Intellinet 523530 Manuel utilisateur

INT-523530/523523-UM-0107-01

16/24-PORT

GIGABIT ETHERNET

DESKTOP SWITCH

USER MANUAL

MODEL 523530/523523

Thank you for purchasing this INTELLINET NETWORK SOLUTIONS™ Gigabit Ethernet Desktop

Switch, Model 523530 (16-port) or Model 523523 (24-port).

With its 10/100/1000 Mbps gigabit ports, this switch easily boosts networking throughput,

providing a real gigabit connection that makes it possible to transfer large, high-bandwidth ﬁles

with greater speed and reliability. The store-and-forward architecture ﬁlters errors and forwards

packets in a non-blocking environment. Flow control ensures the correctness of data being

transmitted. And the 802.3x and back-pressure ﬂow-control mechanisms work, respectively, for

full and half duplex modes.

The switch is designed for easy installation and maintenance. It supports NWay auto-negotiation

protocol that automatically detects the networking speed (10/100/1000 Mbps) and the

duplex modes (full/half). The Auto-MDI/MDI-X function alleviates the need to use crossover

cables, and rich diagnostic LEDs indicate real-time connection status.

Additional features include:

• Support of jumbo frames up to 9 kBytes

• Rugged metal housing for maximum durability

• Support of up to 8192 MAC address entries

• 19” rackmount brackets

• Lifetime Warranty

FCC STATEMENTS

FCC Warning

This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference when the equipment is operated in a commercial environment. This

equipment generates, uses and can radiate radio frequency energy and, if not installed and

used in accordance with the instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is likely to cause harmful

interference, in which case the user will be required to correct the interference at his own expense.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: 1) This device may not cause harmful interference and 2) This device must accept

any interference received, including interference that may cause undesired operation.

CE Mark Warning

This equipment complies with the requirements relating to electromagnetic compatibility, EN 55022

class A for ITE, the essential protection requirement of Council Directive 89/336/EEC on the

approximation of the laws of the member states relating to electromagnetic compatibility.

FRONT PANEL

REAR PANEL

Power receptacle: Plug the female end of the power cord ﬁrmly into the receptacle and the

other end into an electrical outlet. Conﬁrm that the power LED is lit for a normal power status.

Ports: All the ports on the Gigabit Ethernet Desktop Switch support Auto-MDI/MDI-X functionality.

• Crossover or straight-through cables can be used to connect to PCs, routers and other devices.

• Cat5/5e UTP/STP cables provide optimal performance.

System LED Status Operation

PWR Steady green Power on

Port LEDs Status Operation

1000M Steady green Valid port connection at 1000 Mbps

Blinking green Valid port connection; data being transmitted/received

Off Port disconnected or connected at 10/100 Mbps

10/100M Steady green Valid port connection at 10/100 Mbps

Blinking green Valid port connection; data being transmitted/received

Off Port disconnected or connected at 1000 Mbps

• The Auto-negotiation feature allows each port to operate in both half and full duplex mode at

10 Mbps and 100 Mbps; and at full duplex mode at 1000 Mbps.

INSTALLATION

Prior to use, it is recommended that the device be placed/positioned:

• with a minimum of 25 mm of clearance on the top and sides for adequate ventilation

• away from sources of electrical noise, such as radios, transmitters and broadband ampliﬁers

• where it cannot be affected by excessive moisture

Desktop:

1. Attach the included rubber feet to the bottom of the device to keep it from slipping. The

recommended positions are marked.

2. Place the device on a level surface that can support the weight of the switch (and any other

items that need to be considered).

Media Speed Recommended cable

10/100/1000 Mbps copper 10 Mbps Cat3/4/5 UTP/STP

100 Mbps Cat5 UTP/STP

1000 Mbps Cat5/5e UTP/STP

Rackmount:

1. Disconnect any cables from the switch before proceeding with rackmounting.

2. Place the device on a hard, ﬂat surface with the front facing you.

3. Position one of the two included mounting brackets over the mounting holes on one side of the unit.

4. Insert the screws and fully tighten them with a suitable screwdriver.

5. Repeat the two previous steps for the other side of the device.

6. Insert the switch into the rack (secure with suitable screws, if desired); reconnect cables as needed.

SPECIFICATIONS

Standards & Certiﬁcations

• IEEE 802.3 (10Base-T Ethernet); IEEE 802.3u (100Base-TX Fast Ethernet); IEEE 802.3ab

(Twisted Pair Gigabit Ethernet); IEEE 802.3x (ﬂow control, for full duplex mode)

• Certiﬁcations: FCC Class A, CE Mark, VCCI Class A, RoHS

General

• Media support: 10Base-T Cat3, 4, 5 UTP/STP RJ-45; 100Base-TX Cat5 UTP/STP RJ-45;

1000Base-T Cat5e UTP/STP RJ-45

• Packet ﬁlter/forwarding rates: 1,488,000 pps (1000 Mbps); 148,800 pps (100 Mbps);

14,880 pps (10 Mbps)

• Buffer memory: 340 kBytes for 16-port; 500 kBytes for 24-port

• MAC address table: 8192 entries

• Backplane speed: 32 Gbps for 16-port; 48 Gbps for 24-port

• Switch architecture: store and forward

LEDs

• Power

• Link/Act: 1000 Mbps, 10/100 Mbps

Power

• Internal power supply, 100 to 240 V AC, 50/60 Hz

• Power consumption: 14.4 Watts (maximum) for 16-port; 20.9 Watts (maximum) for 24-port

Environmental

• Metal housing, 1 U

• Dimensions: 266 (W) x 185 (L) x 44 (H) mm (10.4 x 7.3 x 1.7 in.); weight: 2.2 kg (4.9 lbs.)

• Operating temperature: 0 – 40°C (32 – 104°F); operating humidity: 10 – 90% RH, non-condensing

• Storage temperature: -10 – 70°C (-14 – 158°F)

Package Contents

• Gigabit Ethernet Desktop Switch

• Power cable

• Rackmount brackets (2) with screws

• User manual

Are you completely satisﬁed with this product?

Please contact your INTELLINET NETWORK SOLUTIONS™ dealer

with comments or questions.

SOLUTIONS

All products mentioned are trademarks or registered trademarks of their respective owners.

www.intellinet-network.com
