Klipsch Klipschorn Manuel utilisateur

Klipschorn

SPECIFICATIONS

FREQUENCY RESPONSE 33Hz-17kHz ± 4dB

SENSITIVITY 105dB @ 1 Watt/1 meter

POWER HANDLING 100 Watts max continuous (400W peak)

MAXIMUM SPL 121dB

NOMINAL IMPEDANCE 8 ohms

ENCLOSURE TYPE Fully horn-loaded

CROSSOVER FREQUENCY HF: 4500Hz

MF: 450Hz

TWEETER K-77-F 1" (2.54cm) Phenolic diaphragm

compression driver

HIGH FREQUENCY HORN Exponential

MIDRANGE K-55-X 2" (5.08cm) Phenolic diaphragm

compression driver

MID-FREQUENCY HORN Exponential

WOOFER K-33-E 15" (38.1cm) Fiber-composite cone

with a trihedral exponential folded horn

DIMENSIONS 50.75" (128.9cm) H x 31.25" (79.38cm) W

x 28.25" (71.75cm) D

WEIGHT 175 lbs. (79.5kg)

ENCLOSURE MATERIAL Birch Plywood and MDF

FINISHES Walnut Lacquer, Cherry Lacquer, Black Lacquer

Three-Way Fully Horn-Loaded Loudspeaker

Audio pioneer and company founder Paul W.

Klipsch launched the Klipschorn loudspeaker

in 1946 to enable people, for the first time

ever, to experience the power, detail and

emotion of a live performance at home.

Commonly called a corner-horn speaker, the

remarkably uncommon Klipschorn includes a

highly efficient horn loaded tweeter and

midrange compression driver. Its patented

folded-horn 15" woofer delivers powerful low

frequencies.

Considered a watershed industry event, the

introduction of the Klipschorn set the

standard for high sensitivity, wide dynamic

range, low distortion and smooth frequency

response. These principles, which drive the

creation of every single Klipsch loudspeaker,

are what make the Klipschorn as sought after

today as it was six decades ago.

As the only speaker in the world to be in

continuous production for 60 years, the

Klipschorn has remained relatively unchanged

since its inception. In 2005, the company

made some minor cosmetic and functional

revisions to this legendary speaker, including

the elimination of the inset collar, or spacer,

between the upper and lower cabinets for a

cleaner aesthetic appearance. A horizontal

wall seal was added to improve the low

frequency horn’s response accuracy.

Available in a cherry, walnut or black ash

wood veneer finish, the Klipschorn reflects a

level of high-quality workmanship that will

never go out of style.

www.klipsch.com

1-800-KLIPSCH
