ULV Intel®Celeron®M 800MHz zero cache with COM ports,

USB 2.0 and TPM Security function support

Enano-8523

Quick Installation Guide

Version 1.0

Mar. 25, 2009

Package Contents

Enano-8523 package includes the following items:

z1 x Enano-8523 single board computer

z1 x PS/2 KB/MS cable

z1 x IDE flat cable

z1 x mini jumper pack

z1 x Utility CD

z1 x QIG (Guick Installation Guide)

Specifications

zCPU: ULV Intel®Celeron®M 800MHz Zero cache processor

zSystem Chipset: Intel®852GM + ICH4

zBIOS: AMI BIOS Label

zSystem memory: 1 x 200-pin DDR 266MHz SO-DIMM SDRAM up

to 1GB

zEthernet: 10/100Base-T dual Intel®82562ET

zI/O

I/O Interface:

4 x USB 2.0

1 x LPT

1 x CFII

4 x RS-232

1 x PS/2 KB/MS

1 x IDE

zSupper I/O: ITE IT8712F-A

zAudio: AC’97 Codec Realtek ALC655

zDisplay:

CRT integrated in Intel®852GM

LVDS

Dual 18-bit LCD integrated in Intel®852GM

Support independent dual display

zWatchdog timer: Software programmable supports 1~255 sec.

system reset

zPower Supply: +5V± 5%, 12V ±5%, 5VSB ATX power support

zPower Consumption:

+5V@3.66A; +12V@ 20mA

(ULV Intel®Celeron®M 800 zero Cache with DDR 266MHz 256MB

RAM)

zTemperature: 0 ~ 60°C( 32 ~ 140°F)

zHumidity: Operation: 5% ~ 95%

zDimension: 115 mm x 165 mm

zWeight: GW: 1100g; NW: 950g

Ordering Information

Standard

Enano-8523-800Z-R10

EPIC on board ULV Intel®Celeron®M 800MHz with zero cache CPU

with LCD/CRT VGA, LAN, USB2.0, Audio, and 4 COM ports

Enano-8523T-800Z-R10

EPIC on board ULV Intel®Celeron®M 800MHz with zero cache CPU

with LCD/CRT VGA, LAN, USB2.0, Audio, 4 COM ports and TPM v1.2

function

Optional:

LPT cable P/N: 32200-015100-RS

Label Connector

IDE1 HDD connector

DIO1 Digital Input Output Connector

BT1 Battery Connector

CN12 Front Panel Connector

COM2 Serial communications connector

USB1 USB 2.0 connector for two USB devices

PCI1 Rev 2.2 PCI slot for PCI card

PW1 Board 12V power connector

PW2 System cooling fan connector

KB_MS1 Keyboard/Mouse connector

CN2 Parallel port connector

CN8 LVDS connector

CN3 Inverter connector

DIMM1 SODIMM slot

CN7 CFII connector

CN1 VGA Connector

CN6 COM1 connector

J5 COM2 and COM3 connectors

J15 Ethernet connector

CN11 Audio connector

JP2 Clear CMOS

JP4 CF card setu

JP6 LCD volta

e setu

Jumpers setting and Connectors

CN12 : System Panel Connectors

PIN DESCRIPTION PIN DESCRIPTION

1-3 POWER LED 2-8 SPEAKER

5-7 PWR BUTTON 10-12 RESET

9-11 HDLED

JP2: Clear CMOS Setup

JP2 DESCRIPTION

1-2(NC) Normal Operation

2-3 Clear CMOS Setup

JP4: CF card setup

JP4 DESCRIPTION

Open Slave(Default)

Close Master

JP6: LCD voltage setup

JP6 DESCRIPTION

1-2 3.3V(Default)

2-3 5V

USB1:2*4 Pin header

PIN DESCRIPTION PIN DESCRIPTION

1 USBVCC2 2 USBGND3

3 D2- 4 D3+

5 D2+ 6 D3-

7 USBGND2 8 USBVCC3

COM4 : COM4(RS-232)

PIN DESCRIPTION PIN DESCRIPTION

1 DCD4 2 DSR4

3 RX4 4 RTS4

5 TX4 6 CTS4

7 DTR4 8 RI4

9 GND 10 GND

FAN1:

3Pin Fan Connector

PIN DESCRIPTION

1 Fan Speed Detect

2 +12V

3 GND

PW2: 5VSBY Power

Connector

PIN DESCRIPTION

1 5VSBY

2 GND

3 PSON

PW1: Big 4P Power

Connector

PIN DESCRIPTION

1 5V

2 GND

3 GND

4 12V

KB_MS1:Keyboard/Mouse

Connector

PIN DESCRIPTION

1 5V

2 MS DATA

3 MS CLK

4 KB DATA

5 KB CLK

6 GND

CN8: LCD LVDS Interface Connector

Pin DESCRIPTION Pin DESCRIPTION

GND

LVDS_Y0+

LVDS_Y0-

LVDS_Y1+

LVDS_Y1-

LVDS_Y2+

LVDS_Y2-

LVDS_CLK+

LVDS_CLK-

LVDS_Y3+

LVDS_Y3-

GND

LVDSB_Y0+

LVDSB_Y0-

LVDSB_Y1+

LVDSB_Y1-

LVDSB_Y2+

LVDSB_Y2-

LVDSB_CLK+

LVDSB_CLK-

LVDSB_Y3+

LVDSB_Y3-

GND

VCC_LCD

CN3: Inverter Power Connector

PIN DESCRIPTION PIN DESCRIPTION

1 VCC12 2 VCC12

3 BKLT_EN 4 BKLT_ADJ

5 GND 6 GND

DIO1: 8 Bits GPIO Connector

PIN DESCRIPTION PIN DESCRIPTION

1 GND 2 VCC5

3 GPIO0 4 GPIO1

5 GPIO2 6 GPIO3

7 GPIO4 8 GPIO5

9 GPIO6 10 GPIO7

Board Layout: Jumper and Connector Locations
