GN 2110 ST

Also available with the SureFit

flexible earhook style as shown

in inset.

Sound Quality )Comfort )Durability )

GN 2100 Series

GN Netcom, the global leader in personal hands-free communications solutions, presents the

next generation of professional headsets—the GN 2100 Series.

SoundTube

We’ve taken the most advanced voice tube technology and matched it with a sleek, lightweight

design – for a combination of clarity, comfort and convenience that’s really a breed apart.

Flex

For noisy environments, GN 2100 Flex headsets feature the DuraFlex-II™ flexible boom, for exact

microphone positioning, and a noise-cancelling microphone, to filter out ambient noise. If you pre-

fer an on-the-ear model, the GN 2100 is also available with our patented SureFit®flexible earhook.

The Right Choice

The GN 2100 is available in a variety of styles to accommodate every user preference, including

monaural or binaural and amplified or Direct Connect.

Next Generation Professional Headsets

Features: Benefits:

Advanced voice tube technology Clear, natural sound quality

Sleek SoundTube design Stylish and unobtrusive

Weighs just 1 ounce Lightweight and easy to wear

Rugged boom turret Superior durability and reliability

(tested for 50,000 rotations)

Swing-away boom Take a drink without taking off your headset

Full-size ear cushion(s) leatherette All-day comfort

(headband) or foam (earhook)

Full range of styles and models The right choice for every user need & preference

Two-year “No Fine Print” Warranty Worry-free ownership

www.gnnetcom.com

GN Netcom, Inc. 77 Northeastern Blvd., Nashua, NH 03062 1-800-826-4656

DS-008 0705

Printed in USA

General Specifications

Operating Temperature 0°-50° C

Polarity Non-polar in amplified applications

Weight (headset & cord) GN 2100 ST: 1.7 oz

GN 2117 ST: 1.2 oz

Dielectric Withstand Voltage 5,000 V(AC) or 7,000 V (DC)

Safety Listed to UL 1950

FCC Parts 68 Registered

OSHA Part 1940 subpart S

cULus

Standard Features SoundTube Flex

Omnidirectional Microphone •

Noise-Canceling Microphone •

DuraFlex-II Microphone Boom •

SureFit Flexible Earhook ••

Click-Stop Headband ••

Swing-Away Boom ••

GN Netcom-compatible

Quick Disconnect ••

Direct Connect ••

2 Year “No Fine Print” Warranty ••

Best Sound, Comfort, Durability ••

Transmit Specifications

Microphone GN 2100 series headsets

are available with either omni-

directional or noise-canceling

electret microphones

Frequency Response 100-3,800 Hz

Distortion Less than 3%

Current Consumption <150 µa @ 3 V (DC)

Operating Voltage 1.8-24 V (DC)

Receive Specifications

Speaker Dynamic

Input Impedance 300 ohms (typical)

Frequency Response 175-3,800 Hz

Automatic Gain Control (AGC) -38 +/- 3.5 dBV

Threshold Level with Amplifier

Volume Control Range 32 +/- 4dB

Maximum Output (UL Rating) <118 dB SPL

Direct Connect: GN 2110 STD, GN 2117 STD and GN 2115 STD are available.

Direct Connect: GN 2120 NCD, GN 2127 NCD and GN 2125 NCD are available.

GN 2110-ST

Binaural

GN 2115-ST

Monaural

GN 2117-ST

On-the-ear

GN 2100 SoundTube™

GN 2120-NC

Binaural

GN 2125-NC

Monaural

GN 2127-NC

On-the-ear

GN 2100 Flex

Direct Connect versions of

GN 2100 Series headsets feature

our Quick Disconnect coil cord,

with the ultra-reliable GN Netcom

Quick Disconnect on one end and

a modular plug on the other.

The GN 8000 Multi-Purpose

Amplifier works with most phone

systems. It features a built-in

headset stand with an on-line

indicator option that signals

when the heaset is in use.

GN 2100 Direct Connect

GN 8000 MPA
