Kramer VM-100YC Manuel utilisateur

Kramer Electronics, Ltd.

USER MANUAL

Model:

VM-100YC

1:10 s-Video Distribution Amplifier

Contents

Introduction 1

Getting Started 1

Overview 2

Your VM-100YC 3

Connecting the VM-100YC 4

Technical Specifications 5

Figures

Figure 1: VM-100YC 1:10 s-Video Distribution Amplifier 3

Figure 2: Connecting the VM-100YC 1:10 s-Video Distribution Amplifier 4

Tables

Table 1: VM-100YC 1:10 s-Video Distribution Amplifier Features 3

Table 2: Technical Specifications of the VM-100YC 1:10 s-Video Distribution Amplifier 5

Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast

range of problems that confront the video, audio, presentation, and

broadcasting professional on a daily basis. In recent years, we have

redesigned and upgraded most of our line, making the best even better! Our

1,000-plus different models now appear in 11 groups

that are clearly

defined by function.

Congratulations on purchasing your Kramer VM-100YC, which is ideal for

the following typical applications:

Production and duplication facilities

Schools and boardrooms

Retail stores, point-of-sale systems, CCTV and security applications

The package includes the following items:

VM-100YC 1:10 s-Video Distribution Amplifier

Power supply (12V DC Input)

This user manual

2 Getting Started

We recommend that you:

Review the contents of this user manual

Use Kramer high performance high resolution cables

1 GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Matrix Switchers; GROUP 3: Control Systems; GROUP 4:

Format/Standards Converters; GROUP 5: Twisted-Pair Solutions; GROUP 6: Specialty AV Products; GROUP 7: Scan

Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and

Rack Adapters; GROUP 11: Sierra Products

2 Download up-to-date Kramer user manuals from the Internet at this URL: http://www.kramerelectronics.com

3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Overview

3 Overview

The VM-100YC is a high quality 1:10 s-Video Distribution Amplifier for

s-Video (Y/C) signals. It accepts one input, provides correct buffering and

isolation, and distributes the signal to 10 identical outputs using 4-pin

connectors. The looping connector can be used to connect to a local display or

other Y/C acceptor, or to create larger systems (for example, connecting three

VM-100YC units to make a 1:30 s-Video Distribution Amplifier).

In addition, the VM-100YC features:

Bandwidth (Y) - 275MHz (-3dB)

Level (gain) controls - Y and C (on the underside)

Selectable input signal termination

A compact desktop size. Two units can be rack mounted side-by-side in

a 1U rack space with the optional RK-1 adapter

To achieve the best performance:

Connect only good quality connection cables, thus avoiding interference,

deterioration in signal quality due to poor matching, and elevated

noise-levels (often associated with low quality cables)

Avoid interference from neighboring electrical appliances and position

your VM-100YC away from moisture, excessive sunlight and dust

Caution – No operator-serviceable parts inside unit.

Warning – Use only the Kramer Electronics input power

wall adapter that is provided with this unit

Warning – Disconnect power and unplug unit from wall

before installing or removing device or servicing unit.

1 For example: model number AD2512C, part number 2535-000251

Your VM-100YC

4 Your VM-100YC

Figure 1 and Table 1 define the VM-100YC.

Figure 1: VM-100YC 1:10 s-Video Distribution Amplifier

Table 1: VM-100YC 1:10 s-Video Distribution Amplifier Features

Feature Function

1 POWER Switch Illuminated switch for turning the unit ON or OFF

2 INPUT 4-pin Connector Connects to the s-Video source

3 LOOP 4-pin Connector For looping (if required) to increase the number of outputs

4 TERM Button Pushing in selects 75; releasing selects Hi-Z

5 OUT 4-pin Connector Connects to the s-Video acceptors (from 1 to 10)

6 12 VDC +12V DC connector for powering the unit

1 For looping select Hi-Z

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Connecting the VM-100YC

5 Connecting the VM-100YC

To connect the VM-100YC 1:10 s-Video Distribution Amplifier,as the

example in Figure 2 illustrates, do the following

1. Connect the s-Video source (for example, an s-Video player) to the

INPUT 4-pin connector.

2. Connect the OUT 4-pin connectors to up to 10 s-Video acceptors (for

example, s-Video recorders).

3. If required, connect the LOOP 4-pin connector, when looping units and

release the TERM switch on first unit (selecting Hi-Z). Push in the

TERM switch on the second unit (selecting 75).

4. Connect the 12V DC power adapter to the power socket and connect the

adapter to the mains electricity (not shown in Figure 2).

5. Switch on the VM-100YC.

The s-Video source distributes to the s-Video acceptors.

Figure 2: Connecting the VM-100YC 1:10 s-Video Distribution Amplifier

1 Switch OFF the power on each device before connecting it to your VM-100YC. After connecting your VM-100YC,

switch on its power and then switch on the power on each device

Technical Specifications

6 Technical Specifications

Table 2 defines the technical specifications:

Table 2: Technical Specifications

of the VM-100YC 1:10 s-Video Distribution Amplifier

INPUT: 1 s-Video: 1Vpp/75(Y), 0.3Vpp/75(C), on a 4-pin connector with a termination

switch

OUTPUT: 10 s-Video: 1Vpp/75(Y), 0.3Vpp/75(C), on 4-pin connectors; 1 s-Video loop

on a 4-pin connector

MAX. OUTPUT LEVEL: 1.9Vpp/75(Y)

BANDWIDTH (-3dB): 275MHz

DIFF. GAIN: 0.03%

DIFF. PHASE: 0.03 Deg.

K-FACTOR: < 0.05%

S/N RATIO: 81.4dB

CONTROLS: Trimmers for "Y" level: -1.4 to +6dB; "C" level: -1 to +6.3dB

COUPLING: AC

POWER SOURCE: 12 VDC, 80mA

DIMENSIONS: 22cm x 18cm x 4.5cm (8.7" x 7" x 1.7") W, D, H.

WEIGHT: 0.93kg (2lbs) approx.

ACCESSORIES: 12 VDC power supply

OPTIONS: RK-1 19" rack adapter

1 Specifications are subject to change without notice

KRAMER: SIMPLE CREATIVE TECHNOLOGY

Kramer Electronics, Ltd.

Web site: www.kramerelectronics.com

E-mail: [email protected]

P/N: 2900-002071 REV 3

For the latest information on our products and a list of Kramer

distributors, visit our Web site: www.kramerelectronics.com,

where updates to this user manual may be found.

We welcome your questions, comments and feedback.

Caution

Safety Warning:

Disconnect the unit from the power supply before

opening/servicing.
