Konica Minolta AFR-12 Guide de configuration

Table Of Contents-1 AFR-12/AF-5Rev. 1.0/05.99

right

GENERAL/MECHANICAL/

ELECTRICAL

D:\SM\MAN-

UALS\AFR12\

GB\M\FRONT

_M.GB

05.99

Table Of Contents-2EP1052 Rev. 1.0/05.99

left

1GENERAL/MECHANICAL/ELECTRICAL

1.1 Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1

1.2 Components Identification- - - - - - - - - - - - - - - - - - - - 4

1.3 Cross-sectional View- - - - - - - - - - - - - - - - - - - - - - - - 6

1.4 Drive System - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 8

1.5 Electrical Component Layout- - - - - - - - - - - - - - - - - - 9

1.6 Description Of Modes - - - - - - - - - - - - - - - - - - - - - - 10

1.6.1 Mixed Original Mode- - - - - - - - - - - - - - - - - - - - - - - - - - - - - 10

1.6.2 1-Sided Original Mode - - - - - - - - - - - - - - - - - - - - - - - - - - - 10

1.6.3 2-Sided Mode - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 10

1.6.4 2-in-1 Mode - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 10

1.6.5 S-ADF (Single Feed) Mode - - - - - - - - - - - - - - - - - - - - - - - - 10

1.6.6 Thin Mode (As set by "Original Thickness" of User’s Mode) - 11

1.7 Document Take-up/feeding Mechanism - - - - - - - - - 12

1.7.1 Construction - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 12

1.7.2 Document Pick-Up Mechanism - - - - - - - - - - - - - - - - - - - - - 13

1.7.3 Document Take-Up Mechanism- - - - - - - - - - - - - - - - - - - - - 14

1.7.4 Separating Mechanism - - - - - - - - - - - - - - - - - - - - - - - - - - - 16

1.7.5 Single Feed Mechanism - - - - - - - - - - - - - - - - - - - - - - - - - - 17

1.8 Document Transport Mechanism- - - - - - - - - - - - - - 18

1.8.1 Construction - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 18

1.8.2 Document Transport Mechanism - - - - - - - - - - - - - - - - - - - - 18

1.8.3 Original Width Scale Retraction Mechanism - - - - - - - - - - - - 19

1.9 Turnover/Exit Mechanism - - - - - - - - - - - - - - - - - - - 20

1.9.1 Construction - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 20

1.9.2 Turnover/Exit Document Transport Mechanism- - - - - - - - - - 21

1.9.3 Turnover/Exit Switching Mechanism (AFR-12) - - - - - - - - - - 23

1.9.4 Exit Mechanism (AF-5) - - - - - - - - - - - - - - - - - - - - - - - - - - - 24

Table Of Contents-3 AFR-12/AF-5Rev. 1.0/05.99

right

1.10 Miscellaneous - - - - - - - - - - - - - - - - - - - - - - - - - - - - 25

1.10.1 Document Size Detection Mechanism - - - - - - - - - - - - - - - - 25

1.10.2 Raised/Lowered Position Detecting Mechanism - - - - - - - - - 25

M-1 AFR-12/AF-5Rev. 1.0/05.99

right

General/Mechanical

Electrical

1GENERAL/MECHANICAL/ELECTRICAL

1.1 Specifications

NAME Duplexing Document Feeder AFR-12

Document Feeder AF-5

TYPE ●Paper Take-Up: Take-up from top of stack,

U-turn feeding

●Transport: Automatic single-belt transport system

●Turnover: Loop turnover system (AFR-12)

●Ejection: U-turn ejection

INSTALLATION Mounted onto the copier

TYPE OF DOCUMENT ●Plain paper

●1-Sided and Dual Original

●Scanning (2-in-1) Modes: 50 to 100 g/m²

●2-Sided Mode: 60 to 90 g/m²

●Mixed Original Mode: 60 to 90 g/m²

●Single Feed Mode: AFR-12 · 35 to 200 g/m²,

AF-5 · 35 to 157 g/m²

DETECTABLE

DOCUMENT SIZES A3L, B4L, A4LC, B5LC, A5L, 11" x 17"L, 8-1/2" x 14"L,

8-1/2" x 11"LC, 11" x 15"L, 8-1/4" x 13"L

CAPACITY ●Document Feed Table:

A4 or smaller 50 sheets (of paper weighing 80 g/m²)

B4 or larger 30 sheets (of paper weighing 80 g/m²)

●Document Exit Table:

A4 or smaller 50 sheets (of paper weighing 80 g/m²)

B4 or larger 30 sheets (of paper weighing 80 g/m²)

ALIGNMENT Aligned along the rear Document Edge Guide

DOCUMENT LOADING Face up (Single Feed Mode-Face down)

D:\SM\MAN-

UALS\AFR12\

GB\M\AFR_1

2M.GB

05.99

M-2AFR-12/AF-5 Rev. 1.0/05.99

left

MODES ●1-Sided Original

●2-Sided Original

●2-in-1

●Mixed Original

●Single Feed Mode

The "Original Thickness" function of User’s Choice

permits selection between the plain paper and thin

paper mode.

POWER SOURCE 24 VDC, supplied from the copier

POWER

CONSUMPTION AFR-12 · 60W or less/2.5A AF-5 · 48W or less/2A

DIMENSIONS

<AFR-12> Width 627 mm

Depth 515 mm

Height 125 mm

WEIGHT

<AFR-12> 13.0 kg

DIMENSIONS

<AF-5> Width 604 mm

Depth 515 mm

Height 125 mm

WEIGHT

<AF-5> 12.0 kg or less

OPERATING

ENVIRONMENT Same as copier

DOCUMENTS WHICH

CANNOT BE USED The following documents, if used in the AFR-12/AF-5,

are very likely to cause trouble.

Type of Document Possible Trouble

Documents stapled or clipped

together Take-up failure, damaged document, defective drive train due to

jammed staples or clips.

Documents glued together Take-up failure, damaged document

Documents folded, torn, or wrinkled Take-up failure, damaged document

Documents severely curled Documents mis-fed due to being dog-eared

M-3 AFR-12/AF-5Rev. 1.0/05.99

right

General/Mechanical

Electrical

DOCUMENTS FOR

WHICH

FEEDING CANNOT BE

GUARANTEED.

The following documents, if used in the

AFR-12/AF-5, may or may not cause trouble.

Type of Document Possible Trouble

Slightly curled documents Dog-eared pages, ejection failure

Heat-sensitive paper for facsimile Crease, ejection failure

Coated documents Take-up failure

Documents with uneven surface

(letter head etc.) Take-up failure

Translucent paper Take-up failure, transport failure

Paper just ejected from the ADF Take-up failure, transport failure

Perforated documents (loose

leafed etc.) Take-up failure, transport failure

Documents weighing 40 to 50 g/m² Folded leading edge, transport failure

Folded documents Transport failure, distorted image

M-4AFR-12/AF-5 Rev. 1.0/05.99

left

1.2 Components Identification

D:\SM\MAN-

UALS\AFR12\

GB\M\AFR_1

2M.GB

05.99 12

<AF-5> <AFR-12>

M-5 AFR-12/AF-5Rev. 1.0/05.99

right

General/Mechanical

Electrical

1. Hookup Cord

2. Maintenance Cover

3. Take-Up Cover

4. Single Feed Tray

5. Document Feed Table

6. Turnover Cover Release Switch (AFR-12)

7. Turnover Cover (AFR-12)

8. Transport Belt

9. Magnet Catches

10.Guide Plate Release Lever (AF-5)

M-6AFR-12/AF-5 Rev. 1.0/05.99

left

1.3 Cross-sectional View

D:\SM\MAN-

UALS\AFR12\

GB\M\AFR_1

2M.GB

05.99

16 15 14 13 12 1110 987

18 <AFR-12>

21 <AF-5>

M-7 AFR-12/AF-5Rev. 1.0/05.99

right

General/Mechanical

Electrical

1. Document Detecting Sensor (S1)

2. Document Take-Up Roller

3. Document Separator Roller

4. Registration Sensor

5. Single Feed Transport Roller

6. Manual Feed Take-up Sensor (PWB-D)

7. Single Feed Transport Roll

8. Registration Driven Roller

9. Registration Drive Roller

10.Size Sensor

11.Transport Belt Drive Roller

12.Transport Rolls

13.Transport Belt Guide Roller

14.Transport Belt Driven Roller

15. Exit Roller

16.Turnover Roller

17.Turnover/Exit Sensor

18.Turnover/Exit Switching Plate

19.Exit Roll

20.Exit Transport Roll

21.Exit Sensor (S3)

22.Exit Transport Roller
