3: Technical Specifications

of the VP-450 1:4 High Resolution UXGA DA

INPUT: 1 XGA on an HD15F connector

OUTPUTS: 4 XGA on HD15F connectors

MAX. OUTPUT LEVEL:

2.3Vpp

BANDWIDTH (-3dB): 420MHz

DIFF. GAIN: 0.04%

DIFF. PHASE: 0.03 Deg.

K-FACTOR: <0.05%

S/N RATIO: 81dB

CONTROLS: AC/DC selectors for R, G, B via 3 switches; Pair of switches for analog/TTL

selection syncs on the underside; ID Bit switch on the underside

COUPLING: DC/AC by selection

POWER SOURCE: 12VDC, 125mA

DIMENSIONS: 12cm x 7.15cm x 2.76cm (4.7" x 2.8" x 1.08"), W, D, H

WEIGHT: 0.3 kg. (0.67 lbs.) approx.

ACCESSORIES: Power supply, mounting bracket

OPTIONS: 19" rack adapters RK-T1, RK-T3

1 Specifications are subject to change without notice
