When designing the fully active XF-48

ﬂoorstander, our engineers refused to

hold back. The speaker intelligently

employs dual high-output ﬁberglass cone

woofers with powerful neodymium motor

structures and two passive radiators to

unleash the kind of bass you hear and feel.

But what makes this ﬂat-panel speaker

remarkably superior is an all-new, patent-

pending Tractrix®Horn-loaded tweeter

with XT™ technology. For over 60 years,

horns have been the driving force behind

our stunningly precise sound, and this

latest design moves us farther ahead by

allowing the slender XF-48 to deliver an

extremely smooth response with constant

directivity.

You’ll discover the XF-48’s performance

has but one rival: style. Its beautifully

crafted aluminum extruded enclosure,

featuring an anodized black-grain ﬁnish

and high-gloss black accents, is the direct

result of our engineers’ quest for perfect

balance.

The entire ICON Series is performance

art at its best, capturing the spirit of our

past and pushing us into the future. It is a

brilliant representation of how our prod-

ucts have evolved and remained desirable

over time. After just one listen, the ICON

sound will be imprinted in your conscious-

ness forever.

www.klipsch.com

1-800-KLIPSCH

Floorstanding Loudspeaker

frequency response 40Hz-23kHz +/-3dB

low frequency extension 33Hz

ampliﬁer power 100W continuous system power /

360W peak

high frequency drivers 0.75” (1.9cm) Titanium diaphragm

compression driver mated to 80° x 80°

round XT Tractrix® Horn

high freq crossover 2550Hz

low frequency drivers Dual 5.25” (13.3cm) high-output,

ﬁberglass cone woofers with Dual 5.25” x

9” (13.3cm x 22.9cm) passive radiators

ampliﬁer HF: Class A/B, LF: Class D

enclosure material Aluminum

enclosure type Bass-reﬂex via dual front-ﬁring

passive radiators

inputs Line-level RCA jack, High-level speaker

binding posts

height 48.8” (123.8cm)

width 7” (17.8cm)

depth 7.9” (20cm) not including 12” (30.5cm)

diameter base

weight 39lbs (17.7kg)

features Input Sensitivity Control, Auto Power

ﬁnishes Black anodized w/ high-gloss

Black accents

voltage 110/120 VAC 60Hz

export voltage 220 VAC 50/60Hz

built from 2007

SpecificationS

• Fully active design with built-in ampliﬁcation

• Patent-pending XT™ Tractrix®Horn technology

• Dual high-output woofers

• Dual passive radiators

XF-48
