Klipsch reference premiere Manuel utilisateur
1
KLIPSCH REFERENCE PREMIERE HD WIRELESS | EXTENDED USER GUIDE V07 | 02.03.2016
EXTENDED USER GUIDE
2
KLIPSCH REFERENCE PREMIERE HD WIRELESS | EXTENDED USER GUIDE V07 | 02.03.2016
FUTURE PROOF YOUR SYSTEM
FREE FIRMWARE UPGRADES FOR LIFE
VISIT KLIPSCH.COM/RP-HD-WIRELESS TO REGISTER
YOUR HD CONTROL CENTER AND GET ACCESS TO NEW FEATURES
AND FIRMWARE UPDATES AS THEY BECOME AVAILABLE.
3
KLIPSCH REFERENCE PREMIERE HD WIRELESS | EXTENDED USER GUIDE V07 | 02.03.2016
HD CONTROL CENTER (RP-HUB1)
ON/OFF
MUTE
SOURCE
VOLUME UP
VOLUME DOWN
HDMI 1 HDMI 2 HDMI 3 HDMI 4 OPTICAL COAX TV ANALOG VOLUME
HDMI Input 1
LED
HDMI Input 2
LED
HDMI Input 3
LED
HDMI Input 4
LED
Coaxial Input
LED
TV Input
LED
Volume LEDs DTS Surround
LED
Bluetooth
®
Input LED
Optical Input
LED
RCA Analog
Input LED
Dolby Digital
LED
4
KLIPSCH REFERENCE PREMIERE HD WIRELESS | EXTENDED USER GUIDE V07 | 02.03.2016
1
2
3
45
6 7 8 9 10
11
Service Port 3.5mm IR Input Coaxial Input Optical Input RCA Analog Inputs
HDMI Input 1
(HDMI 2.0 and HDCP 2.2 Compliant)
HDMI Input 2 HDMI Input 3 HDMI Input 4 HDMI OUT / TV Power Input DC 5V
1 53
7 9
2
6
4
8 10 11
HD CONTROL CENTER (RP-HUB1)
FIRMWARE UPDATES
• Firmware updates need to be downloaded from KLIPSCH.COM to a USB storage device and then inserted into the
HD Control Center’s SERVICE PORT.
• Upon plugging in a USB storage device which contains a new firmware file, a confirmation will pop up to remind you none of
your settings will be affected.
• Select YES to begin the update process. Wait until the on-screen display comes back and the HD Control Center’s Volume
LEDs return to normal operation.
NOTE: This update also applies if old speaker firmware is detected upon startup when new versions are available.
5
KLIPSCH REFERENCE PREMIERE HD WIRELESS | EXTENDED USER GUIDE V07 | 02.03.2016
REMOTE
HDMI 1
HDMI 2 COAX
ANALOG
TV
OK
HDMI 3
MENU
EXIT
SURAUDIO
HDMI 4
OPTICAL
Mute
On/Off
HDMI 1 Source Select
HDMI 2 Source Select
HDMI 3 Source Select
HDMI 4 Source Select
Directional Pad
Return
Audio Enhancement
Bluetooth
® Source Select
Optical Source Select
Coaxial Source Select
RCA Analog Source Select
TV Source Select
Volume
Menu Select
Exit
Surround Mode
6
KLIPSCH REFERENCE PREMIERE HD WIRELESS | EXTENDED USER GUIDE V07 | 02.03.2016
QUICK SETUP
1
REPEAT FOR EVERY SPEAKER
REPEAT FOR EVERY SPEAKER
LEFT
SIDE
LEFT
FRONT
CENTER
TV
LEFT
REAR
RIGHT
SIDE
RIGHT
FRONT
RIGHT
REAR
PLUG THIS SPEAKER
INTO AN OUTLET 21 PRESS BUTTON TO
SELECT THE POSITION
OF THIS SPEAKER
3PLUG HD CONTROL
CENTER INTO TV AND
FOLLOW THE ON-SCREEN
INSTRUCTIONS
2
REPEAT FOR EVERY SPEAKER
Klipsch Reference Premiere HD Wireless Subwoofers and some other WiSA
certified Klipsch speakers may not have a Smart Speaker Selector.
*
*
LED SOLID = CONNECTED
LED FLASHING = NOT CONNECTED
LED OFF = HD CONTROL CENTER OFF
3
FOLLOW ON-SCREEN INSTRUCTIONS
5
4
7
KLIPSCH REFERENCE PREMIERE HD WIRELESS | EXTENDED USER GUIDE V07 | 02.03.2016
ON-SCREEN SETUP GUIDE
LANGUAGE SELECTION
• Select your desired language.
NOTE: You will have the ability to change your language preference at any time from the menu system.
ADD SPEAKERS
• Plug in your HD Wireless speakers if you haven’t already. The LEDs on the front of the speakers will blink when they are
ready to be discovered.
• Your HD Control Center will then begin searching for your speakers that will comprise your system. This process should take
about 1 - 2 minutes. At the end, a notification will appear indicating the number of speakers that were found. If no speakers
were discovered, please try the setup again.
CONFIRM SPEAKER LOCATIONS
• Once your speakers have been discovered, their channel assignments within the system must be confirmed. One by one,
each speaker will play a test tone and flash its front-facing LED to denote which is currently active. You will be asked
where the tone is coming from and select from the list of speakers on screen. The default selection should be the one
corresponding to the one you selected on the Smart Speaker Selector on the speaker’s rear panel.
• If you selected a different location than the default, your HD Control Center will reassign the speaker location and update
the speaker.
NOTE: If conflicts occur, you will be prompted with a warning that multiple speakers are assigned to the same location.
Choose whether to check the speaker locations again or continue with the redundancy.
SETUP COMPLETE
• Your basic setup process is complete. You are now ready to enjoy your system.
8
KLIPSCH REFERENCE PREMIERE HD WIRELESS | EXTENDED USER GUIDE V07 | 02.03.2016
ADJUST SOUND STATUS ADVANCED SETUP GUIDE
MAIN MENU
ADJUST SPEAKER LEVELS
• Customize the relative level of each individual speaker.
• Press UP OR DOWN on your remote to change the SELECTED SPEAKER.
• Press RIGHT OR LEFT to increase or decrease the selected speaker’s LEVEL.
• When you’re happy with your adjustments, select DONE at the bottom of the menu.
NOTE: If multiple speakers are assigned to a given channel, they should have independent entries in the speaker list. You
should be alerted, however, that movie performance will be weak if there is such an overlap in assignment.
ADJUST SPEAKER DISTANCES
• Pinpoint the distance of each speaker in your system from your primary listening position.
• Press UP OR DOWN on your remote to change the SELECTED SPEAKER.
• Press RIGHT OR LEFT to increase or decrease the selected speaker’s DISTANCE.
• When you’re happy with your adjustments, select DONE at the bottom of the menu.
NOTE: You can toggle between feet and meters as units of measure for your adjustments.
SUBWOOFER POSITION
• This applies an EQ based on the placement of your subwoofer in order to optmize performance. Choose between these three options:
WALL
CORNER
OTHER
9
KLIPSCH REFERENCE PREMIERE HD WIRELESS | EXTENDED USER GUIDE V07 | 02.03.2016
ADJUST SOUND STATUS ADVANCED SETUP GUIDE
MAIN MENU
LOW-VOLUME BASS BOOST
• Low-Volume Bass Boost is a custom EQ based on psychoacoustic principles. This dynamic feature aims to add richness when
sound levels are low.
AUDIO ENHANCEMENT
• Audio Enhancement offers selected equalization settings to improve your listening experience.
Choose between these three options:
NATURAL
No enhancements applied. Default option upon startup.
DIALOGUE
Increases dialogue EQ for enhanced vocal clarity without increasing ambient sound.
NIGHT MODE
Adjusts dynamic range for quieter listening environments.
10
KLIPSCH REFERENCE PREMIERE HD WIRELESS | EXTENDED USER GUIDE V07 | 02.03.2016
ADJUST SOUND STATUS ADVANCED SETUP GUIDE
MAIN MENU
SURROUND MODES
• The surround modes can be used to adjust the sound field per your preferences. In almost all situations, DIRECT is the
preferred surround mode. This setting will play back the audio content in its native format and number of channels. All
surround modes will automatically configure themselves based on the number of speakers in your system. No additional
user setup is necessary to use these modes.
DIRECT
All content is decoded and played back in its native format. This is the best setting for most situations.
STEREO
Takes any input material and plays it through left and right speakers only. If the source is not stereo, a stereo mix will
be derived from the input.
ALL-CHANNEL STEREO
Plays a stereo signal through all speakers in the system. This mode will downmix any surround information to stereo
before routing to the speakers.
DOLBY PLIIX MOVIE
Dolby Pro-Logic IIx processing is applied to the incoming source with the decoder configured for movies.
DOLBY PLIIX MUSIC
Dolby Pro-Logic IIx processing is applied to the incoming source with the decoder configured for music.
DOLBY PLIIX GAME
Dolby Pro-Logic IIx processing is applied to the incoming source with the decoder configured for gaming content.
DOLBY EX
Dolby EX processing is applied to the incoming source to create virtual rear channel information. Only valid for
systems with rear speakers present.
DTS NEO:6 CINEMA
DTS NEO:6 processing is applied to the incoming source with the decoder configured for movies.
DTS NEO:6 MUSIC
DTS NEO:6 processing is applied to the incoming source with the decoder configured for music.
NOTE: The Dolby Pro-Logic IIx and DTS Neo:6 modes can also be used to create channels for speakers that may not be
used by the native audio format.
LIP SYNC DELAY
•
Your system is able to compensate for synchonization issues between audio and video by allowing for an adjustable audio delay.
• You can adjust this delay by pressing the LEFT AND RIGHT buttons on your remote.
