INTEL BX

Dual Pentium II® Mainboard

User's Manual

Copyrig t

No part of this publication may be reproduced, transmitted, transcribed, stored

in a retrieval system, or translated into any language in any form or by any

means, electronic, mechanical, magnetic, optical, manual or otherwise,

without the prior written consent of the copyright holders.

User’s Notice

The contents of this publication are sub ect to change. This company reserves

the right to alter the contents of this publication at any time and without

notice. The contents of this publication may contains inaccuracies or

typographical errors and is supplied for informational use only.

Intel and Pentium are registered trademarks of Intel Corporation.

OS/2 and IBM are registered trademarks of International Business Machines.

Windows and MS-DOS are registered trademarks of Microsoft Corporation.

AWARD is a registered trademark of Award Software Inc.

Other brand, corporate, and product names may or may not be registered

trademarks or copyright of their respective companies.

FCC & & DOC Compliance

Federal Communications Commission Statement

This device complies with FCC Rules Part 15. Operation is sub ect to the

following two conditions:

This device may not cause harmful interference, and

This device must accept any interference received, including interference

that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the

manufacturer’s instructions, may cause harmful interference to radio

communication. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

Re-orient or relocate the receiving antenna.

Increase the separation between the equipment and the receiver.

Connect the equipment to an outlet on a circuit different from that to

which the receiver is connected.

Connect the equipment to an outlet on a circuit different from that to

which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Warning! T e use of s ielded cables for t e connection of t e monitor to

t e grap ics card is required to assure compliance wit FCC regulations

C anges or modifications to t is aut ority to operate t is equipment.

III

CONTENTS

SECTION 1: PRODUCT INFORMATION

1-1 Manual Features………………………….…...1-1

1-2 Packa e Check List.....................................1-1

1-3 Mainboard Specifications.……….………….1-2

1-4 Mainboard Layout ……………………………1-5

SECTION 2: HARDWARE INSTALLATION

2-1 Jumper Settin s..........................................2-1

2-1.1 CMOS Clear Setting ………..............………… … ……...2-1

2-1.2 CPU Type & CPU Clock Setting …......................……....2-2

2-2 Connectors ……….……....……………..........2-3

2-2.1 Panel Connector……….…...….……………………………2-3

2-2.2 Power Connector…………....………………………………2-4

2-2.3 Fan Connector …….……..…….….....….…………………2-4

2-2.4 PS/2 Mou e Connector…………..…………………………2-5

2-2.5 Keyboard Connector….………..……………………………2-5

2-2.6 USB Device Connector……..………………………………2-6

2-2.7 Serial Device(COM1/COM2) Connector……….…....……2-6

2-2.8 Printer Connector.….….….….……..….…....….….….…...2-7

2-2.9 Floppy Drive Connector…….….….……......................…2-7

2-2.10 IDE Hard Di k and CD-ROM Connector..…….…….……2-8

2-2.11 IrDA Connector…….….………………………........………2-9

2-2.12 SB-Link Connector…………………………....…....………2-9

2-2.13 Wake On LAN Connector….….….……....…....……..…2-10

2-2.14 Ring-On Connector…………….….…………… ……..…2-10

2-3 System Memory Installation .......………...2-11

2-3.1 Type .............………………………….........….…………2-11

2-3.2 Speed ..……….……………………………………………2-11

2-3.3 Buffered and Non-buffered ..……..........….....….…...…2-12

2-3.4 2-clock and 4-clock ………………..….…...……….....…2-12

2-3.5 Parity and Non-parity………....……...………….........…2-13

2-3.6 Memory Auto detection by BIOS …....….………………2-13

2-3.7 Sugge ted SDRAM combination ….........…...…………2-13

SECTION 3: CMOS SETUP UTILITY

3-1 BIOS Setup Main Menu...............................3-1

3-2 Standard CMOS Setup................................3-2

3-3 BIOS Features Setup...................................3-5

3-4 Chipset Features Setup.............................3-10

3-5 Power Mana ement Setup........................3-14

3-6 PNP/PCI Confi uration..............................3-20

3-7 Load Setup Defaults..................................3-24

3-8 Load Turbo Defaults..................................3-25

3-9 Inte rated Peripherals...............................3-26

3-10 Password Settin ………................…..……3-31

3-11 IDE HDD Auto Detection…....….…..………3-32

3-12 Save & Exit Setup………..........….….…..…3-32

3-13 Exit with Savin ………….……......….….….3-32

SECTION 4: BIOS/SOFTWARE UTILITY

4-1 Flash Utility Maxflash.exe............................4-1

4-2 BIOS Flash/Up rade Protection ......….…....4-2

4-3 Hardware Monitor (Optional) ...........….…....4-3

SECTION 1.

PRODUCT INFORMATION

Thanks for purchasing this Intel BX Dual Pentium II mainboard.

This user’s manual contains all the information and features that show you

how to use this mainboard. Please take a moment to familiarize yourself

with the design and organization of this manual.

1-1 Manual Features

This manual is di ided into the following four sections:

Section 1: Product Information

A brief o er iew of what comes in the mainboard package, the mainboard

layout and the specification it appears.

Section 2: Hardware Installation

Tell you the usage of the mainboard jumpers and the connectors.

Section 3: CMOS Setup Utilit

A summary of the mainboard CMOS (BIOS) Setting.

Section 4: BIOS/Software Utilit

Introduction of mainboard BIOS flash utility.

1-2 Package Check List

This mainboard package contains the following items. Please inspect the

package contents and confirm that e erything is there. If anything is missing

or damaged, call your endor for instructions before operating.

1-1

I. PRODUCT INFORMATION

The package includes:

One Intel BX Dual PII Mainboard

Two Pentium II Retention Module

One Floppy Interface Cable

One IDE Interface Cable

One CD Title including Bus Master IDE Dri er and Utilities

One User’s Manual

1-3 Mainboard Specification

Form Factor ATX form factor

Board Size 22.86 cm x 30.5 cm

CPU Supports Dual Pentium II CPUs up to 350~450 MHz

System Memory DIMM 168-pin x 4 , SDRAM maximum 1GB

Supports 64M-bit SDRAM technology

Chipset Intel 440BX AGP Chipset

Expansion Slots 1 x AGP bus

2 x ISA bus

5 x PCI bus with Bus master mode

Serial Port Two serial ports UART 16C550 compatible

Sets serial port 2 to operate in normal mode , IrDA

or ASKIR

Parallel Port One parallel port supports :

SPP-standard parallel port

EPP-enhanced parallel port

ECP-extended capabilities port

Floppy Interface Supports dri es inches/format with:

3.5 inches—720KB/1.44MB/2.88MB

1-2

I. PRODUCT INFORMATION

5.25 inches—360KB/1.2MB

IDE Interface Dual PCI IDE interface support up to 4 x IDE HDD

or CDROM

Supports PIO mode 4 , DMA mode 2 and Ultra DMA

USB Interface Two USB ports supported

USB legacy keyboard function supported

PS/2 Mo se PS/2 mouse supported by connector onboard

Keyboard PS/2 keyboard by connector onboard

F se Supports reco erable fuse for USB and KB /

MOUSE

RTC and Battery RTC build in chipset (south bridge PIIX4)

Lithium (CR-2032) battery

Wake p f nction Modem ring wake up

LAN wake up

RTC Alarm wake up

Synchrono s

Switching Reg lator

High efficient synchronous switching regulator for

CPU core oltage from 2.0V to 3.5V

Supports o er- oltage / o er-current protection

function

Hardware Monitor

(Optional)

Fan speed monitor--Three fan connectors , warning

when CPU or Housing fan is malfunction

Voltage monitor—Warning when system oltage

(5V,12V,3.3V,VCORE) are abnormal

CPU and system thermal monitor—Warning when

CPU and system temperature is higher than a

predefined alue

Power connector Supports ATX(20-pin) power connector

BIOS Award BIOS

Year 2000 Compliance

PCI 2.1 Compliance

PnP BIOS 1.0a Compliance

APM 1.2 Compliance

DMI 2.0 compliance

1-3

I. PRODUCT INFORMATION

Flash/Upgrade BIOS protection

Supports ACPI (Ad anced Configuration and Power

Interface) and OS Directed Power Management

Supports SOFT power

Virus warning supported

Floppy dri e swapping function supported

LED Indicator System power LED

HDD acti ity LED

SB-Link Connector Supports Creati e PCI sound card

1-4 Mainboard La out

1-4
