IOGear GCS22U Manuel utilisateur

www.iogear.com

GCS22U / GCS24U

PART NO. Q1060-b / Q1084-b

Quick Start Guide

2/4-Port USB Cable KVM Switch

1 x 2/4-Port USB Cable KVM Switch

1 x Quick Start Guide

1 x Warranty Card

Package Contents

System Requirements

Console

• 1 VGA display

• 1 set of USB keyboard and mouse

Computers

• 1 VGA port

• 2 USB ports

Operating Systems

• Windows®7, Windows®8.1, Windows®10

• Mac OS®9 or greater

• Oracle®Solaris

• Linux®, Unix, and other USB supported systems*

*Additional drivers and support may be needed

1. Console USB Mouse Port

2. Console VGA Monitor Port

3. LEDs

4. Console USB Keyboard Port

5. Remote Switch Button

6. CPUs KVM Cables

Overview

2 3 4

2 sets for GCS22U

4 sets for GCS24U

2 for GCS22U

4 for GCS24U

Installation

Step 1

Please make sure your computers and monitor are powered

OFF before you start.

Step 2

Connect the VGA cable from your monitor to the console

VGA monitor port.

Step 3

Connect your USB keyboard and mouse to the console USB

keyboard port and console USB mouse port.

Step 4

Connect a set of your molded KVM cable to each of your

computers – VGA cable to the VGA output and USB

cables to open USB ports from your computer.

Simply press the remote port switching button to switch to

the next port.

LED will light up in green showing the port that is selected.

Final Step

Turn on your computers.

Port Switching

LED Indication

FCC Statement

This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential setting.

This product generates, uses, and can radiate radio frequecy

energy and, if not installed and used as directed, it may cause

harmful interference to radio communications. Although this

product complies with the limits for a Class B digital device,

there is no guarantee that interference will not occur in a

particular installation.

CE Compliance

This device has been tested and found to comply with the

following European Union directives: Electromagnetic

Capability (2004/108/EC), Low Voltage (2006/95/EC) and

R&TTED (1999/5/EC).

Compliance Information

Warranty

Warranty Information

This product carries a 3 Year Limited Warranty. For the terms

and conditions of this warranty, please go to

http://www.iogear.com/support/warranty

Important Product Information

Product Model

Serial Number

Contact

WE’RE HERE TO HELP YOU!

NEED ASSISTANCE SETTING UP THIS PRODUCT?

Make sure you:

1. Visit www.iogear.com for more product information

2. Visit www.iogear.com/support for live help and

product support

IOGEAR

iogear.custhelp.com

support@iogear.com

www.iogear.com

15365 Barranca Parkway, Irvine 92618
