Invacare 1073913 Instructions de montage

Part No 1143248 121” Arm Pad for Walker Platform Attachment

For more information regarding Invacare products, parts, and services,

please visit www.invacare.com

21” Arm Pad for Walker Platform Attachment

Model Nos. 1073913

NOTE:CheckALLpartsforshippingdamage.Ifshippingdamageisnoted,DONOTuse.Contact

carrier/dealerforfurtherinstruction.

ArmpadsinstalledontheWalkerPlatformAttachmentmodel6027maynotbesuitable

forallarmsizes.Invacarerecommendsreplacingtheexisting17”semi‐adjustablearm

padwiththe21”fullyadjustablearmpad.

Safety Summary

Toensurethesafeandproperinstallationofthewalkerplatformattachment,these

instructionsMUSTbefollowed:

 WARNING

DO NOT install this equipment without first reading and understanding this instruction

sheet. If you are unable to understand the warnings, cautions and instructions, contact a

healthcare professional, dealer or technical personnel if applicable, before attempting

to install this equipment - otherwise, injury or damage may occur.

Ensure that ALL attaching hardware is secure.

Invacare products are specifically designed and manufactured for use in conjunction

with Invacare accessories. Accessories designed by other manufacturers have not

been tested by Invacare and are not recommended for use with Invacare products.

 INSTALLATION WARNING

After ANY adjustments, repair or service and BEFORE use, make sure that all

attaching component parts are secure.

Installing the Arm Pad and Strap

NOTE:Forthisprocedure,refertoFIGURE 1.

1. Removearmpadandcover.

NOTE:Notetheorientationoftheexistingarm

strapforinstallationofthenewarmstrap.

2. Pullonringandremovefasteningstrap

throughtheslotsinthearmsupport.

3. Threadtheendwithouttheringofthe

newarmstrapthroughslotsinthearm

support.

NOTE:Makesurethehookendisfacingdown

orthearmstrapwillnotsecureproperly.

4. Slidethearmpadandcoveroverthearm

support. FIGURE 1 Installing the Arm Pad and Strap

Assembly, Installation and Operating Instructions

SAVE THESE INSTRUCTIONS

Arm

Support

Fastening

Strap

Ring

Slots

NOTE:Armpadremovedforclarity.

Securing the Arm Strap

NOTE:Forthisprocedure,refertoFIGURE 2.

1. Unfastenarmstrapbypullinguponthehookandloopfasteningstrap.

2. Loosenarmstrapbypullingthroughring.

3. Slidearmintoposition.

4. Pullfasteningstrapuntilasnugfitisobtained.

5. Foldthehookandloopfasteningstrapoverringandsecuretoarmstrap.

FIGURE 2 Securing the Arm Strap

Arm

Pad

Arm Strap

Ring

Fastening Strap

(hidden from view)

Invacare Corporation www.invacare.com

USA

One Invacare Way

Elyria, Ohio USA

44036-2125

800-333-6900

Canada

570 Matheson Blvd E Unit 8

Mississauga Ontario

L4Z 4G4 Canada

800-668-5324

Invacare, Yes, you can. and the Medallion

Design are registered trademarks of

Invacare Corporation.

PRODUCT MADE

IN CHINA

Part No 1143248

Rev A - 9/26/06
