Kohler Underscore Cube K-1969-VB Guide de l'utilisateur

Features

•Center drain.

•Spacious shape and extra deep bathing well accommodate up

to two bathers.

•Two integral corner seats at 6-3/4" (171 mm) and 11-7/8" (302

mm) from bath floor.

•VibrAcoustic®technology emits sound waves and offers a

surround sound experience.

•Six transducers and a control amplifier with 25’ (7.6 m) of wiring.

•High-resolution color screen in polished chrome.

•Integral lumbar support.

•48" (1219 mm) x 48" (1219 mm) x 34" (864 mm)

Material

•Acrylic

Installation

•Drop-in or under-mount. Codes/Standards

•Syncs with devices enabled with BLUETOOTH®wireless

technology including smart phones, MP3 players, tablets and

laptops located up to 33 feet away.*

ASME A112.19.7/CSA B45.10

CSA B45.5/IAPMO Z124

ASTM E162

Recommended Accessories

1184460 Kit, UI Mounting

ASTM E662

UL 1795

CSA C22.2 No. 218.2

K-578 Cube Undermount Installation Kit Greenguard UL 2818 - Gold

K-8134 Bath cable drain trim CARB P2

K-8150 Cube Cable Drain

K-1177 Vinyl Tiling-in Bead

KOHLER®One-Year Limited Warranty

See website for detailed warranty information.

*The BLUETOOTH®word mark and logos are registered trademarks owned by

Bluetooth SIG, Inc. and any use of such marks by Kohler Co. is under license. Other

trademarks and trade names are those of their respective owners.

Available Color/Finishes

Color tiles intended for reference only.

DescriptionCodeColor

White0

Biscuit96

USA/Canada: 1-800-4KOHLER (1-800-456-4537)

Kohler Co. reserves the right to make revisions without notice to product specifications.

For the most current Specification Sheet, go to www.kohler.com.

12-3-2017 02:33

Underscore®Cube

Drop-In VibrAcoustic®Bath

K-1969-VB

*Recommended User

Notes

Required Electrical Service Measure your actual product for rough-in details.

One circuit required, protected with Class A Ground-Fault

Circuit-Interrupter (GFCI) or Residual Current Device (RCD). Install this product according to the installation

instructions.

120 V, 15 A, 50/60 HzAmplifier:

The hot water supply should be 70% of the

capacity of the bath or greater. Installations will

vary.

Technical Information

All product dimensions are nominal.

Drop-in, Under-mountInstallation: Provide one grounded electrical outlet within 24"

(610 mm) of each component.

CenterDrain location:

39-3/8" x 39-3/8" (1000 mm x 1000 mm)Basin area, bottom: Kit is required for under-mount installations (sold

separately).

44-5/8" x 44-5/8" (1133 mm x 1133 mm)Basin area, top:

115 lbs (52.2 kg)Weight: Control amplifier fits 16" (406 mm) center studs.

25' (7.6 m) cables are included.

99 lbs/ft²(483.4 kg/m²)Minimum floor load:

27-1/2" (699 mm)Water depth:

171 gal (647.3 L)Water capacity:

Drop-in, 47" x 47" (1194 mm x 1194 mm)Cutout:

Amplifier: 120 V, 1.1 A, 50/60 HzElectrical component

rating:

2 at 15 W per channel

2 at 30 W per channel

Amplifier channels:

USA/Canada: 1-800-4KOHLER (1-800-456-4537)

Kohler Co. reserves the right to make revisions without notice to product specifications.

For the most current Specification Sheet, go to www.kohler.com.

12-3-2017 02:33

Underscore®Cube

Drop-In VibrAcoustic®Bath

K-1969-VB
