T320 Internet Router and T640 Internet

Routing Node Control Board (T-CB)

Installation Instructions

12 November 2004

Part No: 530-012185-01

Revision 2

This document describes how to remove and replace a Control Board (T-CB) in a

T320 Internet router and a T640 Internet routing node.

Contents T-CB Description.................................................................... 2

T-CB Components................................................................... 3

Tools and Parts Required........................................................... 4

Replacing a T-CB ................................................................... 4

Removing a T-CB............................................................... 4

Installing a T-CB ............................................................... 5

List of Technical Publications ...................................................... 6

Requesting Support................................................................. 8

Revision History .................................................................... 9

T320 Internet Router and T640 Internet Routing Node Control Board (T-CB) Installation Instructions

T-CB Description

Each T-CB works with an adjacent Routing Engine to provide control

and monitoring functions for the routing platform (see Figure 1). These

functions include determining Routing Engine mastership; controlling power

and reset for the other routing platform components; monitoring and

controlling fan speed; and monitoring system status.

You can install one or two T-CBs in the routing platform. The T-CBs install

into the upper rear of the chassis in the slots labeled CB0 and CB1 (referred

to as T-CB-0 and T-CB-1). If two T-CBs are installed, one functions as the

master T-CB and the other as its backup. If the master fails or is removed,

the backup restarts and becomes the master.

EachT-CBrequiresaRoutingEnginetobeinstalledintheadjacentslot. T-CB-0

installs above RE0,andT-CB-1 installs below RE1.AT-CBdoesnotfunction

if a Routing Engine is not present in the adjacent slot.

T-CBs are hot-pluggable.

Figure 1: T-CB

g002130

Online/offline

button

Extractor clip

LEDs

Control Board - T

MASTER

MULTI CHASSIS MODE

CHASSIS ID

ONLINE/

OFFLINEFAIL

Extractor clip

AUX

YELLOW=10Mb

GREEN=100Mb

CIP

M/S and chassis

ID switches

Control

plane ports

NOTE: The T-CB requires JUNOS software Release 7.0 or later.

2T-CB Description

T-CB Components

Each T-CB consists of the following components:

100-MB Ethernet switch. This switch is used for intermodule communication.

PCI bus to the Routing Engines.

Processor subsystem (SPMB).

Three LEDs, located on the T-CB faceplate. These indicate the status of the

T-CB. Table 1 describes the functions of the T-CB LEDs.

Online/offline button, located on the T-CB faceplate. This button is

nonfunctional.

Two configuration switches, located on the T-CB faceplate.

NOTE: The M/S and CHASSIS ID switches on the T-CB faceplate must always be set to

Sand 0in a standalone routing platform.

If a T640 routing node is connected to a TX Matrix platform, these switches must

be set to Mand the chassis identifier (ID) of the routing node. In this case, both

T-CBs must have the same chassis ID. For more information, see the TX Matrix

Platform Hardware Guide.

Two RJ-45 ports labeled AUX and CIP on the T-CB faceplate. These ports are not

used in a standalone routing platform. Only the CIP port is used in a T640

routing node connected to a TX Matrix platform. For more information, see

the TX Matrix Platform Hardware Guide.

Table 1: T-CB LEDs

Label Color State Description

MASTER Blue On steadily T-CB is functioning as the master.

FAIL Amber On steadily T-CB has failed.

On steadily T-CB is online and is functioning normally.OK Green

Blinking T-CB is powering up, but not online.

T-CB Components 3

T320 Internet Router and T640 Internet Routing Node Control Board (T-CB) Installation Instructions

Tools and Parts Required

To replace a T-CB, you need the following tools:

Phillips (+) screwdriver, number 2

ESD wrist strap with cable

Electrostatic bag or antistatic mat

Blank panels to cover any slots not occupied by a component

Replacing a T-CB

The T-CBs are hot-pluggable. If the routing platform contains a redundant host

subsystem, the T-CB and the Routing Engine are hot-removable and hot-insertable.

Before you replace a T-CB or a Routing Engine, you must take the host subsystem

offline(seetheT320 Internet Router Hardware Guide or the T640 Internet Routing

Node Hardware Guide). To replace a T-CB, use the following procedures:

NOTE: The figures in these procedures show the T640 routing node for reference.

Removing a T-CB on page 4

InstallingaT-CBonpage 5

Removing a T-CB

The routing platform can have one or two T-CBs. They are located in

the upper rear of the chassis in the slots marked CB0 and CB1.Each

T-CB weighs approximately 5 lb (2.3 kg).

To remove a T-CB, follow this procedure (see Figure 2):

1. Place an electrostatic bag or antistatic mat on a flat, stable surface.

2. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist

and connect the strap to one of the ESD points on the chassis. For more

information about ESD, see the T320 Internet Router Hardware Guide or the

T640 Internet Routing Node Hardware Guide.

3. Check whether the T-CB is functioning as the backup or as the master. If

necessary, take the host subsystem offline as described in the T320 Internet

Router Hardware Guide or the T640 Internet Routing Node Hardware Guide.

4. If applicable, disconnect the cable plugged into the port labeled CIP.

5. Loosen the captive screws (using a Phillips (+) screwdriver, number 2) on the

ejector handles on both sides of the T-CB faceplate.

4Removing a T-CB

6. Flip the ejector handles outward to unseat the T-CB.

7. Grasp the ejector handles and slide the T-CB about halfway out of the chassis.

8. Place one hand underneath the T-CB to support it and slide it completely

outofthechassis.

9. PlacetheT-CBontheantistaticmat.

10. If you are not replacing the T-CB now, install a blank panel over the empty slot.

Figure 2: Removing a T-CB

g002187

Installing a T-CB

To install a T-CB, follow this procedure (see Figure 3):

1. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist

and connect the strap to an approved site ESD grounding point. For more

information about ESD, see the T320 Internet Router Hardware Guide or the

T640 Internet Routing Node Hardware Guide.

2. Ensure the ejector handles are not flush with the faceplate. If necessary, loosen

the captive screws and flip the ejector handles outward.

3. Carefully align the sides of the T-CB with the guides inside the chassis.

4. Slide the T-CB into the chassis, carefully ensuring that it is correctly aligned.

5. Grasp both ejector handles and press them inward to seat the T-CB.

6. Tighten the captive screws on the ejector handles, using a Phillips (+)

screwdriver, number 2.

7. If applicable, reconnect the cable previously plugged into the CIP port.

Installing a T-CB 5

T320 Internet Router and T640 Internet Routing Node Control Board (T-CB) Installation Instructions

8. If power is applied to the T-CB and its corresponding Routing Engine is

functioning normally, the T-CB comes online automatically. To verify that the

T-CB is functioning normally, check the LEDs on its faceplate. The green OK LED

should light steadily a few minutes after the T-CB is installed. If the FAIL LED is

lit steadily, remove and install the T-CB again (see “Removing a T-CB” on page

4 and “Installing a T-CB ” on page 5 ). If the FAIL LED still lights steadily, the

T-CB is not functioning properly. Contact your customer support representative.

To check the status of the T-CB, use the CLI command:

user@host> show chassis environment cb

Figure 3: Reinstalling a T-CB

g002188

List of Technical Publications

Table 2 lists the software and hardware guides and release notes for Juniper

Networks routing platforms that use the JUNOS Internet software and describes

the contents of each book.

Table 2: Juniper Networks Technical Documentation

Book Description

JUNOS for J-series, M-series, and T-series Routing Platforms Configuration Guides

Feature Guide Provides a detailed explanation and configuration examples for

several of the most complex features in the JUNOS software.

System Basics Provides an overview of the JUNOS software and describes how to

install and upgrade the software. This manual also describes how

to configure system management functions and how to configure

the chassis, including user accounts, passwords, and redundancy.

6List of Technical Publications

Book Description

Network Interfaces and Class of Service Provides an overview of the network interface and class-of-service

functions of the JUNOS software and describes how to configure

the network interfaces on the router.

MPLS Applications Provides an overview of traffic engineering concepts and describes

how to configure traffic engineering protocols.

Multicast Protocols Provides an overview of multicast concepts and describes how to

configure multicast routing protocols.

Network Management Provides an overview of network management concepts and

describes how to configure various network management features,

such as SNMP, accounting options, and cflowd.

Policy Framework Provides an overview of policy concepts and describes how to

configure routing policy, firewall filters, and forwarding options.

Routing Protocols Provides an overview of routing concepts and describes how to

configure routing, routing instances, and unicast routing protocols.

Services Interfaces Provides an overview of the services interfaces functions of the

JUNOS software and describes how to configure the services

interfaces on the router.

VPNs Provides an overview and describes how to configure Layer 2 and

Layer 3 virtual private networks (VPNs), virtual private LAN service

(VPLS), and Layer 2 circuits. Provides configuration examples.

JUNOS References

Network and Services Interfaces Command

Reference

Describes the JUNOS Internet software operational mode

commands you use to monitor and troubleshoot network and

services interfaces on Juniper Networks routing platforms.

Protocols, Class of Service, and System Basics

Command Reference

Describes the JUNOS Internet software operational mode

commands you use to monitor and troubleshoot most aspects of

Juniper Networks routing platforms.

System Log Messages Reference Describes how to access and interpret system log messages

generated by JUNOS software modules and provides a reference

page for each message.

JUNOScript API Documentation

JUNOScript API Guide Describes how to use the JUNOScript application programming

interface (API) to monitor and configure Juniper Networks routers.

JUNOScript API Configuration Reference Provides reference pages for the configuration tags in the

JUNOScript API.

JUNOScript API Operational Reference Provides reference pages for the operational tags in the JUNOScript

API.

JUNOS Comprehensive Index and Glossary

Comprehensive Index and Glossary Provides a complete index of all JUNOS Internet software books

and the JUNOScript API Guide. Also provides a comprehensive

glossary.

Hardware Documentation

Hardware Guide Describes how to install, maintain, and troubleshoot routers and

router components. Each platform has its own hardware guide.

PIC Guide Describes the router Physical Interface Cards (PICs). Each router

platform has its own PIC guide.

List of Technical Publications 7

T320 Internet Router and T640 Internet Routing Node Control Board (T-CB) Installation Instructions

Book Description

JUNOScope Documentation

JUNOScope Software User Guide Describes the JUNOScope software graphical user interface (GUI),

how to install and administer the software, and how to use the

software to manage router configuration files and monitor router

operations.

J-series Services Router Documentation

J-series Services Router User Guide Contains instructions for installing, configuring, and managing a

J-series Services Router. The guide explains how to prepare your

site for installation, unpack and install the hardware, power on the

router, configure secure routing, monitor network operations, and

perform routine maintenance.

Release Notes

JUNOS Internet Software Release Notes Provide a summary of new features for a particular software

release. Software release notes also contain corrections and

updates to published JUNOS and JUNOScript manuals, provide

information that might have been omitted from the manuals, and

describe upgrade and downgrade procedures.

Hardware Release Notes Describe the available documentation for the router platform

and summarize known problems with the hardware and

accompanying software. Each platform has its own release notes.

JUNOScope Software Release Notes Contain corrections and updates to the published JUNOScope

manual, provide information that might have been omitted from

the manual, and describe upgrade and downgrade procedures.

J-series Services Router Release Notes Briefly describe Services Router features, identify known hardware

problems, and provide upgrade and downgrade instructions

Requesting Support

For technical support, open a support case using the Case Manager link at

http://www.juniper.net/support/ or call 1-888-314-JTAC (within the United States) or

1-408-745-9500 (outside the United States).

If you are reporting a hardware or software problem, issue the following command

from the CLI before contacting support:

user@host>request support information |save

filename

To provide a core file to Juniper Networks for analysis, compress the file with

the gzip utility, rename the file to include your company name, and copy it to

ftp.juniper.net:pub/incoming. Then send the filename, along with software version

information (the output of the show version command) and the configuration, to

support@juniper.net.

For documentation issues, fill out the bug report form located at

http://www.juniper.net/techpubs/docbug/docbugreport.html.

8Requesting Support

Revision History

12 November 2004—Revision 2. Added JUNOS software requirement, and updated

support section.

12 November 2004—Revision 1.

Juniper Networks, the Juniper Networks logo, NetScreen, NetScreen Technologies, the NetScreen logo, NetScreen-Global Pro, ScreenOS, and

GigaScreen are registered trademarks of Juniper Networks, Inc. in the United States and other countries.

The following are trademarks of Juniper Networks, Inc.: ERX, ESP, E-series, Instant Virtual Extranet, Internet Processor, J2300, J4300, J6300, J-Protect,

J-series,J-Web,JUNOS,JUNOScope,JUNOScript,JUNOSe,M5,M7i,M10,M10i,M20,M40,M40e,M160,M320,M-series,MMD,NetScreen-5GT,

NetScreen-5XP, NetScreen-5XT, NetScreen-25, NetScreen-50, NetScreen-204, NetScreen-208, NetScreen-500, NetScreen-5200, NetScreen-5400,

NetScreen-IDP 10, NetScreen-IDP 100, NetScreen-IDP 500, NetScreen-Remote Security Client, NetScreen-Remote VPN Client, NetScreen-SA 1000 Series,

NetScreen-SA 3000 Series, NetScreen-SA 5000 Series, NetScreen-SA Central Manager, NetScreen Secure Access, NetScreen-SM 3000, NetScreen-Security

Manager, NMC-RX, SDX, Stateful Signature, T320, T640, T-series, and TX Matrix. All other trademarks, service marks, registered trademarks, or registered

service marks are the property of their respective owners. All specifications are subject to change without notice. Juniper Networks assumes no responsibility

for any inaccuracies in this document. Juniper Networks reserves the right to change, modify, transfer, or otherwise revise this publication withoutnotice.

Requesting Support 9

Autres manuels pour T320

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Juniper Routeur réseau

Juniper

Juniper J4300 Manuel utilisateur

Juniper

Juniper T1600 Manuel d'installation et d'exploitation

Juniper

Juniper E120 - RELEASE 11.1.X HARDWARE GUIDE... Instructions d'installation

Juniper

Juniper MX2020 Instructions d'installation

Juniper

Juniper EX6210 Manuel utilisateur

Juniper

Juniper ACX2000 Instructions d'installation

Juniper

Juniper PTX10003-80C Instructions d'installation

Juniper

Juniper ACX6160 Manuel utilisateur

Juniper

Juniper ACX500 Manuel utilisateur

Juniper

Juniper NetScreen-5GT Wireless Manuel utilisateur

Juniper

Juniper ACX2200 Manuel utilisateur

Juniper

Juniper EX4500 Series Manuel utilisateur

Juniper

Juniper ACX Series Manuel utilisateur

Juniper

Juniper ACX2000 Manuel utilisateur

Juniper

Juniper ACX2000 Manuel utilisateur

Juniper

Juniper MX10016 Manuel utilisateur

Juniper

Juniper EX2200 Series Instructions d'installation

Juniper

Juniper ACX5448-D Instructions d'installation

Juniper

Juniper SSR1200 Instructions d'installation

Juniper

Juniper ERX - RELEASE 11.1.X HARDWARE GUIDE... Instructions d'installation

Juniper

Juniper T Series Instructions d'installation

Juniper

Juniper E SERIES BROADBAND SERVICES ROUTERS 11.3.X - E120 AND E320 HARDWARE GUIDE REV... Instructions d'installation

Juniper

Juniper SRX240 Series Instructions d'installation

Juniper

Juniper J-Series Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
