Keysight Technologies E4982A Manuel utilisateur

Keysight E4982A

LCR Meter

Installation Guide

Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176 - TestEquipmentDepot.com

Notices

No part of this manual may be reproduced

in any form or by any means (including

electronic storage and retrieval or transla-

tion into a foreign language) without prior

agreement and written consent from Key-

sight Technologies as governed by United

States and international copyright laws.

Manual Printing History

The manual’s printing date and part num-

ber indicate its current edition. The printing

date changes when a new edition is printed

(minor corrections and updates that are

incorporated at reprint do not cause the

date to change). The manual part number

changes when extensive technical

changes are incorporated.

February 2012 Edition 1

February 2015 Edition 2

Manual Part Number

E4982-90000

Edition

Edition 2, February 2015

Printed in Malaysia

Keysight Technologies

1400 Fountaingrove Parkway

Santa Rosa, CA 95403 USA

Warranty

The material contained in this docu-

ment is provided “as is,” and is sub-

ject to being changed, without notice,

in future editions. Further, to the max-

imum extent permitted by applicable

law, Keysight disclaims all warran-

ties, either express or implied, with

regard to this manual and any infor-

mation contained herein, including

but not limited to the implied warran-

ties of merchantability and fitness for

a particular purpose. Keysight shall

not be liable for errors or for inciden-

tal or consequential damages in con-

nection with the furnishing, use, or

performance of this document or of

any information contained herein.

Should Keysight and the user have a

separate written agreement with

warranty terms covering the material

in this document that conflict with

these terms, the warranty terms in

the separate agreement shall control.

Technology Licenses

The hardware and/or software described in

this document are furnished under a

license and may be used or copied only in

accordance with the terms of such license

Restricted Rights Legend

If software is for use in the performance of

a U.S. Government prime contract or sub-

contract, Software is delivered and

licensed as “Commercial computer soft-

ware” as defined in DFAR 252.227-7014

(June 1995), or as a “commercial item” as

defined in FAR 2.101(a) or as “Restricted

computer software” as defined in FAR

52.227-19 (June 1987) or any equivalent

agency regulation or contract clause. Use,

duplication or disclosure of Software is

subject to Keysight Technologies’ standard

commercial license terms, and non-DOD

Departments and Agencies of the U.S. Gov-

ernment will receive no greater than

Restricted Rights as defined in FAR

52.227-19(c)(1-2) (June 1987). U.S. Govern-

ment users will receive no greater than

Limited Rights as defined in FAR 52.227-14

(June 1987) or DFAR 252.227-7015 (b)(2)

(November 1995), as applicable in any

technical data.

Safety Notices

CAUTION

A CAUTION notice denotes a haz-

ard. It calls attention to an operat-

ing procedure, practice, or the like

that, if not correctly performed or

adhered to, could result in damage

to the product or loss of important

data. Do not proceed beyond a

CAUTION notice until the indicated

conditions are fully understood and

met.

WARNING

A WARNING notice denotes a

hazard. It calls attention to an

operating procedure, practice, or

the like that, if not correctly per-

formed or adhered to, could result

in personal injury or death. Do not

proceed beyond a WARNING

notice until the indicated condi-

tions are fully understood and met.

LCR Meter 3

Caution

Do not exceed the operating input power, voltage,

and current level and signal type appropriate for the

instrument being used, refer to your instrument's Function

Reference.

Electrostatic discharge (ESD) can damage the highly

sensitive microcircuits in your instrument. ESD damage is

most likely to occur as the test fixtures are being connected

or disconnected. Protect them from ESD damage by wearing

a grounding strap that provides a high resistance path to

ground. Alternatively, ground yourself to discharge any static

charge built- up by touching the outer shell of any grounded

instrument chassis before touching the test port connectors.

4LCR Meter

Safety Summary

When you notice any of the unusual conditions listed below,

immediately terminate operation and disconnect the power

cable.

Contact your local Keysight Technologies sales representative

or authorized service company for repair of the instrument.

If you continue to operate without repairing the instrument,

there is a potential fire or shock hazard to the operator.

•Instrument operates abnormally.

•Instrument emits abnormal noise, smell, smoke or a

spark- like light during operation.

•Instrument generates high temperature or electrical shock

during operation.

•Power cable, plug, or receptacle on instrument is

damaged.

•Foreign substance or liquid has fallen into the instrument.

LCR Meter 5

Manufacturer’s Declaration

Herstellerbescheinigung

GERA- USCHEMISSION

LpA < 70 dB

am Arbeitsplatz

normaler Betrieb

nach DIN 45635 T. 19

Manufacturer's Declaration

ACOUSTIC NOISE EMISSION

LpA < 70 dB

operator position

normal operation

per ISO 7779

6LCR Meter

Regulatory Compliance Information

This product complies with the essential requirements of the

following applicable European Directives, and carries the CE

marking accordingly:

•The Low Voltage Directive 2006/95/EC

•The EMC Directive 2004/108/EEC

To obtain Declaration of Conformity, please contact your

local Keysight Technologies sales office, agent or distributor.

LCR Meter 7

Safety Notice Supplement

•This equipment complies with EN/IEC61010- 1:2001.

•This equipment is of MEASUREMENT CATEGORY I (CAT

I). Do not use for CAT II, III, or IV.

•Do not connect the measuring terminals to mains.

•This equipment is a POLLUTION DEGREE 2, INDOOR

USE product.

•This equipment is tested in stand- alone condition and in

combination with the accessories supplied by Keysight

Technologies against the requirement of the standards

described in the Declaration of Conformity. If it is used

as a system component, compliance of related regulations

and safety requirements are to be confirmed by the

builder of the system.

8LCR Meter

General Safety Precautions

The following general safety precautions must be observed

during all phases of operation, service, and repair of this

instrument. Failure to comply with these precautions or with

specific WARNINGS elsewhere in this manual may impair the

protection provided by the equipment. Such noncompliance

would also violate safety standards of design, manufacture,

and intended use of the instrument. Keysight Technologies

assumes no liability for the customer’s failure to comply

with these precautions.

•Ground the Instrument

To avoid electric shock, the instrument chassis and

cabinet must be grounded with the supplied power cable’s

grounding prong.

•DO NOT Operate in an Explosive Atmosphere

Do not operate the instrument in the presence of

inflammable gasses or fumes. Operation of any electrical

instrument in such an environment clearly constitutes a

safety hazard.

•Keep Away from Live Circuits

Operators must not remove instrument covers. Component

replacement and internal adjustments must be made by

qualified maintenance personnel. Do not replace

components with the power cable connected. Under

certain conditions, dangerous voltage levels may remain

even after the power cable has been disconnected. To

avoid injuries, always disconnect the power and discharge

circuits before touching them.

•DO NOT Service or Adjust the Instrument Alone

Do not attempt internal service or adjustment unless

another person, capable of rendering first aid and

resuscitation, is present.

•DO NOT Substitute Parts or Modify the Instrument

NOTE

The E4982A complies with INSTALLATION CATEGORY II as well as

POLLUTION DEGREE 2 in IEC61010-1. The E4982A is an INDOOR USE

product.

NOTE

The LEDs in the E4982A are Class 1 in accordance with IEC60825-1,

CLASS 1 LED PRODUCT.
