KitchenAid 5K45SSN Manuel utilisateur

Stand Mixer

5K45SSN,

5KSM150PSN, 5KSM195PSN

W11520569A.indb 1W11520569A.indb 1 6/17/2022 3:25:37 PM6/17/2022 3:25:37 PM

PARTS AND FEATURES

*Included with select models only. Also available as optional accessory.

**The Bowl design and material depend on the Stand Mixer model.

611

1Speed Control Lever

2Motor Head

3Attachment Hub

4Attachment Knob

5Motor Head Locking Lever

(not shown)

6Beater Shaft

7Beater Height Adjustment Screw

(not shown)

8Bowl Clamping Plate

9Bowl**

10 Pouring Shield*

11 2.8 L Stainless Steel Bowl*

12 Dough Hook

13 Wire Whip

14 Flex Edge Beater*

15 Flat Beater

W11520569A.indb 2W11520569A.indb 2 6/17/2022 3:25:45 PM6/17/2022 3:25:45 PM

ENGLISH

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be

followed, including the following:

1. Read all instructions. Misuse of appliance may result in personal injury.

2. To protect against risk of electrical shock, do not put Stand Mixer in water or

other liquid.

3. This appliance is not intended for use by persons (including children) with

reduced physical, sensory, or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

4. Turn the appliance off (0), then unplug from the outlet when not in use, before

assembling or disassembling parts and before cleaning. To unplug, grasp the

plug and pull from the outlet. Never pull from the power cord.

5. Avoid contacting moving parts. Keep hands, hair, clothing, as well as spatulas

and other utensils away from beater during operation to reduce the risk of injury

to persons and/or damage to the Stand Mixer.

6. Do not operate any appliance with a damaged cord or plug or after the appliance

malfunctions, or is dropped or damaged in any manner. Return appliance to

the nearest Authorised Service Facility for examination, repair, or electrical or

mechanical adjustment.

7. The use of attachments/accessories not recommended or sold by KitchenAid

may cause fire, electrical shock or injury.

8. Do not use the appliance outdoors.

9. Do not let the cord hang over edge of table or counter.

10. Remove Flat Beater, Wire Whip, or Dough Hook from Stand Mixer before

washing.

11. Children should be supervised to ensure that they do not play with the appliance.

12. If the supply cord is damaged, it must be replaced by the manufacturer, its

service agent, or similarly qualified persons in order to avoid a hazard.

PRODUCT SAFETY

W11520569A.indb 3W11520569A.indb 3 6/17/2022 3:25:47 PM6/17/2022 3:25:47 PM

13. Never leave the appliance unattended while it is in operation.

14. To avoid product damage, do not use the Stand Mixer Bowls in areas of high

heat such as an oven, microwave, or on a stovetop.

15. Refer to the “Care and Cleaning” section for instructions on cleaning the

surfaces in contact with food.

16. Allow the appliance to cool completely before putting on or taking off parts, and

before cleaning the appliance.

17. This appliance is intended to be used in household and similar applications such

as:

- staff kitchen areas in shops, offices, and other working environments;

- farmhouses;

- by clients in hotels, motels and other residential type environments;

- bed and breakfast type environments.

SAVE THESE INSTRUCTIONS

ELECTRICAL REQUIREMENTS

Electrical Shock Hazard

Plug into an earthed outlet.

Do not remove earth prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these

instructions can result in

death, fire, or electrical shock.

Wattage:

300 W max.

For 5KSM125 - 5KSM200 Series

275 W max.

For 5K45, 5KSM45 - 5KSM100 Series

Voltage: 220-240 V

Frequency: 50-60 Hz

NOTE: If the plug does not fit in the

outlet, contact a qualified electrician.

Do not modify the plug in any way.

Do not use an adapter.

Do not use an extension cord. If the power

supply cord is too short, have a qualified

electrician or service technician install an

outlet near the appliance.

PRODUCT SAFETY

W11520569A.indb 4W11520569A.indb 4 6/17/2022 3:25:49 PM6/17/2022 3:25:49 PM

ENGLISH

NOTE: The Speed Control Lever can be set between the speeds listed in the above

chart to obtain speeds 3, 5, 7, and 9 if a finer adjustment is required. Do not exceed

Speed 2 when preparing yeast doughs as this may cause damage to the Stand Mixer.

SPEED CONTROL GUIDE

SPEED ACTION ATTACHMENT DESCRIPTION

1Stir Flat Beater

Flex Edge Beater*

For slow stirring, combining, mashing,

starting all mixing procedures. Use to add

ﬂour and dry ingredients to batter, and to

add liquids to dry ingredients. Do not use

Speed 1 to mix or knead yeast doughs.

2Slow

Mixing

Flat Beater

Flex Edge Beater*

Dough Hook

For slow mixing, mashing, faster stirring.

Use to mix and knead yeast doughs,

heavy batters and candies, start mashing

potatoes or other vegetables, cut

shortening into ﬂour, and mix thin or

splashy batters.

4Mixing,

Beating Flat Beater

Flex Edge Beater*

Wire Whip

For mixing semi-heavy batters, such

as cookies. Use to combine sugar and

shortening and to add sugar to egg

whites for meringues. Medium speed for

cake mixes.

6Beating,

Creaming

For medium-fast beating (creaming) or

whipping. Use to ﬁnish mixing cake,

doughnut, and other batters. High speed

for cake mixes.

Fast

Beating,

Whipping Wire Whip

For whipping cream, egg whites, and

boiled frostings.

10 Fast

Whipping

For whipping small amounts of cream,

egg whites, or for ﬁnal whipping of

mashed potatoes.

PRODUCT USAGE

ACCESSORY GUIDE

ACCESSORY USE TO MIX DESCRIPTION

Flat Beater

Flex Edge

Beater*

Normal to heavy

mixtures:

Cakes, creamed frostings, candies, cookies,

pie pastry, biscuits, meat loaf, mashed

potatoes.

Wire Whip Mixtures that need air

incorporated:

Eggs, egg whites, heavy cream,

boiled frostings, sponge cakes, mayonnaise,

some candies.

Dough Hook Mixing and kneading

yeast doughs: Breads, rolls, pizza dough, coffee cakes, buns.

*Included with select models only. Also available as optional accessory.

W11520569A.indb 5W11520569A.indb 5 6/17/2022 3:25:50 PM6/17/2022 3:25:50 PM

ATTACHING/REMOVING THE BOWL

PRODUCT USAGE

LIFTING/LOWERING THE MOTOR HEAD

NOTE: Motor Head should always be in lock position when using the Stand Mixer.

To attach Bowl: Turn speed control to

“0” (OFF). Unplug Stand Mixer.

To lift Motor Head: Push the locking

lever to the UNLOCK position and lift

the head. Once lifted, the lever will

automatically go back in LOCK position

to keep the head lifted.

Place Bowl on Bowl Clamping Plate. Turn

Bowl gently in clockwise direction.

Unlock and lift the Motor Head. Then,

lock*the head to keep it lifted.

To put down Motor Head: Push the

locking lever to UNLOCK and gently

bring the head down. The locking lever

will automatically go back in LOCK

position when the head is down. Before

mixing, test lock by attempting to raise

Motor Head.

To remove Bowl: Repeat steps 1 and 2.

Turn Bowl gently counterclockwise.

*Locking option is available on select models.

W11520569A.indb 6W11520569A.indb 6 6/17/2022 3:25:54 PM6/17/2022 3:25:54 PM

ENGLISH

PRODUCT USAGE

*Included with select models only. Also available as optional accessory.

ATTACHING/REMOVING THE FLAT BEATER, FLEX EDGE BEATER*,

WIRE WHIP, OR DOUGH HOOK

To attach accessory: Turn speed control

to “0” (OFF). Unplug Stand Mixer.

To remove accessory: Repeat steps 1

and 2. Press accessory upward as far as

possible and turn to the left. Then pull

accessory from the Beater Shaft.

Unlock and lift the Motor Head. Then,

lock** the head to keep it lifted.

Slip accessory onto Beater Shaft and

press upward as far as possible. Then,

turn accessory to the right, hooking

accessory over the pin on the shaft.

**Locking option is available on select models.

W11520569A.indb 7W11520569A.indb 7 6/17/2022 3:25:59 PM6/17/2022 3:25:59 PM

PRODUCT USAGE

PLACING/REMOVING THE POURING SHIELD*

*Included with select models only. Also available as an optional accessory.

BEATER TO BOWL CLEARANCE

Your Stand Mixer is adjusted at the factory so the Flat Beater just clears the bottom of

the Bowl. If, for any reason, the Flat Beater hits the bottom of the Bowl or is too far away

from the Bowl, you can correct clearance easily.

NOTE: When properly adjusted, the Flat Beater will not strike on the bottom or side of

the Bowl. If the Flat Beater or the Wire Whip is so close that it strikes the bottom of the

Bowl, coating may wear off the beater or wires on whip may wear.

Turn speed control to “0” (OFF). Unplug

Stand Mixer.

To place Pouring Shield*: Turn speed

control to “0” (OFF). Unplug Stand Mixer.

Attach your chosen accessory. See the

“Attaching/Removing the Flat Beater,

Wire Whip, or Dough Hook” section.

Lift Motor Head. Turn screw slightly

counterclockwise (left) to raise Flat

Beater or clockwise (right) to lower Flat

Beater. Make adjustment with Flat Beater,

so it just clears surface of Bowl. If you

overadjust the screw, the Bowl lock lever

may not lock into place.

From the front of the Stand Mixer, slide

the Pouring Shield* over the Bowl until

the shield is centred. The bottom rim of

the shield should fit within the Bowl.

W11520569A.indb 8W11520569A.indb 8 6/17/2022 3:26:02 PM6/17/2022 3:26:02 PM

ENGLISH

PRODUCT USAGE

USING THE POURING SHIELD*

Use the Pouring Shield* to avoid having ingredients splashing out of the Bowl when

mixing, as well as to easily pour ingredients in the Bowl while mixing.

*Included with select models only. Also available as an optional accessory.

To remove Pouring Shield*: Turn speed

control to “0” (OFF). Unplug Stand Mixer.

Lift the front of the Pouring Shield* clear

of the Bowl rim and pull forward. Remove

attachment and Bowl.

For best results, rotate the shield so the

Motor Head covers the U-shaped gap in

the shield. The pouring chute will be just

to the right of the Attachment Hub asyou

face the Stand Mixer.

Pour the ingredients into the Bowl

through the pouring chute.

W11520569A.indb 9W11520569A.indb 9 6/17/2022 3:26:04 PM6/17/2022 3:26:04 PM

PRODUCT USAGE

OPTIONAL ATTACHMENTS

KitchenAid offers a wide range of optional attachments such as food grinders or

pasta makers. They may be attached to the Stand Mixer attachment power shaft,

as shown here.

OPERATING THE SPEED CONTROL

NOTE: The Stand Mixer may warm up during use. Under heavy loads with extended

mixing time, the top of the unit may become hot. This is normal.

Plug Stand Mixer into proper electrical

outlet. Always set Speed Control Lever

on lowest speed to start, then gradually

increase speed to avoid splashing

ingredients. See “Speed Control Guide”

chart.

To attach: Turn speed control to

“0” (OFF). Unplug Stand Mixer.

Do not scrape Bowl while Stand Mixer

is operating. The Bowl and beater are

designed to provide thorough mixing

without frequent scraping. Scraping

the Bowl once or twice during mixing is

usually sufficient.

Loosen Attachment Knob by turning it

counterclockwise. Remove Attachment

Hub cover.

W11520569A.indb 10W11520569A.indb 10 6/17/2022 3:26:08 PM6/17/2022 3:26:08 PM

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels KitchenAid Mixer

KitchenAid

KitchenAid 5K45SS Manuel utilisateur

KitchenAid

KitchenAid KP26M1XPM - Mixer 6QT, Pearl Metallic Manuel utilisateur

KitchenAid

KitchenAid 5KSM3311X Manuel utilisateur

KitchenAid

KitchenAid K5-A Manuel utilisateur

KitchenAid

KitchenAid 5KSM7591X Manuel utilisateur

KitchenAid

KitchenAid KSM15 Series Manuel utilisateur

KitchenAid

KitchenAid 3C Manuel utilisateur

KitchenAid

KitchenAid KV25G0XAQ Manuel utilisateur

KitchenAid

KitchenAid K45 Manuel utilisateur

KitchenAid

KitchenAid KSM500PSER0 Manuel utilisateur

KitchenAid

KitchenAid KSM55 Manuel utilisateur

KitchenAid

KitchenAid 5KSM175PS Manuel utilisateur

KitchenAid

KitchenAid K5SSWH - Heavy Duty Series Stand Mixer Guide rapide

KitchenAid

KitchenAid 5KPM5EER4 Manuel utilisateur

KitchenAid

KitchenAid KP26M1X - Professional 600 Series Stand Mixer 575... Manuel utilisateur

KitchenAid

KitchenAid KHM926WH Manuel utilisateur

KitchenAid

KitchenAid KHM720OB Manuel utilisateur

KitchenAid

KitchenAid 3KSMC895 Manuel utilisateur

KitchenAid

KitchenAid 4KSMC50S Guide rapide

KitchenAid

KitchenAid KSM150PS - Artisan Series Mixer Manuel utilisateur

KitchenAid

KitchenAid 5KSM7586P Manuel utilisateur

KitchenAid

KitchenAid K45 WH Manuel utilisateur

KitchenAid

KitchenAid KSM150PSAC - Artisan Series Mixer Manuel utilisateur

KitchenAid

KitchenAid KSM158GBCA - 90th Anniversary Limited-Edition Stand... Manuel utilisateur

Manuels Mixer populaires d'autres marques

Bosch

Bosch GRW 9 Manuel utilisateur

MULTIQUIP

MULTIQUIP Whiteman WM45E Mode d’emploi

Jay-Lor

Jay-Lor 5050 Manuel utilisateur

Sunbeam

Sunbeam FPSBSM210X Manuel utilisateur

MULTIQUIP

MULTIQUIP Whiteman MC94S Mode d’emploi

Thinky

Thinky ARE-250 Manuel utilisateur

Midas

Midas XL4 Manuel utilisateur

bianco

bianco PURO 4 Manuel utilisateur

Paso

Paso DAG9200 Manuel utilisateur

Sima

Sima SFX-9A Manuel utilisateur

better chef

better chef IM-815WC Instructions d'installation

ALLEN & HEATH

ALLEN & HEATH GR1 Manuel utilisateur

Lacor

Lacor 69083 Fiche technique

M-Audio

M-Audio Midiman SAM Manuel utilisateur

Buffalo

Buffalo CP921 Manuel utilisateur

Pentair

Pentair HYPRO Cleanload 3376-0870 Instructions de fonctionnement

Cuisinart

Cuisinart SM50WHE Manuel utilisateur

Hobart

Hobart HCM-300 Manuel utilisateur
