1-1 FeatureofMotherboard

lIntel®H310/H370 express chipset

lLGA1151 CPUsocketsupportsIntel®Coffee Lake-Sseriesprocessor(TDP ≤65

W).

lSupport 2*DDR42400MHzSO-DIMM up to32GBand dualchannelfunction

lSupport 1*Inteli219-VGigabit Ethernet LANchip

lSupport USB 3.1datatransportdemand

lSupport 2*SATAIII (6Gb/s)ports

lSupport1*PCIEx1slot, 1*M.2E-key2230 PCIeslotand1*M.2M-key

2242/2260/2280slot

lSupport 1*HDMI +1*DP+1*LVDS(option witheDP)

lSupport 1*COM, optional4/6*USB 3.1&4*USB 2.0forrichIO expansion

lSupport Smart FANfunction

lSupportsACPI S3Function

lCompliancewithErPStandard

lSupportWatchdog TimerTechnology

1-2 Specification

Spec

Description

Design lThinmini-ITXformfactor;PCBsize: 17.0x17.0cm

Chipset lIntel H310/H370 Express Chipset

CPUSocket lIntel

LGA1151 Socket forCoffee Lake-Sseriesprocessors

*Note: fordetailed CPUsupport information pleasevisitourwebsite

MemorySlot

DDR

DIMMslot

lSupport DDR4 2400/2666 MHzSO-DIMMup to32GB

lSupport dualchannel function

ExpansionSlot

1* PCIEx1

slot (

)

l1* M.2PCIEslot(M2E,2230 E-keyPCIEinterface)

Storage

*SATAIII 6G/sport

(SATA

)

l1* M.2M-keyslot,type-2242/2260/2280 withSATAinterface(

M2M

*SATA/PCIEinterface)

*Note: PCIE signal issupported byNF893-H370 seriesonly.

LANChip lIntegrated with1* Intel i219-V GigabitPCI-ELANchip

lSupport Fast Ethernet LANfunction ofproviding 10/100/1000Mbps

Ethernet datatransferrate

AudioChip lRealtekALC662-VD4-channel AudioCodecintegrated

lAudiodriverand utilityincluded

BIOS lAMIFlashROM

Multi I/O

Rear Panel I/O:

l1*19VDC-inPowerJack

l4* USB 3.1(Gen.1)port (Optional for NF893-H310 Series)

l4* USB 3.1(Gen.2)port (Optional for NF893-H370 Series)

l1* HDMI port

l1* DPport

l1* RJ-45 LANport

l1* Line-out port

l1* MICport

Internal I/OConnectors&Headers:

l1*2-pin19Vinternal powerconnector

l1* CPUFANconnector&1* SYSFANconnector

l1* SATAPower-out connector

l1* MON_SWconnector

1* Front panel header

l1* PS/2keyboard&mouseheader

l1* Serialportheader

l1* GPIO header

l2* 9-PinUSB2.0headerfor4* USB2.0ports

l1* 19-PinUSB3.1(Gen.2)headerfor2* USB3.1(Gen.2)ports(Optional

for NF893-H370 Series)

l1*Front panelaudioheader

l1* DMIC_CONdigital microphone header

l1* Speakerheader

l1* PN_LEDheader(forLANactivityLED/BluetoothactivityLED/

WIFI

activityLED)

l1* LVDSconnector(Default)or1* EDPconnector(Optionalbyorder)

l1*Inverterheader

1-3 LayoutDiagram

RearIODiagram

*Note: NF893-H310 seriescomewith 4* USB3.1(Gen.1) portswhichsupports5Gpsdatatransfer

rate; NF893-H370 seriescomewith 4* USB3.1(Gen.2) portswhichsupports10Gpsdatatransferrate

MIC Port

Line-OutPort

RJ-45 LANPort

Display Port

HDMIPort

USB3.

Ports

19VDC

Power Jack

MotherboardInternalDiagram-Front

NF893-H310 Series:

LGA 1151

CPUSocket

H310Chipset

DDR

SODIMMSlots

(SODIMM1/2)

LANPort

Line

Out

Port

MIC

Port

HDMI

Port

Display

Port

USB3.1

(Gen.1)Ports

19VDC

PowerJack

Internal 19VDC

PowerConnector

SATAIIIPorts

(SATA1/2)

SYSFAN

Connector

CPUFAN

Connector

FrontPanel

Header

Inverter

USB2.0Port

Header

USB2.0Port

Header

GPIOHeade

M.2M-Key Slot

(M2M)

PS2KBMSHeader

M.2E-Key Slot

(

M2E

)

FrontPanel

Audio

Header

CIEX1Slot

(PCI

SPEAK_CON

Header

DMIC_CON

Header

PN_LED

Header

SATAPower

Connector

(SATAPWR)

LVDS

Connector

(Optionalwith

EDP)

MON_SW

Header

SerialPort

Header

NF893-H370 Series:

*Note: The productdiagrams areforillustration purposeonlyand mostlycomefrom Model

NF893-H370, unless otherwisenoted.

LGA 1151

CPUSocket

H370Chipset

DDR

SODIMMSlots

(SODIMM1/2)

LANPort

Line

Out

Port

MIC

Port

HDMI

Port

Display

Port

USB3.1

(Gen.2)Ports

19VDC

PowerJack

Internal 19VDC

PowerConnector

SATAIIIPorts

(SATA1/2)

SYSFAN

Connector

CPUFAN

Connector

FrontPanel

Header

USB2.0Port

Header

USB2.0Port

Header

GPIOHeader

SerialPort

Header

M.2M-Key Slot

(M2M)

PS2KBMSHeader

M.2PCIESlot

(

M2E

)

FrontPanel

Audio

Header

PCIEX1Slot

(PCI

MON_SW

Header

SPEAK_CON

Header

DMIC_CON

Header

PN_LED

Header

SATAPower

Connector

(SATAPWR)

*USB3.1(Gen.2)

Header

Inverter

LVDS

Connector

(Optionalwith

EDP)
