Kohler Underscore K-1167-XH2GR Guide de l'utilisateur

Features

•Flange helps prevent water from seeping behind wall and

simplifies alcove installation.

•Right drain.

•Integral lumbar support and armrests for comfort.

•Slotted overflow allows for deep soaking.

•60" (1524 mm) x 30" (762 mm) x 19" (483 mm)

Material

•Acrylic

Hydrotherapy

•118-122 BubbleMassage™airjets.

•Variable-speed blower lets you adjust airjet massage intensity

to 18 levels.

•Variable-speed pump for adjusting hydromassage intensity.

•Zones of Control™feature allows you to target airjet massage

to back, midsection, or feet. Codes/Standards

•Automatic purge cycles remove residual water from air channels

after use. ASME A112.19.7/CSA B45.10

CSA B45.5/IAPMO Z124

•Single-speed whirlpool offers eight fully adjustable

hydro-massage jets for water flow and direction. ASTM E162

ASTM E662

•Pump with air switch for whirlpool. UL 1795

•Built-in 1500 W heater. CSA C22.2 No. 218.2

Installation Greenguard UL 2818 - Gold

EPA TSCA Title VI

•Three-wall alcove.

Required Accessories

K-7271 Brass Slotted Overflow Bath Drain

KOHLER®Plastic Baths and Receptors

Lifetime Limited Warranty

K-7272 PVC Slotted Overflow Bath Drain KOHLER®Hydrotherapy Components

Five-Year Limited Warranty

K-9698 Flexjet®Whirlpool Trim Kit See website for detailed warranty information.

Recommended Accessories

K-1491 Bath/Whirlpool Pillow Available Color/Finishes

K-1601 Bath/Whirlpool Footstop Color tiles intended for reference only.

K-9497 2-1/2" Keypad Trim

K-24916 Wireless Music Kit DescriptionCodeColor

White0

Biscuit96

Almond47

DuneNY

Ice™Grey95

SandbarG9

CashmereK4

Thunder™Grey58

1-800-4KOHLER (1-800-456-4537)

Kohler Co. reserves the right to make revisions without notice to product specifications.

For the most current Specification Sheet, go to www.kohler.com.

9-28-2018 08:43

Underscore®Rectangle

5' BubbleMassage™Whirlpool Bath

K-1167-XH2GR

18"

Notes

Required Electrical Service Measure your actual product for rough-in details.

One dedicated circuit required, protected with Class A

Ground-Fault Circuit-Interrupter (GFCI) or Residual Current Device

(RCD).

Install this product according to the installation

instructions.

The hot water supply should be 70% of the

capacity of the bath or greater. Installations will

vary.

220-240 V, 20 A, 50/60 HzBlower, Pump,

Heater:

Technical Information This unit is not intended for flush-mount apron

installation.

All product dimensions are nominal.

3-Wall AlcoveInstallation: IMPORTANT! Dry fit the drain assembly prior to

installing the bath. The bath cannot be installed

with all drain components attached.

RightDrain location:

42-7/16" x 20" (1078 mm x 508 mm)Basin area, bottom:

54-5/16" x 24-1/4" (1380 mm x 616 mm)Basin area, top: The pump base extends 10-1/4" (260 mm)

beyond the edge of the rim. Modify the framing

as needed.

157 lbs (71.2 kg)Weight:

53.9 lbs/ft²(263.2 kg/m²)Minimum floor load:

15-1/8" (384 mm)Water depth:

59.8 gal (226.4 L)Water capacity:

Blower: 220-240 V, 3 A, 50/60 Hz

Pump: 220-240 V, 11 A, 50/60 Hz

Heater: 220-240 V, 50/60 Hz, 1500 W

Electrical component

rating:

1-15/16" (49 mm)Minimum flat for door:

1-800-4KOHLER (1-800-456-4537)

Kohler Co. reserves the right to make revisions without notice to product specifications.

For the most current Specification Sheet, go to www.kohler.com.

9-28-2018 08:43

Underscore®Rectangle

5' BubbleMassage™Whirlpool Bath

K-1167-XH2GR
