Intermec Oracle-Ready CK31 Manuel

CK31 Handheld Computer Operator’s Guide

Battery

latch























































































  

�















You should use this operator’s guide if you use the CK31 daily to perform your job. This guide contains basic operating information to help you use

the CK31.

Turn on the CK31.

Press I (the Power key) to turn on the CK31.

When you turn on the CK31, the screen turns on.

If the screen does not turn on, install a charged

battery.

Check the battery level.

Change beeper volume.

Scan a bar code.

Point the CK31 at the bar code.

Press the Scan button or pull the trigger.

If your CK31 has a laser scanner, a red spot or narrow

beam of light appears near the bar code.

If your CK31 has an imager, a wide beam of light appears

near the bar code.

Move the CK31 so the spot or beam is centered on the bar

code. When the Good Read light turns on, the bar code

has been scanned.

Press I to turn o the

CK31.

Press down on the latch

and lift the battery out of

the CK31.

Insert the tabs on the

new battery into the

bottom of the opening.

Press the battery in

place to snap the latch.

Press and release C (the Green key), and then press

and release E to change the beep volume.

If the battery is low, change it.























Turn on the backlight.

Press E (the Backlight key) to turn on the

backlight. The backlight makes the screen

easier to see in dark areas.

Depending on the kind of scanner your CK31 has, you may

need to move the CK31 closer to or farther from the bar code.

6001 36th Avenue West

Everett, Washington 98203

U.S.A.

tel 425.348.2600

fax 425.355.9551

www.intermec.com

CK31 Handheld Computer Operator’s Guide

*075388-001*

P/N 075388-001

Icons appear on

the screen when

the battery is

not fully charged.

CK31 Handheld Computer Operator’s Guide

Using the Screen Icons

While you use the CK31, icons appear at the bottom of the screen to help you keep track of the battery and network connections. See the next table

to learn what the icons mean.

Icon Means

Battery is half full. You should be able to work for several more hours before changing batteries.

Battery is almost empty. You need to install a charged battery as soon as possible.

Battery is empty. Install a charged battery right away!

Excellent radio connection to the network.

Good radio connection to the network. You might need to move to get a better connection.

Bad radio connection to the network. Try moving until you get a better connection.

No radio connection to the network. You need to move until you get reconnected.

You pressed the Orange key.

You pressed the Green key.

Orange key is locked. Press the Orange key again to unlock it.

Green key is locked. Press the Green key again to unlock it.

Using the Keypad

See the next illustration to nd the locations of the Power (I), Backlight (E), Orange (B), Green (C), Backspace, and Esc keys on your CK31.

More Information

For more information on operating the CK31, see the CK31 Handheld Computer Quick Start Guide (P/N 075205) or the CK31 Handheld Computer User’s

Manual (P/N 075207).



































Backspace

key

7 8 9

1 2

456

C D

H I

M N



I /




























