Intel I815E Manuel utilisateur
I815E
Socket 370
Intel 815E Little Board
USER’S MANUAL
Version 1.1
ii I815E User’s Manual
Acknowledgments
Award is a registered trademark of Award Software International,
Inc.
PS/2 is a trademark of International Business Machines
Corporation.
Intel and Celeron are registered trademarks of Intel Corporation.
Microsoft Windows is a registered trademark of Microsoft
Corporation.
Winbond is a registered trademark of Winbond Electronics
Corporation.
All other product names or trademarks are properties of their
respective owners.
I815E User’s Manual iii
Table of Contents
Introduction...............................................................1
Product Description..........................................................1
Checklist...........................................................................2
Specifications....................................................................3
Board Dimensions.............................................................4
Installations ..............................................................5
Installing the CPU.............................................................6
Installing the Memory (DIMM) .........................................7
Setting the Jumpers...........................................................8
Connectors on I815E.......................................................12
BIOS Setup..............................................................25
Drivers Installation.................................................47
Appendix.................................................................75
A. I/O Port Address Map.......................................................75
B. Interrupt Request Lines (IRQ) .........................................76
iv I815E User’s Manual
A picture of the I815E Embedded Board
INTRODUCTION
I815E User’s Manual 1
Introduction
Product Description
I815E is a high-performance flexible embedded board based on the Intel
815E chipset that contains the Graphics and Memory Controller Hub
(GMCH), the I/O Controller Hub (ICH2) and the Firmware Hub (FWH).
It supports 66/100/133MHz system bus, up to 1.4GHz CPU speed,
integrated 2D/3D graphics accelerator, and PC100/PC133 SDRAM
modules. With the ICH2, it is able to support UDMA33/66/100, four
USB ports, and integrated LAN.
System memory is provided by one 168-pin DIMM socket that
accommodates SDRAM with a maximum capacity of 256MB. The
Award BIOS facilitates easy system configuration and peripheral setup.
Other advanced features include four USB ports, 256-level watchdog
timer (supported by LPC I/O IT8712), and IrDA interface.
INTRODUCTION
2I815E User’s Manual
Checklist
Your I815E package should include the items listed below.
•The I815E Embedded Little Board
•This User’s Manual
•1 IDE Ribbon Cable
•1 Floppy Ribbon Connector
•1 CD containing the following:
•Chipset Drivers
•Flash Memory Utility
INTRODUCTION
I815E User’s Manual 3
Specifications
Processor
Supported Socket 370 for Intel Celeron / Pentium III (FC-PGA),
533MHz~1.4GHz, 66/100/133MHz Bus Speed
Chipset Intel 815E Chipset
GMCH: 82815 544-PIN BGA
ICH2: 82801BA 360-PIN BGA
FWH
BIOS Award BIOS; supports ACPI
System Memory 1x DIMM socket supports up to 256MB capacity
PC100/PC133 DIMM modules supported
LPC I/O Chipset ITE IT8712 (keyboard controller is built-in)
I/O Features 1x FDD (up to 2.88MB, 3 Mode, LS120)
1x Parallel Port (EPP, ECP Port)
2x Serial Ports (1x RS232 and 1x RS232/422/485)
1x IrDA TX/RX Headers
Bus Master IDE 2x IDE interfaces for up to 4 devices; supports PIO Mode
3/4 or UDMA33/66/100 HDD, and ATAPI CD-ROM
VGA 815E integrated graphics
Shared memory
4MB display cache on board
VGA CRT connector on board
Pin header for optional TV-Out (CH7007) daughter board
with S-Video & RCA jacks
Audio ICH2 integrated audio with AC97 codec
LAN ICH2 integrated Ethernet controller
10Base-T / 100Base-TX protocol
Primary RJ-45 Ethernet connector on board
Secondary LAN
(Optional) Optional Intel 82559 Ethernet controller
10Base-T / 100Base-TX protocol
Optional Secondary RJ-45 Ethernet connector on board
USB Two USB ports on board
Another two USB ports supported by USB pin header
IrDA Pin header
Hardware
Monitoring Built-in IT8712
Monitors CPU/system temperature and voltages
Watchdog Timer
256-level Watchdog timer
P/S Connector ATX type power supply connector
Rear Side
Connectors PS/2 keyboard, PS/2 mouse, Primary RJ45 connector;
optional secondary RJ-45 connector, printer port, VGA
CRT, USBx2, serial Port, Microphone, speaker
Form Factor 5.25-inch SBC (Little Board)
Dimensions 203mm x 146mm (7.99” x 5.75”)
INTRODUCTION
4I815E User’s Manual
Board Dimensions
INSTALLATIONS
I815E User’s Manual 5
Installations
This section provides information on how to use the jumpers and
connectors on the I815E in order to set up a workable system. The topics
covered are:
Installing the CPU.............................................................6
Installing the Memory (DIMM) .........................................7
Setting the Jumpers...........................................................8
Connectors on I815E.......................................................12
INSTALLATIONS
6I815E User’s Manual
Installing the CPU
The I815E board supports a Socket 370 processor socket for Intel
Pentium III and Celeron processors.
The Socket 370 processor socket comes with a lever to secure the
processor. Raise this lever to about a 90°angle to allow the insertion of
the processor. Place the processor into the socket by making sure the
notch on the corner of the CPU corresponds with the notch on the inside
of the socket. Once the processor has slide into the socket, return the lever
to the lock position. Refer to the figures below.
After you have installed the processor into the socket, check if the
jumpers for the CPU type and speed are correct.
NOTE:
Ensure that the CPU heat sink and the CPU top surface are in
total contact to avoid CPU overheating problem that would
cause your system to hang or be unstable.
