Klipsch Reference RC-64 Manuel utilisateur

RC-64

SPECIFICATIONS

FREQUENCY RESPONSE 62Hz-21kHz ± 3dB

POWER HANDLING 200W RMS / 800W Peak

SENSITIVITY 99dB @ 2.83V / 1m

NOMINAL IMPEDANCE 8 ohms compatible

HIGH FREQUENCY DRIVERS 1.25" (3.2cm) Titanium diaphragm

compression driver mated to 90˚x 60˚

square Tractrix®Horn

HIGH FREQUENCY CROSSOVER 1150Hz, 1800Hz

LOW FREQUENCY DRIVERS Quad 6.5" (16.5cm) High-output

Cerametallic™cone woofers

ENCLOSURE TYPE Sealed

HEIGHT 8" (20.3cm)

WIDTH 33" (83.8cm)

DEPTH 13.5" (34.3cm)

MOUNTING Uptilt and Downtilt feet

WEIGHT 61 lbs (27.7kg)

FINISH Cherry or Black Ash wood veneer

Quad 6.5" Center Channel Loudspeaker

Designed to be one of the most unique and

powerful center channels on the market, the

RC-64 is certainly a force to be reckoned with.

Exclusive Tractrix®Horns have always been the

key component of this critically acclaimed series.

In the RC-64, this technology has been refined to

include improved throat geometry for a more

genuine, lifelike sound. Behind the horn lies a

professional-grade 1.25-inch titanium diaphragm

compression driver to provide a unique

combination of precision, clarity and effortless

power.

The RC-64 employs four 6.5-inch high-output

woofers for a solid bass foundation. These

Cerametallic™woofers with inverted copper dust

caps exhibit a very high stiffness-to-mass ratio

and superb damping characteristics.

Klipsch Tapered Array™technology operates all

of the woofers at the lowest frequencies –

maintaining the high output capability necessary

for good center channel performance – but only

two operate all the way through the midrange to

where the tweeter takes over. This eliminates

acoustic interference between the woofer

outputs, a flaw in conventional speaker designs

that can severely impair sound quality at the sides

of the listening area.

The RC-64’s sealed cabinet offers improved

internal cross-bracing to minimize panel vibrations

that can color sound. Increased baffle ribbing

around the horn mouth dramatically improves

acoustics across the sonic range. For signal purity

and perfect driver integration, the crossover on

the RC-64 features the finest components and

Klipsch custom internal wiring. Bi-wire inputs with

premium binding posts ensure superior

connectivity.

Available in either a cherry or black real wood

veneer finish, the fully video-shielded RC-64

comes with a knife-edge back and low-diffraction,

magnetically attached grille to further accentuate

the elegance of this speaker.

www.klipsch.com

1-800-KLIPSCH

• Ultra-high-performance center channel speaker

• Tapered Array™design for maximum dialogue clarity

• Magnetically shielded drivers to prevent video interference

• Furniture-grade wood veneer finish
