Kohler C3-430 Instructions de montage

Homeowner’s Guide

C3-430 Toilet Smart Seat



C3-430

K-22445X

English page 2-15



1349981-X5-A 2 Kohler Co.

CAUTIONS AND WARNINGS

Warning

Attention

Please read the CAUTIONS AND WARNINGS carefully and be sure to fol-

low them.

Warning: Mis-operation due to neglecting this sign may lead to serious injury or

death.

Attention: Mis-operation due to neglection this sign may lead to personal injury

or property loss.

¨This product must be grounded safely. Connect only to dedicated 220V~, 50Hz,

10A circuit protected by Ground-Fault Circuit-Interrupters (GFCI's) or Earth-Leak-

age Circuit-Breakers (ELCB's).

¨Risk of electric shock or product damage: Do not immerse the product in water.

Do not use the product that has been dropped in water. Water should not be poured

on the power plug.

¨Risk of product damage: The power supply shall not be connected before the

installation is finished. Otherwise it may lead to product failure.

¨Warning- To reduce the risk of low grade burns, electric shock, fire or injury to

persons.

• Children, elders or those with disabilities from their body, sensitivity or mantal

disabilities should not use or get close to this product unless under close

tutelage. Children are forbidden to use or touch this product. Do not leave

children alone in a room with such product.

• For those children and the elderly who are unable to adjust the temperature,

they should ask for help to adjust seat temp, flush temp and wind temp of

bidet seat to the proper gears.

• Exposed skin should not make contact with the heated seat for too long a

time to prevent low temperature burning.

¨Never operate this appliance if it has a damaged cord or plug, or if it is not

working properly.

¨Keep power line far from heated surface.

¨In case the power line is damaged: to avoid danger, product should be replaced

by the manufacturer or the professionals from its maintenance department or

similar department.

¨Risk of product damage: Do not install the product at a place with excessive hu-

midity, where moisture may condense at the surface of the product. Make sure that

usage environment is always under adequate ventilation to prevent damage to the

electronic components.

Kohler Co. 3 1349981-X5-A

CAUTIONS AND WARNINGS (Cont.)

¨Risk of product damage: Do not apply excessive forceto the nozzle. Otherwise,

the product may be broken.

¨Risk of product damage: Antifreeze measures should be taken to prevent damage

to the piping or inlet hose due to freezing. The product should be stored or used at

room temperature, or water inside the product should be emptied. Please keep the

product at room temperature before re-installation or usage.

¨The thermal protector may get out of order during storage or transportation in a

warm climate which can lead to product failure. Please ensure that the product

cools to room temperature before reinstallation or usage.

¨Do not lean on the cover when using this appliance to prevent the product from

damage.

¨Install this product properly according to the Installation Guide.

¨This product shall be repaired by professionals only. Do not try to repair this product

by yourself.

¨When installing the product in a room, a water inlet angle valve shall be installed in

close proximity. For emergency circumstances, the water inlet valve can be turned

off without using any tools: otherwise unexpected failure may cause the loss to the

customer.

¨Do not drop or insert any substance into the pipeline or the opening.

¨It is required to use the new hose assembly attached with the appliance. Do not re-

use the old one.

¨When the user has cut power supply off, if reactivation of power supply is required,

please wait for 30 seconds before turning on power supply again.

¨Stop using this product if the following conditions are found. Please disconnect

power supply and turn off the inlet angle valve to stop the water supply.

• Water leaks out from the inside of the hose or the product.

• When the product is cracked or damaged.

• Strange sound or odor comes from the product.

• Smoke comes out from the product.

• When the product is abnomally hot.

1349981-X5-A 4 Kohler Co.

Water Supply Pressure Min water pressure 0.07 MPa(dynamic pressure)

Max water pressure 0.74 MPa

Reted voltage 220 V, 50 Hz

Power cord length About 1.5 m

Rated power* 1100 W

Outline Dimension of Product 530 x 430 x 120 mm

Product Weight About 4.5 kg

Inlet water temp 1~35°C

Operation Environment 1~40°C

Cleaning Rear Wash Yes, adjustable dials

Front Wash Yes, adjustable dials

Flow rate

(when pressure is 0.2 MPa)

The max dial of rear wash not lower than

500 ml/min

Spray water temp adjustment OFF, adjust 3 dials (ambient temp, about 31~39°C)

Single spray duration (Max) About 300 seconds

Safety

Devices

Water Overheat

Prevention Thermal fuse

Counter-flow

Prevention Check valve

Comfort Heated

seat

Temp adjustment OFF, adjust 3 dials

Safety device Thermal fuse

Cover Buffering

Seat Buffering

Sanitary Self-Cleaning Yes

Quick-release body Lever activated by release button

Antibacterial Material** Seat, Cover

UV Sterilization*** Yes

Other safety devices Circuit-breakers

Other

function

Keypad and Panel Diagram On the side of the unit

Seating Sensor Hidden in seat

Lighting Yes

Specications

Kohler Co. 5 1349981-X5-A

Thank You for Choosing Kohler Company

Thank you for choosing Kohler. Kohler craftsmanship offers you a rare combination of proven perfor-

mance and graceful sophistication that will satisfy you for years to come. The dependability and beauty

of your Kohler product will surpass your highest expectations. We are very proud of our products here at

Kohler and we know you will be too.

Please take a few minutes to review this manual before you start installation. If you encounter any

installation or performance problems, please don’t hesitate to contact us. Our phone numbers

and website are listed on back cover.

All information in this manual is based upon the latest product information available at the time

of publication. At Kohler, we constantly strive to improve the quality of our products. We reserve

the right to make changes in product characteristics, packaging or availability at any time without

notice.

Thank you for choosing Kohler Company.

Specications (Cont.)

*Power value shall be checked under the following conditions: dynamic pressure 0.2 MPa, inlet

water temp 15° C.

**Antibacterial : Cover and seat contains long term inorganic anti-bacterial material which will

inhibit bacteria growth on the surface, this does not represent mildew or other incidental effects.

The anti-bacterial rate is more than 90% (test per GB21551.1-2008, GB21551.2-2010 antibacte-

rial performance test requirements).

***UV sterilization (refer sterilization by ultraviolet light from a UV lamp): The UV lamp sterilization

the nozzle surface by irradiation during its operating period.The bacteria removal rate is more than

99% (measure after a UV sterilization operation period)

1349981-X5-A 6 Kohler Co.

Use Guide

A - Stop

When WASH fucntion is ON, press button to terminate WASH function.

Cover (anti-bacterial*)

Seat (anti-bacterial*)

Keypad and Panel Diagram

Operation

Kohler Co. 7 1349981-X5-A

B - Front

C - Rear

D - Heating

E - Dial Indication

Low

Small light

High

All light ON

Mid

Small light ON

Mid light ON

When user is seating on, press this button to activate front wash (fe-

male only) and display current wash strength. Continue pressing the

Front button to change the spray's strength when the front wash func-

tion is ON. The strength circulates per "Low, Mid, High, Mid."

Automatically stops after continuos washing for 5 minutes.

When user is seating on, press this button to activate rear wash and

display current spray strength. Continue pressing the Rear button to

change the spray's strength when the rear wash function is ON. The

strength circulates per "Low, Mid, High, Mid."

Automatically stops after continuos washing for 5 minutes. This unit is

equipped with a wide oscillate clean function. If you would like to use

or close the wide oscillate function, please hold Front button and Stop

button for 2 seconds.

When the wash function is activated, press the Heating button to set

the spray water temperature per "OFF, Low, Mid, High, Mid" circulation

with the coeeesponding water temp indicator turning on. If this function

is turned off, the indicators will not light up.

When the wash function is not activated, press the Heating button to

set the seat temperature per "OFF, Low, Mid, High, Mid" circulation

with the corresponding seat temp indicator turning on. If this function is

turned off, the indicators will not light up.

1349981-X5-A 8 Kohler Co.

¨Lighting (ON/OFF)

Hold Front button for 2 seconds to activate or deactivate lighting function.

OFF: long beep, light turns off.

ON: short beep, light ia affected by light (bright when external light is weak, other-

wise turned off)

¨Energy save (switch among 3 modes)

Hold Heating button to cyclically enter the 3 modes.

No Energy Save mode: Long beep, light flashes once. Then exit the Energy Save

mode.

General Energy Save mode: One beep, light flashes slowly. Then enter the Gen-

eral Energy Save mode.

Deep Energy Save mode: One beep, light flashes twice. Seat temp and water

temp are deactivated. Then enter the Deep Energy Save mode.

¨Standby mode

Hold the Stop button for 2 seconds to enter standby mode and stop seat heat-

ing function, so as to minimize energy consumption.

Press any button on the side panel or sit on the seat to exit standby mode auto-

matically with all functions recovered.

¨Manual wand cleaning

Hold the Rear button for 2 seconds to clean the wand manually.

¨Ensure if water inlet valve is OPEN

¨Connec water inlet hose according to installation Guide. Open water stop valve, and

plug power cord.

¨Plug power cord into socket. Bidet seat generates one short beep, wand extends

and retracts once, and the indicator on the side panel blinks until initialization com-

pletes.

¨During initialization, it is normal to hear motor rotating and water flow.

¨Test according to "USE GUIDE" section

¨Factory setting for initial use.

Button-Holding Function Introduction

Preparations Before inital Operations

Front wash: Water temp: Mid

• Water flow: Mid Seat temp: Mid

• Spray position: Mid Lighting: ON

Energy save: OFF

Rear wash:

• Water ow: Mid

• Spray position: Mid

Kohler Co. 9 1349981-X5-A

Care and Cleaning

For best result, keep the following in mind when caring for your Kohler

product:

IMPORTANT! Do not immerse product in water

¨Test First - Always test your cleaning solution on an

inconspiciuous area before applying it on the entire

surface.

¨Do Not Let Cleaners Soak -

Do not allow cleaners to

sit or soak on the product.

¨Avoid Abrasive Materials - Use a soft, dampened

sponge or cloth. Never use an abrasive material such

as a brush or scouring pad to clean surfaces.

¨Wipe Clean - Wipe surfaces clean with a damp cloth

immediately after applying cleaner. Wipe away and

dry any overspray that lands on nearby surfaces.

Cleaning your seat

¨Avoid abrasive cleaners, detergents disinfectants or

cleaning

products in aerosol cans.

Care tip: Clean the seat with a mixture of dish washing

liquid and water, or any of the products listed toilet seats,

using a damp soft sponge or cloth. Dry with a soft towel

and let the seat air dry.

¨Do not allow abrasive chemicals and cosmetics (such as

ngernail polish and aftershave) to come in contact with

the toilet seat, as they can damage the nish.

NOTICE: Failure to comply with these cleaning instructions may void Kohler’s

warranty obligations.

NOTE: Success with the cleaners and procedures is dependent upon such

factors as the hardness and temperature of the water, using exact quantities

of ingredients, changes in cleaning formulas, and the condition of the product

being cleaned. Since there are variations within these factors, Kohler cannot

guarantee effectiveness of the formulas mentioned.

1349981-X5-A 10 Kohler Co.

Clean the Nozzle

1. Press and hold the "Rear" button for over 2 seconds.

2. The bidet wand will extend out.

3. Clean the bidet wand with a soft-bristled brush.

4. After having the bidet wand cleaned, press "Stop" button, the bidet wand will retract.

Autres manuels pour C3-430

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Kohler Appareil de salle de bains

Kohler

Kohler K-5250 Manuel utilisateur

Kohler

Kohler K-8360-BN Instructions de montage

Kohler

Kohler Mariposa K-1239-HB Guide de démarrage rapide

Kohler

Kohler K-4615 Manuel utilisateur

Kohler

Kohler K-9531 Manuel utilisateur

Kohler

Kohler C3-510 Manuel utilisateur

Kohler

Kohler K-9923 Manuel utilisateur

Kohler

Kohler K-8247 Instructions de montage

Kohler

Kohler STERLING SP5400 Series Manuel d'utilisation

Kohler

Kohler Mira Sport Thermostatic 9.0 Manuel utilisateur

Kohler

Kohler Waterlite tower 3866 Manuel utilisateur

Kohler

Kohler Mira Store Manuel utilisateur

Kohler

Kohler K-R37028 Instructions de montage

Kohler

Kohler K-8002 Instructions de montage

Kohler

Kohler K4915 Manuel d'utilisation

Kohler

Kohler HARKEN K-78197T Manuel utilisateur

Kohler

Kohler Mira Sport Multi-fit J03E Manuel utilisateur

Kohler

Kohler Vanity K-2604 Instructions de montage

Kohler

Kohler Englefield K-5627X Instructions de montage

Kohler

Kohler KUMIN 18656IN-ND Series Manuel utilisateur

Kohler

Kohler K-12183 Manuel utilisateur

Kohler

Kohler ODEON K-8827T Manuel utilisateur

Kohler

Kohler K-8501 Instructions de montage

Kohler

Kohler K-4636 Manuel utilisateur

Manuels Appareil de salle de bains populaires d'autres marques

DURAVIT

DURAVIT C.1 C15240 0090 Manuel

Heatstore

Heatstore HSTRL500WTN Manuel utilisateur

Sunshower

Sunshower PURE SOLO Manuel utilisateur

Delabie

Delabie Delabie Sporting 714700 Manuel utilisateur

ESS

ESS Container TCL-11 Manuel utilisateur

Mustee

Mustee 22C Manuel utilisateur

VITRA

VITRA V-Flow Manuel utilisateur

baliv

baliv DUK-80.30 T Manuel utilisateur

Malmet

Malmet B105BT Manuel utilisateur

bathstore

bathstore Transition H1690MM Mode d’emploi

BELLOSTA

BELLOSTA Edward 0800/M Manuel utilisateur

baliv

baliv DU-5160 Manuel utilisateur

Franke

Franke PRTR0006 Manuel utilisateur

Gessi

Gessi RILIEVO 59011 Manuel utilisateur

noken

noken VITAE 100188525-N299998810 Manuel utilisateur

Allen + Roth

Allen + Roth 1142VA-30-201 Manuel utilisateur

Britex

Britex HBDA Manuel utilisateur

GRE

GRE DSALC32W Manuel utilisateur
