Environmental

Operating Temperature: -20°C to +50°C (-4°F to +122°F)

Storage Temperature:-30°C to 70°C (-22°F to +158°F)

Relative Humidity: 5% to 95%

DEX Connector Pinouts

CK60 DEX Snap-On Adapter (AA4) Instructions

*962-032-011C*

P/N 962-032-011C CK60 DEX Snap-On Adapter (AA4)

Pin Number I/O to Computer Description

Ring O RS-232 Transmit data

Tip IRS-232 Receive data

Sleeve PWR Signal Ground

Specifications

Instructions

Worldwide Headquarters

6001 36th Avenue West

Everett, Washington 98203

U.S.A.

tel 425.348.2600

fax 425.355.9551

www.intermec.com

© 2010 Intermec Technologies

Corporation. All rights reserved.

After you remove the CK60 Handheld Computer DEX Adapter (Model AA4) from the

shipping box, save the box and packing material in case you need to ship or store the

device. The CK60 DEX adapter shipping box should contain these items:

• CK60 DEX adapter

• CK60 DEX adapter instructions

• Compliance insert

DEX/UCS is an industry standard for electronic transfer of invoice information between the

supplier’s mobile computer and the retailer’s in-store receiving system. The transfer takes

place through a DEX adapter cable.

The DEX Snap-On Adapter allows quick and easy attachment of the DEX cable to the CK60

Handheld Computer. Two metal guides ensure proper alignment of the adapter to the

handheld computer; spring clips hold the adapter securely in place while the handheld

computer is carried around the store.

A power connector on the DEX adapter allows connection of an external power supply to

the CK60 without removing the adapter.

You must remove the DEX adapter from the CK60 if you want to place the handheld

computer in a dock.

To attach the DEX adapter:

• Align metal clips with guides on either side of the CK60 handheld computer and press

firmly. The adapter latches into place.

To remove the DEX adapter:

• Squeeze the finger grips on both sides of the DEX adapter to disengage clips and pull

the DEX adapter away from the handheld computer.

Out of the Box

What is the CK60 DEX Adapter?

CK60 DEX Adapter Features

Metal clips (one on each side)

DEX cable

Slide DEX adapter

onto CK60

Power connector
