Juniper SRX5400 Manuel utilisateur

SRX5400 Services Gateway Getting Started

Guide

October 2017

Part Number: 530-082619

Revision 01

This document describes how to install the SRX5400 Services Gateway.

Contents About This Guide | 3

Step 1: Prepare the Site for SRX5400 Services Gateway Installation | 4

Rack-Mounting Requirements | 5

Tools Required to Unpack and Prepare the SRX5400 Services Gateway for Installation | 6

Step 2: Install the Mounting Hardware in a Four-Post Rack or Cabinet or an Open-Frame Rack | 6

Step 3: Install the Services Gateway | 9

Remove Components | 10

Install the Services Gateway Using a Lift | 11

Install the Services Gateway Without a Mechanical Lift | 13

Reinstall Components | 14

Step 4: Connect the Grounding Cable | 14

Step 5: Connect External Devices and Network Cables | 16

Connect to a Network for Out-of-Band Management | 16

Connect a Management Console | 16

Connect the Network Cables | 17

Step 6: Connect Power Cables | 18

Connect Power to an AC-Powered Services Gateway | 18

Connect Power to a DC-Powered Services Gateway | 20

Step 7: Perform the Initial Software Configuration | 23

Enter Configuration Mode | 23

Configure User Accounts and Passwords | 24

Configure System Attributes | 24

Commit the Configuration | 26

Safety Warnings | 29

SRX5400 Services Gateway Compliance Statements for EMC Requirements | 31

Canada | 31

European Community | 32

Japan | 32

United States | 32

SRX Series Documentation and Release Notes | 32

Requesting Technical Support | 33

Revision History | 34

About This Guide

This guide contains information that you need to install and configure the SRX5400 Services Gateway

quickly. For complete installation instructions, see the SRX5400 Services Gateway hardware documentation

at www.juniper.net/documentation/.

WARNING: This guide contains a summary of safety warnings in “Safety Warnings” on

page 29. For a complete list of warnings for this device, including translations, see the

SRX5400 Services Gateway hardware documentation at www.juniper.net/documentation/.

The SRX5400 Services Gateway is a high-performance, highly scalable, carrier-class security device with

multi-processor architecture.

The SRX5400 Services Gateway is 5 rack units (U) tall. Five of these devices can be stacked in a single

floor-to-ceiling rack, for increased port density per unit of floor space.

The services gateway provides four slots that you can populate with one Switch Control Board (SCB) and

up to three additional cards of the following types:

•Services Processing Cards (SPCs) provide the processing capacity to run integrated services such as

firewall, IPsec, and IDP.

•Modular Port Concentrators (MPCs) and the Modular Interface Cards (MICs) that install in them provide

Ethernet interfaces that connect the services gateway to your data network.

NOTE: The SRX5400 Services Gateway supports the SRX5K-SPC-4-15-320 SPC only. It does

not support the SRX5K-SPC-2-10-40 SPC.

By installing different combinations of MPCs and SPCs, you can tailor both the number of ports and the

maximum services processing capacity to suit your network. Table 1 on page 3 describes the possible

system configurations for the SRX5400 Services Gateway.

Table 1: Possible System Configurations

MaximumMinimumComponent

21SPC

21MPC

11SCB

Table 1: Possible System Configurations (continued)

MaximumMinimumComponent

11Routing Engine

NOTE: For SPCs and MPCs, there are three slots available allowing for the following SPC and MPC

configuration scenarios: 1 SPC and 1 MPC, 2 SPCs and 1 MPC, or 1 SPC and 2 MPCs.

NOTE: MPCs are the only interface cards supported by the SRX5400 Services Gateway. The

SRX5400 Services Gateway does not support the IOCs or Flex IOCs supported on other services

gateways in the SRX5000 line.

Four AC power supplies (PSUs) provide full power redundancy. Each AC power supply provides power to

all components in the device. When two or more power supplies are present, they share power almost

equally within a fully populated system. However, if using only two AC PSUs, you must insert them into

the first and third PSU slots. In the DC configuration, two power supplies are required to supply power to

a fully configured device.

For detailed information about the SPCs, MPCs, and other cards supported by the services gateway, see

the SRX5400, SRX5600, and SRX5800 Services Gateway Card Reference at www.juniper.net/documentation/.

The services gateway is shipped in a cardboard box strapped securely to a wooden pallet. Plastic straps

secure the top and bottom in place. The services gateway chassis is bolted to this pallet. A printed copy

of this document and a cardboard accessory box are also included in the shipping container.

Step 1: Prepare the Site for SRX5400 Services

Gateway Installation

IN THIS SECTION

Rack-Mounting Requirements | 5

Tools Required to Unpack and Prepare the SRX5400 Services Gateway for Installation | 6

Rack-Mounting Requirements

•You can install the services gateway in a four-post rack or cabinet or an open-frame rack.

•The rack rails must be spaced widely enough to accommodate the services gateway chassis' external

dimensions: 8.71 in. (22.1 cm) high, 24.5 in. (62.2 cm) deep, and 17.45 in. (44.3 cm) wide. The mounting

brackets extend the width to 19 in. (48.3 cm). See Figure 1 on page 5.

Figure 1: Rack Clearance and Chassis Dimensions

•The rack must be strong enough to support the weight of the fully configured services gateway, up to

128 lb (58.1 kg).

•For the cooling system to function properly, the airflow around the chassis must be unrestricted. Allow

at least 6 in. (15.2 cm) of clearance between side-cooled services gateways. Allow 2.8 in. (7 cm) between

the side of the chassis and any non-heat-producing surface such as a wall.

•For service personnel to remove and install hardware components, there must be adequate space at the

front and back of the services gateway. Allow at least 30 in. (76.2 cm) in front of the services gateway

and 24 in. (61 cm) behind the services gateway.

•The rack or cabinet must have an adequate supply of cooling air.

•Ensure that the cabinet allows the chassis hot exhaust air to exit from the cabinet without recirculating

into the services gateway.

•The services gateway must be installed into a rack that is secured to the building structure.

•Mount the services gateway at the bottom of the rack if it is the only unit in the rack.

•When mounting the services gateway in a partially filled rack, load the rack from the bottom to the top

with the heaviest component at the bottom of the rack.

Tools Required to Unpack and Prepare the SRX5400 Services Gateway for

Installation

To unpack the services gateway and prepare for installation, you need the following tools:

•A mechanical lift—recommended

•Phillips (+) screwdrivers, numbers 1 and 2

•2.5-mm flat-blade (–) screwdriver

•7/16-in. torque-controlled driver or socket wrench

•1/2-in. or 13-mm open-end or socket wrench to remove bracket bolts from the shipping pallet

•Electrostatic discharge wrist strap

•Antistatic mat

Proceed to “Step 2: Install the Mounting Hardware in a Four-Post Rack or Cabinet or an Open-Frame

Rack” on page 6.

Step 2: Install the Mounting Hardware in a Four-Post

Rack or Cabinet or an Open-Frame Rack

To install the mounting shelf on the front rails of a four-post rack or cabinet, or on the rails of an open-frame

rack:

1. If needed, install cage nuts in the holes specified in Table 2 on page 7.

2. On the back of each rack rail, partially insert a mounting screw into the lowest hole specified in

Table 2 on page 7.

3. Install the mounting shelf on the back of the rack rails. Rest the bottom slot of each flange on a mounting

screw.

4. Partially insert screws into the open holes in each flange of the mounting shelf (see Figure 2 on page 8

or Figure 3 on page 9).

5. Tighten all the screws completely.

Table 2: Mounting Shelf Hole Locations

Distance Above U Division

Hole (Starting from U

Division)

1.14 U2.00 in. (5.1 cm)4

0.86 U1.51 in. (3.8 cm)3

0.50 U0.88 in. (2.2 cm)2

0.14 U0.25 in. (0.6 cm)1

Figure 2: Mounting Hardware for a Four-Post Rack or Cabinet

g004258

Four-post open rack

Small mounting shelf

Figure 3: Mounting Hardware for an Open-Frame Rack

Proceed to “Step 3: Install the Services Gateway” on page 9.

Step 3: Install the Services Gateway

IN THIS SECTION

Remove Components | 10

Install the Services Gateway Using a Lift | 11

Install the Services Gateway Without a Mechanical Lift | 13

Reinstall Components | 14

Because of the services gateway’s size and weight, you must remove all components, as shown in

Figure 4 on page 10 and Figure 5 on page 10, before you install the services gateway. We also recommend

using a mechanical lift to install the services gateway.

Remove Components

Figure 4: Components to Remove from the Front of the Services Gateway

g030323

SPCs

SCB

MPC

Figure 5: Components to Remove from the Rear of the Services Gateway

g030324

Power

supplies

Fan tray

Air filter

Before you lift the services gateway, you must remove the following components:

•Power supplies

•SCB

•Routing Engine

•Air filter

•Fan tray

•SPCs

•MPCs
