IOGear GCS661U Manuel utilisateur

GCS661U

USB Laptop KVM Switch

Installation

Installation Guide

Table of Contents

Table of Contents 3

Package Contents 4

System Requirements 5

Overview 6

Before You Start 7

Software Installation 8

Hardware Installation 13

Operation 16

USB 2.0 Peripheral Port 17

Fullscreen Mode 18

File Transfer Utility 19

Firmware Upgrade 23

FCC Statement 25

CE Statement 27

SJ/T 11364-2006 28

Limited Warranty 29

Contact 30

Package Contents

1 x USB Laptop KVM Switch

1 x Carrying Pouch

1 x Installation Guide

1 x Warranty Card

System Requirements

Computers

A USB 2.0 Type A port from the Master Computer*•

A USB 2.0 Type A port from the Slave Computer**•

Operating System

Windows XP•

Windows Vista (32-bit / 64-bit)•

Windows 7•

*The term “Master Computer” will be shown throughout the Installation guide. “Master Computer” refers to

the computer that you will be using as the Console – Monitor, keyboard and mouse.

**The term “Slave Computer” will be shown throughout the Installation guide. “Slave Computer” refers to

the computer that is being accessed remotely by the Master Computer.

Overview

USB 2.0 Connection for the Slave Computer (longer)1.

LEDs2.

USB 2.0 Connection for the Master Computer (shorter)3.

USB 2.0 Peripheral Port for Master Computer4.

1 32 4

Before You Start

If you wish the Slave Computer to be ready for access every time after booting up or after GCS661U is

plugged in without the present of a monitor, keyboard and mouse connected to the Slave Computer, the

following procedures are required:

Remove all user accounts besides the one that you will be using to access from the Master Computer.1.

Disable login password on the Slave Computer.2.

Install Laptop KVM Remote Software onto the Slave Computer. Please refer to the Software Installation3.

section for details.

Software Installation

Note: Please make sure the USB connection that has the word “Remote” is connected to the Slave

Computer before you can proceed with the software installation.

Step 1

Go to My Computer folder and locate the GCS661U, which is shown as a CD Drive. (In this example, it

is F Drive)

Step 2

Right click on the GCS661U drive and click on

Explore.

Step 3

Double-click on Laptop KVM Remote Setup to

begin the software installation process.

Step 4

A Window may popup to ask you to grant the

access for installation, simply click Allow to

continue.

Step 5

The initial setup screen will then popup, simply

click next to proceed.
