IWILL BD100 Plus Manuel utilisateur
1
EC Declaration of Conformity
We
Iwill Corp.
No. 10, Wu Chuan 3rd Rd.,
Hsin Chuang City, Taipei,
Taiwan, R.O.C.
Declare under sole responsibility that the
BD100 Plus motherboard
Meets the intent of Directive 89/336/ECC for Electromagnetic Compatibility. Compliance was
demonstrated to the following specifications as listed in the official Journal of the European
Communities:
EN 50081-1 Emissions:
EN 55022 Radiated, Class B
EN 55022 Conducted, Class B
EN 60555-2 Power Harmonics
EN 50082-1 Immunity:
IEC 801-2 Electrostatic Discharge
IEC 801-3 RF Radiate
IEC 801-4 Fast Transient
2
About This Manual
This manual will introduce to the user how this product is consisted. All useful information will be
described in later chapters. Keep this manual for your future upgrade or system re-configuration.
Chapter 0 Overview
An overview of some special and basic features of the BD100 Plus motherboard
Chapter 1 Features
The detailed features and specifications of the BD100 Plus motherboard
Chapter 2 Quick Installation
The quick reference for experienced users
Chapter 3 Hardware Installation
The detailed information on jumper setting, connection, and hardware installation
Chapter 4 System BIOS Setup
The detail information of the system BIOS setup options
Chapter 5 Software and Tools
The detail information for install software and tools
Copyright
This manual contains information protected by copyright law. All rights are reserved. No any part of
this document may be used or reproduced in any forms or by any means, or stored in a database or
retrieval system without prior written permission from Iwill Corp.
This manual is subject to change without notice.
Trademark
Intel / Pentium are trademarks of Intel Corporation.
IWILL and IWILL logo are trademarks of IWILL Corp.
Sound Blaster is a registered trademark of Creative Technology Ltd.
Sound Blaster-LINK and SB-LINK are trademarks of Creative Technology Ltd.
All other product names are trademarks and registered trademarks of their respective owners.
Warning
Most of the features of this product have passed strict verification and are subject to change at any
time without notice. If any malfunction occurs due to the future technical changes made by the
respective component manufacturers, Iwill assumes no responsibility or liability for it.
3
Contents
CHAPTER 0.................................................................................................5
OVERVIEW.................................................................................................5
CHAPTER 1.................................................................................................7
FEATURES...................................................................................................7
1.1 FEATURES ..............................................................................................7
1.2 ENVIRONMENT REQUIREMENTS...............................................................9
1.3 MOTHERBOARD COMPONENTS PLACEMENT...........................................10
1.4 BACK PANEL CONNECTOR ..................................................................102
1.5 FORM FACTOR......................................................................................13
CHAPTER 2...............................................................................................15
QUICK INSTALLATION..........................................................................15
CHAPTER 3...............................................................................................19
HARDWARE INSTALLATION ................................................................19
3.1 PREPARATION AND INSPECTION .............................................................19
3.2 UNPACK THE BD100 PLUS....................................................................19
3.3 INSTALLATION PROCEDURE ...................................................................20
CHAPTER 4...............................................................................................29
SYSTEM BIOS SETUP..............................................................................29
4.1 INTRODUCTION.....................................................................................29
4.2 MAIN MENU.........................................................................................30
4.3 STANDARD CMOS SETUP ...............................................................31
4.4 BIOS FEATURES SETUP...................................................................34
4.5 CHIPSET FEATURES SETUP ............................................................38
4.6 POWER MANAGEMENT SETUP......................................................41
4.7 PNP/ PCI CONFIGURATION..............................................................45
4
4.8 INTEGRATED PERIPHERALS ..........................................................46
4.9 LOAD SETUP DEFAULTS.................................................................50
4.10 IWILL SMART SETTING.................................................................50
4.11 SUPERVISOR / USER PASSWORD SETTING.................................51
4.12 IDE HDD AUTODETECTION..........................................................52
4.13 SAVE & EXIT SETUP.......................................................................52
4.14 EXIT WITHOUT SAVING................................................................52
CHAPTER 5...............................................................................................53
SOFTWARE AND TOOLS........................................................................53
5.1 SOFTWARE INSTALLATION.....................................................................53
5.2 HOW TO MAKE DRIVER DISKETTE WITHOUT O.S. INSTALLED...................54
5.3 CPU FREQUENCY SELECTION BY BIOS..................................................54
5.4 VIEW DETAILED MANUAL.....................................................................55
5.5 INSTALLING OPERATING SYSTEMS.........................................................55
5.6 INSTALLING THE SUSPEND TO DISK UTILITY ON YOUR BD100 PLUS ......57
5.7 HOW TO USE THE THERMAL SENSOR......................................................62
5.8 IWILL SCSI SERIES ...............................................................................63
5
Chapter 0
Overview
Thank you for purchasing Iwill BD100 Plus motherboard. This operation manual will instruct you
how to configure and install the system properly. It contains an overview about the engineering
design and features of this product. Also, this manual provides useful information for later upgrades
or configuration changes. Keep this for your future reference.
BD100 PLUS FEATURES
The BD100 Plus is the newest, most exciting motherboard in the market today. A step ahead of the
competition, the BD100 Plus provides more power, convenience, and reliability for users. The
BD100 Plus has more speed, and is great for better, fast computer graphics. The BD100 Plus has our
special Iwill Smart Setting—an easy way to set your CPU frequency—and also more versatile
power-on functions, all for your convenience. Furthermore, the BD100 Plus has several power
saving modes to reduce energy waste. All of these features are compacted in a dynamic motherboard
that has the stability you require in a powerful motherboard. Special features of the BD100 Plus
include:
lAGP Booster—allows for fast graphics for games, and in some cases brings more
stability to your AGP port
lIwill Smart Setting—allows easy setting of your CPU frequency, no jumpers required!
lVersatile Power-On—you can power-on the system using a hot key, password, LAN,
or modem
lPower Management Setup—allows you to set Doze, Standby, and Suspend modes
lPower Failure Recovery—after a power failure, the system will automatically turn on
again once the power returns
lHealth Monitoring System—helps manage your system so that your system runs safely
The BD100 Plus also includes some basic features, such as: 1 x Slot 1 for Pentium® III/II/Celeron,
Intel 443BX chipset, 4 x DIMM slots, 5 x PCI slots, 1 x FDC floppy disk connector, 2 x IDE
connectors, 2 x USB ports, 1 x PS/2 mouse, 1 x PS/2 keyboard ports, one parallel port, two serial
ports, ATX power connector, one Sound Blast Link connector, and much, much more!
The BD100 Plus has speed, convenience, and reliability, all wrapped up in one outstanding
motherboard. The BD100 Plus is ahead of the pack. There is no other motherboard quite like it.
Iwill: Lead the way into the 21st century!
6
YEAR 2000 issue
The IBM compatible PC utilizes a Motorola MC146818 compatible Real-Time Clock (RTC) chip to
maintain the date and time. Unfortunately, the “century”is not manipulated by the RTC. It uses 8-
bits of information to report the year and can only hold the last two digits of a year in packed BCD
format. For example, 1997 is reported solely as 97. Since the RTC also contains non-volatile
memory, IBM specified a location in the memory to hold “century”information. By combining the
century data with the year data, software can obtain a full 4-digit year. When the Year 2000 occurs,
the RTC reports the year as ’00’and the “century”in RTC memory will contain ’19.’Combining the
full 4-digit year yields 1900, not 2000. Any applications which compare dates, or uses relative dates
to perform functions will see incorrect dates.
All motherboards contain BIOS, which is one of the key ingredients to check for systems designed to
handle the year 2000. All motherboards currently shipped from Iwill contain BIOS capable of
handling the year 2000 date correctly. The BIOS contains a feature that checks the least two
significant digits of the year stored in the RTC during each BIOS request (INT 1Ah) to read the date
and, if less than `80', updates the century byte to `20'. This feature enables operating systems and
applications using the BIOS date/time services to reliably manipulate the year as a four-digit value.
Be aware that the BIOS capability alone does not ensure that the system will handle the transition
correctly. Other system components such as the operating system and application software also need
to be able to handle the year 2000 date, and recognize the date format from other sources.
Peripherals and Devices
If you want to improve your system’s I/O performance, choose the latest Iwill SCSI controllers. The
following are some Iwill SCSI controllers you may purchase and use with your BD100 Plus
motherboard:
lSIDE 2930C: a fast SCSI for MO, CD-R, CD-R/W, CD-ROM. This
value/performance SCSI card connects up to 7 devices.
lSIDE 2930U+: a 20MB/Sec. transfer rate. A full function card, supports booting from
hard disk or CD-ROM, connects 7 devices
lSIDE 2935UW: 40 MB/sec transfer rate, 15 devices. The most stable product for an
efficient system
lSIDE 2935LVD: an 80MB/sec transfer rate, and a 12-meter cable length connecting 15
devices. Perfect solution for enthusiasts.
7
Chapter 1
Features
1.1 Features
1.1.1 Processor
Supports single Pentium®
III/II/Celeron processors
Supports 100 MHz and 66 MHz bus speeds
Supports all published Pentium®
III/II/Celeron processor voltages
SEC (Single Edge Contact) cartridge Slot 1 connector
Jumper inside selects the processor speed from 233 MHz to 500 MHz or higher
1.1.2 Core Logic
Intel 82443BX PCI/ AGP controller
Integrated DRAM controller
Integrated PCI bus mastering controller
Integrated Accelerated Graphics Port (AGP) bus controller
Intel 82371EB PCI/ISA/IDE Xcelerator (PIIX4E)
Multifunction PCI-to-ISA bridge (PCI Rev 2.1 compliant)
Integrated IDE controller with Ultra DMA/33 support
USB host interface with support for two USB ports
Enhanced DMA controller and standard Interrupt controller and Timer function
System Management Bus (SMB) with support for DIMM Serial PD
1.1.3 Main Memory
4 x 168-pin DIMM (Dual Inline Memory Module) sockets
Supports up to 1 GB of 3.3 V Unbuffered SDRAM or Registered DIMM
Supports up to 1 GB of 3.3 V Extended Data Out (EDO) memory.
64-bit data interface with ECC support (SDRAM only)
8
1.1.4 Multi I/O
Winbond W83977 super I/O controller
Note: Several different chips of the W83977 series may be used to support special features.
Supports two floppy disk drives (include 3 Mode drive) and / or QIC-80 tape drive
Supports one multi-mode parallel port
Supports two high speed 16550 FIFO serial ports
Integrated keyboard controller
Integrated PS/2 mouse controller
Supports PS/2 Power-On function
Supports Power Failure Recovery
1.1.5 Expansion slots
1 x ISA slot
4 x PCI slots
1 x shared ISA/PCI slot
1 x AGP slot
1.1.6 Form Factor
Compliance with ATX Version 2.01 specification
Supports ATX power supply connector
Supports the remote on/off switch
Physical dimensions: length: 188 mm / width: 305 mm
1.1.7 Manageability
Winbond W83781 System Hardware Monitor built-in.
Note: Several different chips of the W83781 series may be used to support special features.
Wake on LAN header for use with add-in network interface cards (NICs)
Power failure recovery
Wake on modem
1.1.8 Other features
Award BIOS
Using 2Mbit Flash ROM to provide on-board-upgrade ability without changing components
Plug and Play compatible
Supports Advanced Power Management (APM)
Supports ACPI (Advanced Configuration Power Interface)
Supports Creative SB-LINK to deliver Sound Blaster 16 compatibility
9
1.2 Environment Requirements
Temperature 0-55 degrees C (operating or storage)
5% to 95% non-condensing relative humidity
At least a 250 W power supply
The power supply must comply with the following recommendations found in the specifications:
The potential relation between 3.3 VDC and +5 VDC power rails
The current capability of the +5VSB line
All timing parameters
10
1.3 Motherboard Components Placement
The following figure shows the location of the components on the BD100 Plus motherboard.
FAN1
AGP
FAN3
IDE0
IDE1
S2
S1
LPT
SLOT1
USB
MS
KB
J21,J22
JP5
PWR ON
PWR
DIMM0~3
FDC
J43
IR
1
NC
NC
VCC
IRRX
GND
IRTX
IRMODE
7
GND
+12V
SENSE
1
3
1--2:Normal
2--3:Clear CMOS
1
3
JP1
SB-LINK
GNT#
1
3
6
4
GND
REQ#
GND
SIRQ
1
1
1
1
PCIx
1
1
LID-ON
GND
5VSB
1
3
WOL
FAN2
Tmp2
1
10
11
20
RST ALED
KL
SPKR
Cathode-
Anode+
Reset
GND
VCC
Cathode-
NC
Anode+
Buzz
GND
Keylock
GND
NC
PLED
ACPI LED
Anode+ Cathode-
1
JP10
JP9
J52
JP11
JP42
Table des matières
Autres manuels IWILL Carte mère
IWILL
IWILL P4G Series Manuel utilisateur
IWILL
IWILL P55TU Manuel utilisateur
IWILL
IWILL P4SE Series Manuel utilisateur
IWILL
IWILL kv200 Manuel utilisateur
IWILL
IWILL VD133 Manuel utilisateur
IWILL
IWILL DS133R Manuel utilisateur
IWILL
IWILL KK400 Series Manuel utilisateur
IWILL
IWILL DPX2-S320 Manuel utilisateur
IWILL
IWILL K7S2 Series Manuel utilisateur
IWILL
IWILL DK8N Manuel utilisateur
IWILL
IWILL DP400 Manuel utilisateur
IWILL
IWILL P4R533 Manuel utilisateur
IWILL
IWILL DX400-SN Manuel utilisateur
IWILL
IWILL IWILL P4D-N Manuel utilisateur
IWILL
IWILL P55TV Manuel utilisateur
IWILL
IWILL piils Manuel utilisateur
IWILL
IWILL P4DA Manuel utilisateur
IWILL
IWILL DN800-SATA Manuel utilisateur
IWILL
IWILL DPIILS2 Manuel utilisateur
IWILL
IWILL DH800 Manuel utilisateur
Manuels Carte mère populaires d'autres marques
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Manuel utilisateur
Gigabyte
Gigabyte GA-9IVDT Manuel utilisateur
Texas Instruments
Texas Instruments ADS8372EVM Manuel utilisateur
Commell
Commell MS-C73 Manuel utilisateur
IBT Technologies
IBT Technologies MB860 Manuel utilisateur
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manuel utilisateur
