JETWAY NF894V Series Manuel utilisateur

NF894V Series

User’s Manual

NO. G03-NF894V-F

Revision: 1.0

Release date: April 18, 2022

Trademark:

* Specifications and Information contained in this documentation are furnished for information use only, and are

subject to change at any time without notice, and should not be construed as a commitment by manufacturer.

Environmental Protection Announcement

Do not dispose this electronic device into the trash while discarding. To minimize

pollution and ensure environment protection of mother earth, please recycle.

ENVIRONMENTAL SAFETY INSTRUCTION...................................................................iii

USER’S NOTICE .............................................................................................................iv

MANUAL REVISION INFORMATION.............................................................................. iv

ITEM CHECKLIST........................................................................................................... iv

CHAPTER 1 INTRODUCTION OF THE MOTHERBOARD

1-1 FEATURE OF MOTHERBOARD ............................................................................1

1-2 SPECIFICATION .................................................................................................... 2

1-3 LAYOUT DIAGRAM ............................................................................................... 3

CHAPTER 2 HARDWARE INSTALLATION

2-1 JUMPER SETTING................................................................................................. 7

2-2 CONNECTORS, HEADERS AND WAFERS........................................................... 12

2-2-1 CONNECTORS......................................................................................... 12

2-2-2 HEADERS & WAFERS ............................................................................. 15

CHAPTER 3 INTRODUCING BIOS

3-1 ENTERING SETUP................................................................................................. 24

3-2 BIOS MENU SCREEN............................................................................................25

3-3 FUNCTION KEYS...................................................................................................26

3-4 GETTING HELP......................................................................................................26

3-5 MENU BARS..........................................................................................................26

3-6 MAIN MENU...........................................................................................................27

3-7 ADVANCED MENU ................................................................................................ 28

3-8 CHIPSET MENU..................................................................................................... 40

3-9 SECURITY MENU .................................................................................................. 44

3-10 BOOT MENU.......................................................................................................... 46

3-11 SAVE & EXIT MENU ..............................................................................................47

TABLE OF CONTENT

iii

Environmental Safety Instruction

Avoid the dusty, humidity and temperature extremes. Do not place the product in

any area where it may become wet.

0 to 40 centigrade is the suitable temperature. (The temperature comes from the

request of the chassis and thermal solution)

Generally speaking, dramatic changes in temperature may lead to contact

malfunction and crackles due to constant thermal expansion and contraction from

the welding spots’ that connect components and PCB. Computer should go

through an adaptive phase before it boots when it is moved from a cold

environment to a warmer one to avoid condensation phenomenon. These water

drops attached on PCB or the surface of the components can bring about

phenomena as minor as computer instability resulted from corrosion and oxidation

from components and PCB or as major as short circuit that can burn the

components. Suggest starting the computer until the temperature goes up.

The increasing temperature of the capacitor may decrease the life of computer.

Using the close case may decrease the life of other device because the higher

temperature in the inner of the case.

Attention to the heat sink when you over-clocking. The higher temperature may

decrease the life of the device and burned the capacitor.

USER’S NOTICE

INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT MAY BE REPRODUCED, TRANSMITTED

OR TRANSLATED INTO ANY LANGUAGE IN ANY FORM OR BY ANY MEANS WITHOUT WRITTEN

PERMISSION OF THE MANUFACTURER.

THIS MANUAL CONTAINS ALL INFORMATION REQUIRED TO USE THIS MOTHER-BOARD SERIES AND WE

DO ASSURE THIS MANUAL MEETS USER’S REQUIREMENT BUT WILL CHANGE, CORRECT ANY TIME

WITHOUT NOTICE. MANUFACTURER PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY

KIND, AND WILL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL

DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFIT, LOSS OF BUSINESS, LOSS OF USE OF DATA,

INTERRUPTION OF BUSINESS AND THE LIKE).

PRODUCTS AND CORPORATE NAMES APPEARING IN THIS MANUAL MAY OR MAY NOT BE

REGISTERED TRADEMARKS OR COPYRIGHTS OF THEIR RESPECTIVE COMPANIES, AND THEY ARE

USED ONLY FOR IDENTIFICATION OR EXPLANATION AND TO THE OWNER’S BENEFIT, WITHOUT

INTENT TO INFRINGE.

Manual Revision Information

Reversion Revision History Date

1.0 First Edition April 18, 2022

Item Checklist

Motherboard

Cable(s)

I/O Back panel shield

Chapter 1

Introduction of the Motherboard

1-1 Feature of Motherboard

Onboard Intel®Apollo Lake SoC Series Processor (Default J3455), with low

power consumption and high performance

Support 2* DDR3L 1866MHz SO-DIMM with maximum memory capacity up to

8GB

Onboard 32GB eMMC (Optional)

Integrated with 2* Intel i225-V 2.5 Gigabit Ethernet LAN chip

Integrated with Realtek HD Audio Codec

Support 4* USB 3.0 data transport demand

Support 2* HDMI (one option with DP, Default HDMI)+ 1* eDP or 1* LVDS display

Support 1* PCIe x1 slot & 1* full-size Mini-PCIe slot

Onboard 1* M.2 M-key (type-2242/2280, SATA interface) slot

Onboard 1* SATAIII (6Gb/s) port connector

Support 9V~36V DC-In

Support Smart FAN function

Supports ACPI S3 Function

Compliance with ErP Standard

Support Watchdog Timer Technology

Solution for Industrial Automation, Industrial PPC, KIOSK and Digital Signage

1-2 Specification

Spec

Description

Design

Mini-ITX form factor; 6-layers; PCB size: 17.0x17.0cm

CPU

Intel®Apollo Lake series SoC CPU (Default J3455)

* For detailed CPU support information please visit our website

Memory Slot

2* DDR3L SO-DIMM slot

Support DDR3L1866 MHz SODIMM up to 8GB

Support dual channel function

Expansion Slot

1* PCIE x 1 slot (PCIEX1)

1* Full-size Mini-PCIE slot (MPE1)

1* SIM card slot (SIM CARD)

Storage

1* SATA III 6G/s connector (SATA1)

1* M.2 M-key,type-2242/2280, SATA interface slot (M.2)

LAN Chip

Integrated with 2* Intel i225-V 2.5 Gigabit Ethernet LAN chip

Support Fast Ethernet LAN function of providing

10/100/1000/2500 Mbps Ethernet data transfer rate

Audio Chip

Realtek HD Audio Codec integrated

Audio driver and utility included

BIOS

AMI Flash ROM

Multi I/O

Rear Panel I/O:

1* 9V~36V DC-IN power jack

2* HDMI port (one option with DP, Default HDMI)

2* RJ-45 LAN port

4* USB 3.0 port

1* Audio line-out connector

Internal I/O Connectors, Headers & Wafers:

1* 2-Pin internal 9V~36V power connector

1* CPU FAN connector

1* SATA power out connector

1* Front panel header

1* Front panel audio header

1* 3W Amplifier wafer

1* LAN Status LED header

1* 9-Pin USB 2.0 header for 2* USB 2.0/1.1 ports

1* 4-Pin USB 2.0 header for 1* USB 2.0/1.1 port

1* RS232/422/485 serial port header(COM1)

5* RS232 serial port header(COM2/3/4/5/6)

1* PS2 Keyboard & Mouse header

1* SMBUS header

1* GPIO header

1* eDP wafer

1* LVDS header

1* LVDS Inverter wafer

1* JSIM header

1-3 Layout Diagram

Rear IO Diagram

Warning!!

The board has a 9V~36V DC-in power jack (DCIN3) in I/O back panel and an internal 9V~36V

power connector (DCIN2). User can only connect one type of compatible power supply to one

of them to power the system.

RJ-45 LAN Ports

HDMI2 Port

USB 3.0 Ports

Line-out

9V~36V

DC-In

Power Jack

HDMI1 Port (co-lay DP by order)

Motherboard Internal Diagram

*Note: 1. SIM card slot (SIMCARD/ expansion card drawn from JSIM header) only work when

compatible SIM card installed & LAN expansion card installed in the full-size MPE slot (MPE1); 2.

SIMCARD and JSIM is optional, i.e., only one can work at the same time.

PCI Express 2.0 x 1 Slot

(PCIE1)

RS232/422/485

Serial Port Header

(COM1)

2*DDR3L

SODIMM Slot

(SODIMM1/2)

INVERTER

SATAIII Port

*SIM Card

Slot

*Full-size

Mini-PCIE Slot

(MPE1)

Front Panel

Header

LAN_LED

Header

Front Panel

Audio Header

SMBUS

Header

LVDS

Header

CPUFAN

Connector

SATA Power

Out Port

RS232 Serial Port Header

(COM2/3/4/5/6)

Intel CPU

JSIM

Header

PS/2 Keyboard & Mouse

Header

eDP

Wafer

USB 2.0

Headers

GPIO

Header

*M.2 Socket 3

Connector

(M2)

9V~36V

DC-In

Power Jack

HDMI2 Port

RJ-45

LAN Ports

HDMI1 Port (co-lay DP by order)

USB 3.0 Ports

Line-out

3W Amplifier Wafer

Internal 9V~36V

DC-In Power Connector

32 GB

EMMC Chip

(optional)

Motherboard Jumper Position

JCOM1

JMPE

JAT_ATX1

JLCD

JLED
