Kramer VM-73 Manuel utilisateur

KRAMER ELECTRONICS LTD.

USER MANUAL

MODEL:

VM-73

Multiformat 1:3 Distribution

Amplifier

P/N: 2900-000544 Rev 3

VM-73 – Contents i

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Recycling Kramer Products 2

3Overview 3

3.1 Defining the VM-73 Multiformat 1:3 Distribution Amplifier 3

4Installing in a Rack 5

5Connecting the VM-73 6

5.1 Reading the EDID 8

6Technical Specifications 9

Figures

Figure 1: UVM-73UMultiformat 1:3 Distribution Amplifier Front Panel 4

Figure 2: Connecting the UVM-73UMultiformat 1:3 Distribution Amplifier 7

VM-73 - Introduction 1

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 11 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters and GROUP 11:

Sierra Products.

Congratulations on purchasing your Kramer VM-73 Multiformat 1:3 Distribution

Amplifier, which is ideal for the following typical applications:

•Video reproduction in studios

•School and university presentations

2 VM-73 - Getting Started

2 Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

•Review the contents of this user manual

•Use Kramer high-performance, high-resolution cables

•Use only the power cord that is supplied with this machine

Go to http://www.kramerelectronics.com to check for up-to-date

user manuals, application programs, and to check if firmware

upgrades are available (where appropriate).

2.1 Achieving the Best Performance

To achieve the best performance:

•Use only good quality connection cables to avoid interference, deterioration

in signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

•Do not secure the cables in tight bundles or roll the slack into tight coils

•Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

•Position your Kramer VM-73 away from moisture, excessive sunlight and

dust

2.2 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC

aims to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility. For details of Kramer’s recycling arrangements in your particular country

go to our recycling pages at http://www.kramerelectronics.com/support/recycling/.

VM-73 - Overview 3

3 Overview

The VM-73 is a high-performance distribution amplifier for HDMI, computer

graphics, component video, s-Video and composite video signals. The unit takes

one input of each video format and distributes each input to three identical outputs.

Specifically, the VM-73 features:

•Multiformat operation: composite, component, Y/C, XGA and HDMI

•High bandwidth (-3dB) of 430MHz for composite video, 440MHz for Y/C,

430MHz for component video, 405MHz for XGA and 2.25Gbps for HDMI

•HDTV compatibility

•HDMI and HDCP compatibility

•The ability to pass EDID information from PC OUT 1 to the PC input

•The option to acquire the EDID information from the highest priority

connected HDMI output

OUT 1 being the highest priority output and OUT 3 the lowest (see Section5.1.2)

•A worldwide power supply 100-240V AC

•A standard 19” rack mount size, rack “ears” included

3.1 Defining the VM-73 Multiformat 1:3 Distribution

Amplifier

This section defines the VM-73.

4 VM-73 - Overview

Figure 1: VM-73 Multiformat 1:3 Distribution Amplifier Front Panel

# Feature Function

1 POWER LED Lights green when receiving power

2 HDMI INPUT Connector Connects to the HDMI source

3 HDMI OUT Connectors Connect to the HDMI acceptors (1 to 3)

4 PC INPUT 15-pin HD Connector Connects to the computer graphics source

5 PC OUT 15-pin HD Connectors Connect to the computer graphic acceptors (1 to 3)

6 COMP. INPUT RCA Connectors Connects to the component video source

7 COMP. OUT RCA Connectors Connect to the component video (Y/Pr/Pb) acceptors (1 to 3)

8 Y/C INPUT s-Video Connector Connects to the Y/C video source

9 Y/C OUT s-Video Connectors Connect to the Y/C acceptors (1 to 3)

10 CV INPUT BNC Connector Connects to the composite video source

11 CV OUT BNC Connectors Connect to the composite video acceptors (1 to 3)

12 POWER IN with Fuse AC connector and fuse enabling power supply to the unit

13 POWER Switch Illuminated switch for turning the unit on and off

4VM-73 – Overview

VM-73 - Installing in a Rack 5

4 Installing in a Rack

This section provides instructions for rack mounting the unit.

6 VM-73 - Connecting the VM-73

5 Connecting the VM-73

Always switch off the power to each device before connecting it to your

VM-73. After connecting your VM-73, connect its power and then

switch on the power to each device.

To connect the VM-73 as illustrated in the example in Figure 2:

1. Connect the HDMI input source (for example, a DVD player) to the HDMI

INPUT connector.

2. Connect the three HDMI OUT connectors to up to three HDMI acceptors, (for

example, LCD televisions with speakers).

Not all outputs need to be connected.

3. Connect a computer graphics input source (for example, a PC graphics card)

to the PC INPUT 15-pin HD connector.

4. Connect the three PC OUT 15-pin HD connectors to up to three PC

acceptors (for example, VGA displays or projectors).

5. Connect the component input source (for example, a DVD player) to the

COMP. INPUT RCA connectors (Y/Pb/Pr or Y/Cb/Cr).

6. Connect the three COMP. OUT connectors to up to three component

acceptors (for example, component displays or projectors).

7. Connect the Y/C input source (for example, a DVD player) to the Y/C INPUT

s-Video connector.

8. Connect the three Y/C OUT connectors to up to three Y/C acceptors (for

example, displays).

9. Connect the composite video input source (for example, a DVD player) to

the CV INPUT BNC connector.

10. Connect the three CV OUT connectors to up to three CV acceptors, (for

example, video recorders).

VM-73 - Connecting the VM-73 7

11. Connect the power cord to the mains electricity (not shown in Figure 2).

12. Turn the POWER on.

Figure 2: Connecting the VM-73 Multiformat 1:3 Distribution Amplifier
