Intermec EasyCoder 401 Manuel utilisateur

EasyCoder 401

Fan Fold Kit

P/N 1-960391-02

Edition 3

September 1998

Installation Instructions

EasyCoder 401 – Installation Instructions

EasyCoder 401

Fan Fold Kit

Installation Instructions

Edition 3, September 1998

Part No. 1-960391-02

Description

FAN FOLD KIT

Inadditiontotheinternalpaperroll,theEasyCoder401printerscan

also use thermal paper or receiving face material from an external

supply, e.g. an external paper roll or a stack of fan-folded tickets.

The paper is inserted into the printer through either the upper or

lower slot in rear plate.

Itisimportantthatthepaperwebisproperlyalignedinparallelwith

theprinter'scentre-linewall.Therefore,Intermecoffersanoptional

“Fan Fold Kit” consisting of:

• 1 Fan Fold Guide

• 1 Inner Guide

• 1 Outer Guide

• 2 Screws MRT 4 ×6 FZB

The kit also contains two guide shafts, each consisting of:

• 1 Break Shaft

• 2 Guide Rolls

• 1 Screw MRT 4

8 FZB

Theseguideshaftsareincludedforuseinotherprintermodelsthan

EasyCoder 401 and can be discarded.

Continued!

EasyCoder 401 – Installation Instructions

FAN FOLD KIT, cont'd.

Description, cont'd.

IMPORTANTPRINTHEADANDRIBBONINFORMATION

The use of any thermal transfer ribbons, other than those supplied by UBI, will invalidate

the printhead warranty. UBI thermal transfer ribbons are engineered specifically for this printhead.

The quality of thermal and thermal transfer media supplies in this printer is also of great importance

for the quality of printing bar codes and a long life of the printhead. UBI has carefully matched the

paper werecommend/provide to the needs of this printer. We therefore strongly advise of using

only UBI recommended/provided supplies to ensure a high quality printing.

TEAR-OFF

401

Fan Fold Guide assy.

Theguide bracketwith itstwo guidesis assembledbefore delivery

and can be fitted in the upper slot in the rear plate by means of two

screws. The outer guide is adjustable for different paper widths.

Note:

The lower slot in the rear plate can only be fitted with a fan fold

guideafterthecrescent-shapedguideplateinsidethepapersupply

roll has been removed.

EasyCoder 401 – Installation Instructions

The guide bracket with the two guides can be fitted either at the

upper slot in the rear plate.

Insertthecompleteunitthroughtheslotfromtheoutsideandattach

it to the rear plate by means of the two #T20 Torx screws included

in the kit.

Adjust the position of the outer guide to fit the width of the paper.

Installation –

Fan Fold Guides

FAN FOLD KIT, cont'd.

Continued!

EasyCoder 401 – Installation Instructions

Load the paper web according to the illustration below. Note that

the external supply should be protected from dust, sand, git and

otherparticlesthatmaydamagetheprintheadorimpairtheprintout

quality.

Paper Load Instructions

FAN FOLD KIT, cont'd.

Information in this manual is subject to change without prior notice and does

not represent a commitment on the part of Intermec Printer AB.

©CopyrightIntermecPTCAB,1998.Allrightsreserved.PublishedinSweden.

EasyCoder is a registered trademark of Intermec Technologies Corp.

Torx is a registered trademark of Camcar Division of Textron Inc.
