Kramer VM-8HN Manuel utilisateur

KRAMER ELECTRONICS LTD.

USER MANUAL

MODEL:

VM-8HN

1:8+2 HDMI Looping DA

P/N: 2900-300427 Rev 4

VM-8HN – Contents

Contents

1Introduction 1

2Getting Started 2

2.1 Achieving the Best Performance 2

2.2 Safety Instructions 3

2.3 Recycling Kramer Products 3

3Overview 4

3.1 Defining the VM-8HN 1:8+2 HDMI Looping DA 5

4Installing in a Rack 8

5Connecting the VM-8HN 9

5.1 Acquiring an EDID 10

5.2 Setting the DIP-Switches 11

6Protocol 3000 12

6.1 Command Summary 12

6.2 Command Details 12

6.3 EDID Source 16

6.4 Signal Validation 16

6.5 Stage 16

6.6 HDCP Types 16

7Technical Specifications 17

Figures

Figure 1: VM-8HN 1:8+2 HDMI Looping DA Front Panel 6

Figure 2: VM-8HN 1:8+2 HDMI Looping DA Rear Panel 7

Figure 3: Connecting the VM-8HN 1:8+2 HDMI Looping DA 10

VM-8HN - Introduction

1 Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been

providing a world of unique, creative, and affordable solutions to the vast range of

problems that confront video, audio, presentation, and broadcasting professionals

on a daily basis. In recent years, we have redesigned and upgraded most of our

line, making the best even better!

Our 1,000-plus different models now appear in 14 groups that are clearly defined

by function: GROUP 1: Distribution Amplifiers; GROUP 2: Switchers and Routers;

GROUP 3: Control Systems; GROUP 4: Format/Standards Converters; GROUP 5:

Range Extenders and Repeaters; GROUP 6: Specialty AV Products; GROUP 7:

Scan Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9:

Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11:

Sierra Video Products; GROUP 12: Digital Signage; GROUP 13: Audio; and

GROUP 14: Collaboration.

Congratulations on purchasing your Kramer VM-8HN 1:8+2 HDMI Looping DA,

which is ideal for the following typical applications:

Digital signage

Entertainment

Rental and staging

VM-8HN - Getting Started

2 Getting Started

We recommend that you:

Unpack the equipment carefully and save the original box and packaging

materials for possible future shipment

Review the contents of this user manual

2.1 Achieving the Best Performance

To achieve the best performance:

Use only good quality connection cables (we recommend Kramer high-

performance, high-resolution cables) to avoid interference, deterioration in

signal quality due to poor matching, and elevated noise levels (often

associated with low quality cables)

Do not secure the cables in tight bundles or roll the slack into tight coils

Avoid interference from neighboring electrical appliances that may adversely

influence signal quality

Position your Kramer VM-8HN away from moisture, excessive sunlight and

dust

This equipment is to be used only inside a building. It may only be

connected to other equipment that is installed inside a building.

VM-8HN - Getting Started

2.2 Safety Instructions

Caution:

There are no operator serviceable parts inside the unit

Warning:

Use only the power cord that is supplied with the unit

Warning:

Do not open the unit. High voltages can cause

electrical shock! Servicing by qualified personnel only

Warning:

Disconnect the power and unplug the unit from the wall

before installing

2.3 Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC

aims to reduce the amount of WEEE sent for disposal to landfill or incineration by

requiring it to be collected and recycled. To comply with the WEEE Directive,

Kramer Electronics has made arrangements with the European Advanced

Recycling Network (EARN) and will cover any costs of treatment, recycling and

recovery of waste Kramer Electronics branded equipment on arrival at the EARN

facility.

VM-8HN - Overview

3 Overview

The VM-8HN is a high-quality 1:8 HDMI distributor with 2 looping HDMI outputs

that takes one HDMI input, equalizes and reclocks the signal and distributes it to

eight identical outputs and two loops. The VM-8HN distributes signals having

resolutions up to 4Kx2K 30Hz and including WUXGA and 1080p.

In particular, the VM-8HN features:

A maximum data rate of 10.2Gbps (3.4Gbps per graphic channel)

HDMI support for Deep Color, x.v.Color™, Lip Sync, HDMI Uncompressed

Audio Channels, Dolby TrueHD, DTS-HD, CEC (CEC pass through from

input to output 1 only)

HDCP compliance

Video wall support that mutes the video on all displays and simultaneously

unmutes them when all inputs are ready; with selectable output delay.

Automatic 5V turn off - When no active input signal is detected, the unit turns

off 5V on the output allowing attached devices to power off.

MAC Setting enables and disables HDCP support on the input allowing the

source to transmit a non−HDCP signal if required.

Force RGB modifies the EDID saved on the input to support RGB format

(that is, not YUV format).

Kramer Equalization & re-Klocking™ Technology that rebuilds the digital

signal integrity to travel longer distances

I-EDIDPro™ Kramer Intelligent EDID Processing™, an intelligent EDID

handling and processing algorithm that ensures Plug and Play operation for

HDMI systems

A default EDID for fast and efficient connection of the unit

The default EDID feature lets you connect the VM-8HN without having to connect a

display to the output

Support for EDID Designer

3D pass-through

VM-8HN - Overview

3.1 Defining the VM-8HN 1:8+2 HDMI Looping DA

This section defines the VM-8HN.

VM-8HN - Overview

VM-8HN –Overview

Figure 1: VM-8HN 1:8+2 HDMI Looping DA Front Panel

Feature

Function

ON LED

Lights when the device is powered on

EDID READ Button

Press to select the chosen output

EDID SELECT Button

Press to sequentially cycle through the outputs

IN LED

Lights when an active input signal is detected

OUT LED (1-8)

Lights when an active output acceptor is detected, flashes when HDCP is not supported by the monitor

LOOP LED (1-2)

Lights when an active output loop acceptor is detected

PROGRAM mini USB Connector

Use to upgrade the device firmware, also works with the EDID Designer

VM-8HN - Overview

Figure 2: VM-8HN 1:8+2 HDMI Looping DA Rear Panel

Feature

Function

INPUT Connector

Connects to the HDMI source

OUT Connector (1-8)

Connect to up to 8 HDMI acceptors

LOOP Connector (1-2)

Connect to up to 2 HDMI loop acceptors

SETUP DIP-Switches

Adjust to set output delay, automatic power off for the 5V output, MAC mode, programming, force RGB

MAC settings enable the system to force the source to input non-HDCP content.

Force RGB forces the source to send video with an RGB color space.

RESET Button

Press to return to default EDID

Power Socket, Fuse and Switch

Connects power to and switches the unit on and off

VM-8HN –Overview
