T320 Core Router Quick Start

January 2015

Part Number: 530-036370

Revision 3

This document describes how to install the Juniper Networks T320 Core Router.

Contents T320QuickStartDescription..........................................3

Step 1: Prepare the Site for T320 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Rack-MountingRequirements......................................4

ToolsRequired...................................................5

Step2:InstalltheMountingHardware...................................7

Install the Mounting Hardware in a Four-Post Rack or Cabinet . . . . . . . . . . . . 7

InstallCageNuts,ifNeeded....................................8

Install the Large Mounting Shelf and Spacer Bars . . . . . . . . . . . . . . . . . . . 8

InstalltheSmallMountingShelf................................9

Remove the Center-Mounting Brackets . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Install the Mounting Hardware in an Open-Frame Rack . . . . . . . . . . . . . . . . . . 9

InstallCageNuts,ifNeeded....................................11

Install the Large Mounting Shelf and Spacer Bars . . . . . . . . . . . . . . . . . . . 11

Remove the Spacer Bars and Center-Mounting Brackets . . . . . . . . . . . . . 11

Step3:InstalltheRouter.............................................12

InstalltheRouterUsingaLift......................................12

Install the Router Without a Mechanical Lift . . . . . . . . . . . . . . . . . . . . . . . . . . 13

RemoveComponents.........................................13

LifttheRouterintotheRack...................................14

ReinstallComponents........................................16

Step4:ConnecttheGroundingCable...................................17

Step 5: Connect External Devices and PIC Cables . . . . . . . . . . . . . . . . . . . . . . . . . 18

ConnectaManagementConsole...................................18

Connect to a Network for Out-of-Band Management . . . . . . . . . . . . . . . . . . . 19

ConnectthePICCables...........................................19

Step6:PowerontheRouter..........................................20

ConnecttheDCPowerCables.....................................20

PowerOntheRouter.............................................21

Step 7: Perform Initial Software Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

EnteringConfigurationMode......................................22

Configuring User Accounts and Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

ConfiguringSystemAttributes.....................................23

CommittingtheConfiguration.....................................24

SafetyWarnings....................................................27

ComplianceStatementsforNEBS.....................................28

Compliance Statements for EMC Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Canada .......................................................29

EuropeanCommunity............................................29

Israel .........................................................29

Japan.........................................................29

United States ..................................................30

Junos OS Documentation and Release Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

RequestingTechnicalSupport.........................................31

Self-Help Online Tools and Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

OpeningaCasewithJTAC........................................32

Revision History ....................................................32

T320 Core Router Quick Start

T320 Quick Start Description

This Quick Start contains information you need to install and configure the router quickly.

For complete installation instructions, see the T320 Core Router Hardware Guide at

http://www.juniper.net/techpubs/hardware/.

WARNING: This Quick Start contains a summary of safety warnings in “Safety

Warnings” on page 27. For a complete list of warnings for this router, including

translations, see the T320 Core Router Hardware Guide at

http://www.juniper.net/techpubs/hardware/.

The router is shipped in a wooden crate. A wooden pallet forms the base of the crate.

The router chassis is bolted to this pallet. The shipping crate contains:

•One accessory box (the box to which this Quick Start is taped)

•One Juniper Networks router

•One Quick Start (this document)

T320 Quick Start Description

Step 1: Prepare the Site for T320 Installation

Before installing the router, make sure that the site meets power, environmental, and

clearance requirements for the router. See the site preparation guidelines in the T320

Core Router Hardware Guide.

•Rack-Mounting Requirements on page 4

•Tools Required on page 5

Rack-Mounting Requirements

•You can install the router in a four-post rack or cabinet, or an open-frame rack.

•The rack rails must be spaced widely enough to accommodate the router chassis's

external dimensions: 25.13 in. (63.82 cm) high, 31 in. (78.7 cm) deep, and 17.4 in. (44.2

cm) wide. The front-mounting flanges and center-mounting brackets extend the width

to fit into standard 19-in. (48.3 cm) racks.

•The rack must be strong enough to support the weight of the fully configured router.

Each router can weigh up to 369.9 lb (167.8 kg) if fully configured. Up to three routers

can be installed into one standard (44-U) rack that can handle their combined weight,

which can be greater than 1100 lb (499 kg).

•For service personnel to remove and install hardware components, there must be

adequate space at the front and back of the router. Allow at least 24 in. (61.0 cm) both

in front of and behind the router. NEBS GR-63 recommends at least 30 in. in front of

the router.

•The rack or cabinet must have an adequate supply of cooling air.

•In a closed cabinet, there must be a minimum of 6 in. (15.2 cm) of unobstructed airflow

behind the router, or airflow baffles must be installed to prevent recirculation of hot

air and overheating.

•If the router is the only unit in the rack, mount it at the bottom of the rack.

•When mounting the router in a partially filled rack, load the rack from the bottom to

the top with the heaviest component at the bottom of the rack.

T320 Core Router Quick Start

Figure 1: Rack Clearances and Router Dimensions

Tools Required

•A mechanical lift – recommended

•1/2-in. or 13-mm open-end or socket wrench to remove bracket bolts from the shipping

pallet

•Phillips screwdrivers, numbers 1 and 2

•Flat-blade screwdriver

•7/16-in.socket wrench

•3/8-in. nut driver

•Wire cutters

•Pliers

Tools Required

•Cage nuts

•Electrostatic discharge wrist strap

•Antistatic mat

•Blank panels to cover any slots not occupied by a component

T320 Core Router Quick Start

Step 2: Install the Mounting Hardware

To install the mounting hardware, perform the appropriate procedure for your rack or

cabinet type:

•Install the Mounting Hardware in a Four-Post Rack or Cabinet on page 7

•Install the Mounting Hardware in an Open-Frame Rack on page 9

Install the Mounting Hardware in a Four-Post Rack or Cabinet

To install the mounting hardware for a four-post rack or cabinet:

•Install cage nuts, if needed.

•Install the large mounting shelf and the spacer bars on the front rack rail.

•Install the small mounting shelf on the rear rack rail.

•Remove the center-mounting brackets from the chassis.

Figure 2: Mounting Hardware for a Four-Post Rack or Cabinet

Step 2: Install the Mounting Hardware

Table 1: Four-Post Rack and Cabinet Mounting Holes

Small ShelfSpacer BarsLarge ShelfDistance Above “U” DivisionHole

–x–13.86 U24.26 in. (61.6 cm)42

–x–10.86 U19.01 in. (48.3 cm)33

–x–7.86 U13.76 in. (34.9 cm)24

xx–4.86 U8.51 in. (21.6 cm)15

x––3.86 U6.76 in. (17.1 cm)12

x––4.86 U5.01 in. (12.7 cm)9

xx–1.86 U3.26 in. (8.3 cm)6

x––.86 U1.51 in. (3.8 cm)3

x–x.5 U0.88 in. (2.2 cm)2

•Install Cage Nuts, if Needed on page 8

•Install the Large Mounting Shelf and Spacer Bars on page 8

•Install the Small Mounting Shelf on page 9

•Remove the Center-Mounting Brackets on page 9

Install Cage Nuts, if Needed

For racks without threaded holes, you must install cage nuts in the mounting holes

specified in Table 1 on page 8:

1. On each front rack rail, install cage nuts for the large shelf and spacer bars.

2. On each rear rack rail, install a cage nut for the small shelf.

Install the Large Mounting Shelf and Spacer Bars

The large shelf and spacer bars install on the front rail. See Figure 2 on page 7.

1. On the front side of each front rail, partially insert a mounting screw in the lowest

mounting hole location specified in Table 1 on page 8 for the large shelf.

2. Install the large shelf on the front side of each front rail. Rest the bottom slot of each

flange on one of the mounting screws.

3. Tighten all the screws completely.

4. Remove the screws that fasten the spacer bars to the back of the front-mounting

flanges on the chassis.

T320 Core Router Quick Start

5. Place one spacer bar over a flange of the large shelf. Position the notch in the rear of

the spacer bar so the upper part of the bar is flush with the rack rail and the lower part

is flush with the flange of the shelf.

6. Secure the spacer bar by inserting a mounting screw through the nonthreaded holes

in the recesses of the spacer bar into the threaded hole on the rack.

7. Repeat Steps 5 and 6 for the other spacer bar.

8. Tighten all the screws completely.

Install the Small Mounting Shelf

The small shelf installs on the back of the rear rails, extending toward the center of the

rack. See Figure 2 on page 7.

1. On the back side of each rear rail, partially insert a mounting screw in the highest

mounting hole specified for the small shelf in Table 1 on page 8.

2. Install the small shelf on the back of each rear rail. Align the lower of the two slots in

the flange of the small shelf with the partially installed mounting screw. The bottom

of the small shelf must align with the bottom of the large shelf.

3. Partially insert screws into the open holes in the flanges of the small shelf.

4. Tighten all the screws completely.

Remove the Center-Mounting Brackets

The router is shipped with a spacer bar attached to the back of each front-mounting

flange, and two center-mounting brackets attached to the chassis. Remove the

center-mounting brackets from the chassis by loosening the screws at the top and bottom

of each bracket.

Install the Mounting Hardware in an Open-Frame Rack

For open-frame racks, you install the large mounting shelf:

•Front-mount: Attach the large mounting shelf and the spacer bars to the back of the

rails. Remove the center-mounting brackets from the chassis.

•Center-mount: Attach the large mounting shelf to the back of the rails (See

Figure 3 on page 10). You do not have to remove the spacer bars from the

front-mounting flanges.

The small mounting shelf is not needed for open-frame racks. Table 2 on page 10 specifies

the holes in which you insert mounting screws, and cage nuts if needed.

Install the Small Mounting Shelf

Figure 3: Mounting Hardware for an Open-Frame Rack

Table 2: Open-Frame Rack Mounting Holes

ChassisLarge ShelfDistance Above “U” DivisionHole

x-12.86 U22.51 in. (57.2 cm)39

xx9.86 U17.26 in. (43.8 cm)30

xx6.86 U12.01 in. (30.5 cm)21

xx3.86 U6.76 in. (17.1 cm)12

xx0.86 U1.51 in. (3.8 cm)3

•Install Cage Nuts, if Needed on page 11

•Install the Large Mounting Shelf and Spacer Bars on page 11

•Remove the Spacer Bars and Center-Mounting Brackets on page 11

T320 Core Router Quick Start

Autres manuels pour T320

Table des matières

Autres manuels Juniper Routeur réseau

Juniper

Juniper M10 Instructions d'installation

Juniper

Juniper EX8208 Manuel utilisateur

Juniper

Juniper EX2300 Series Manuel utilisateur

Juniper

Juniper E120 - RELEASE 11.1.X MODULE GUIDE 3-26-2010 Manuel utilisateur

Juniper

Juniper E SERIES BROADBAND SERVICES ROUTERS 11.3.X - ERX MODULE GUIDE REV... Manuel utilisateur

Juniper

Juniper ACX710 Manuel utilisateur

Juniper

Juniper ACX5448-D Instructions d'installation

Juniper

Juniper M120 Instructions d'installation

Juniper

Juniper M5 Manuel utilisateur

Juniper

Juniper MX10003 Instructions d'installation

Juniper

Juniper J2300 Manuel utilisateur

Juniper

Juniper MX2008 Instructions d'installation

Juniper

Juniper MX10016 Manuel utilisateur

Juniper

Juniper PTX1000 Instructions d'installation

Juniper

Juniper MX10 Instructions d'installation

Juniper

Juniper T4000 - Instructions d'installation

Juniper

Juniper MX960 Manuel utilisateur

Juniper

Juniper NFX150-C-S1 Manuel utilisateur

Juniper

Juniper M7i Manuel utilisateur

Juniper

Juniper TX MATRIX PLUS Instructions d'installation

Juniper

Juniper Day One+ MX304 Manuel utilisateur

Juniper

Juniper Day One+ ACX7509 Manuel utilisateur

Juniper

Juniper EX9200 Series Fiche technique

Juniper

Juniper T4000 - Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
