Intel PSB-701LF Manuel utilisateur

USER’S

MANUAL

PSB-701LF

Intel®Core2Duo/Quad

FullSizeCPUCard

WithVGA/Sound/2LAN

PSB-701LF M1

PSB-701LF Intel® Core 2

Duo/Quad

Full Size CPU Card

With VGA/ Sound/ 2LAN

OPERATION MANUAL

This operation manual is meant to assist both Embedded Computer

manufacturers and end users in installing and setting up the system. The

information contained in this document is subject to change without any

notice.

This manual is copyrighted in March, 2008. You may not reproduce or

transmit in any form or by any means, electronic, or mechanical, including

photocopying and recording.

ACKNOWLEDGEMENTS

All trademarks and registered trademarks mentioned herein are the

property of their respective owners.

CE NOTICE

This is a class A product. In a domestic environment this product may

cause radio interference in which case the user may be required to take

adequate measures.

FCC NOTICE

This equipment has been tested and found to comply with the limits for a

Class A digital device, pursuant to part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio

communications. Operation of this equipment in a residential area is

likely to cause harmful interference in which case the user will be

required to correct the interference at his own expense.

You are cautioned that any change or modifications to the equipment not

expressly approve by the party responsible for compliance could void

your authority to operate such equipment.

Contents

TABLE OF CONTENTS

CHAPTER 1 INTRODUCTION

1-1 About This Manual ........................................................ 1-2

1-2 System Specification ...................................................... 1-3

1-3 Safety Precautions ......................................................... 1-5

CHAPTER 2 HARDWARE CONFIGURATION

2-1 Jumper & Connector Quick Reference Table ................ 2-2

2-2 Component Locations .................................................... 2-3

2-3 How to Set the Jumpers ................................................. 2-4

2-4 COM Port Connector ……..…………………………... 2-6

2-5 RS232/422/485(COM2) Selection ................................ 2-7

2-6 Keyboard and PS/2 Mouse Connector .....................….. 2-8

2-7 Keyboard or PS/2 Mouse Selection …………………… 2-8

2-8 External Keyboard Connector ………………………… 2-9

2-9 Reset Connector ............................................................ 2-9

2-10 Hard Disk Drive LED Connector .................................. 2-9

2-11 ATX Power Button ….................................................... 2-10

2-12 External Speaker Connector .......................................... 2-10

2-13 Power LED Connector ……............................................ 2-10

2-14 KeyLock Connector ..………………………………… 2-11

2-15 External SMI Connector ……………………………… 2-11

2-16 Clear CMOS Data Selection ………………………… 2-12

2-17 CPU Fan Connector ………………………………….. 2-12

2-18 System Fan Connector ………………………………… 2-13

2-19 Inverter Connector …………………………..……….. 2-13

2-20 Printer Connector ……………………………………… 2-14

2-21 TPM Connector ………………………….…………….. 2-15

2-22 VGA Connector …………………..…………………… 2-16

2-23 Serial ATA Connector ………………………………… 2-17

2-24 Universal Serial Bus Connector ……………………… 2-19

2-25 LAN Connector …………….………………………… 2-21

2-26 ATX Power Connector ………………………………. 2-23

2-27 Memory Installation ………………………………….. 2-23

2-28 Sound Connector ……………………………………… 2-24

2-29 CD Audio-In Connector ………………………………. 2-24

2-30 LVDS Connector ……………………………………… 2-25

2-31 LVDS Panel Voltage Selection ……………………….. 2-26

2-32 PCI Express/ SDVO Interface Selection ……………… 2-27

Contents

CHAPTER 3 SOFTWARE UTILITIES

3-1 Introduction …………..........................................…....... 3-2

3-2 VGA Driver Utility ……………………………….…… 3-3

3-3 Flash BIOS Update ..............................................…....... 3-4

3-4 LAN Driver Utility …...........................................…...... 3-6

3-5 Sound Driver Utility …………………………………… 3-7

3-6 Intel Chipset Software Installation Utility …..……..….. 3-8

3-7 USB2.0 Software Installation Utility ………………….. 3-9

3-8 Watchdog Timer Configuration ……………………….. 3-10

CHAPTER 4 AWARD BIOS SETUP

4-1 Introduction ................................................................... 4-2

4-2 Entering Setup ............................................................... 4-3

4-3 The Standard CMOS Features ………............................ 4-4

4-4 The Advanced BIOS Features ....................................... 4-7

4-5 Advanced Chipset Features ........................................... 4-9

4-6 Integrated Peripherals …............................................... 4-12

4-7 Power Management Setup ............................................. 4-16

4-9 PC Health Status …….................................................... 4-19

4-10 Load Fail-Safe Defaults ................................................. 4-18

4-11 Load Optimized Defaults .........................................…. 4-18

4-12 Password Setting ……………………………………… 4-19

4-13 Save & Exit Setup ......................................................... 4-20

4-14 Exit Without Saving ………………………………… 4-21

APPENDIX A EXPANSION BUS

SHB Connector Pin Assignment ……………………………… A-2

APPENDIX B TECHNICAL SUMMARY

Block Diagram ........................................................................... B-2

Interrupt Map ............................................................................ B-3

RTC & CMOS RAM Map ........................................................ B-4

Timer & DMA Channels Map .................................................. B-5

I/O & Memory Map ...............................................…................ B-6

Page:1-1

INTRODUCTION

This chapter gives you the information for PSB-701LF. It also

outlines the System specifications.

Section includes:

zAbout This Manual

zSystem Specifications

zSafety Precautions

Experienced users can skip to chapter 2 on page 2-1

for a Quick Start.

CHAPTER

Chapter 1 Introduction

Page: 1-2 PSB-701LF USER

′

S MANUAL

1-1. ABOUT THIS MANUAL

Thank you for purchasing our PSB-701LF Intel® Core 2 Duo/ Core 2

Quad Full Size CPU Card enhanced with VGA/Sound/2LAN, which is

fully PC / AT compatible. The PSB-701LF provides faster processing

speed, greater expandability and can handle more tasks than before. This

manual is designed to assist you how to install and set up the system. It

contains four chapters. The user can apply this manual for configuration

according to the following chapters:

Chapter 1 Introduction

This chapter introduces you to the background of this manual, and the

specifications for this system. The final page of this chapter will indicate

how to avoid damaging this board.

Chapter 2 Hardware Configuration

This chapter outlines the component locations and their functions. In the

end of this chapter, you will learn how to set jumper and how to configure

this card to meet your own needs.

Chapter 3 Software Utilities

This chapter contains helpful information for proper installations of the

VGA utility, LAN utility, Sound utility, and Flash BIOS Update. It also

describes the Watchdog-timer configuration.

Chapter 4 Award BIOS Setup

This chapter indicates you how to set up the BIOS configurations.

Appendix A Expansion Bus

This Appendix introduces you the expansion bus for SHB connector.

Appendix B Technical Summary

This section gives you the information about the Technical maps.

Chapter 1 Introduction

PSB-701LF USER

′

S MANUAL Page: 1-3

1-2. SYSTEM SPECIFICATIONS

zCPU (LGA775):

Intel® Core 2 Quad/ Core 2 Duo/ Celeron M with LGA775 CPU socket.

(Support Process Technology of Intel: 65nm, 45nm).

Auto detect voltage regulator.

zCHIPSET :

Intel® Q35 + ICH9DO + FWH (FSB:800/1066/1333MHz).

zMEMORY :

2×240Pin 667/800MHz DDR2-DIMM.

If want to enable the iAMT function, please plug the DDR2 memory in the

DIMM1.

zCACHE :

Built-in CPU.

zREAL-TIME CLOCK :

Build in South Bridge.

zBIOS :

Phoenix-Award BIOS for plug & play function.

32 Mb flash with VGA BIOS.

Support S/IO Setup.

zKEYBOARD CONNECTOR :

PS/2 K/B, with mini DIN or external connector (1×5-pin Boxheader) with

mini DIN cable; Support Y-Cable.

zMOUSE CONNECTOR :

PS/2 Mouse, with mini DIN connector (selectable with KB DIN connector).

zDISPLAY :

Build-in Intel® Q35; Support CRT, LVDS.

LVDS: Support 18-bit, 24-bit LVDS. Use Chrontel CH7308A by

SDVO bus to transfer to LVDS.

Chapter 1 Introduction

Page: 1-4 PSB-701LF USER

′

S MANUAL

zSATA INTERFACE :

6 ports S-ATA. Support RAID 0,1,5,10.

4 connectors are on SHB and 2 ports signals be linked to gold fingers.

zSERIAL PORT :

2 port, 16550 UARTs RS-232.

COM1 for RS-232,COM2 for RS-232/422/485.

zPARALLEL PORT :

One port supports SPP / ECP / EPP Function.

zUSB CONNECTOR :

10 port, support USB 2.0.

6 connectors are on SHB and 4 ports signals be linked to gold fingers.

zLAN ADAPTER :

Dual Ports to support 100/1000Mbps with Intel® 82566DM, Intel® 82573L.

Support Wake-on-LAN wtih ATX power

zSOUND :

High Definition Audio with Realtek ALC262 IC.

zHARDWARE MONITORING FUNCTION :

Monitor Voltage, CPU temperature, & Cooling fan.

If CPU Temperature is over setting, the buzzer will send out a warming (only

under DOS system).

zGREEN FUNCTION :

Controlled by hardware and software.

zLED INDICATOR :

System power

Hard Disk access

zDMA CONTROLLER :

82C37 x 2

zDMA CHANNELS :

Chapter 1 Introduction

PSB-701LF USER

′

S MANUAL Page: 1-5

zINTERRUPT CONTROLLERS :

82C59 x 2

zINTERRUPT LEVELS :

zOPERATING TEMPERATURE :

0 to 60°C.

zINPUT POWER REQUIREMENT :

ATX power: +5V, +12V, -12V, 5VSB.

zBOARD DIMENSIONS :

338.5mm x 122mm, 13.33” x 4.8”

zBOARD NET WEIGHT :

370 gram. (0.82lb)

1-3. SAFETY PRECAUTIONS

Follow the messages below to avoid your systems from damage:

1. Keep your system away from static electricity on all occasions.

2. Prevent electric shock. Don‘t touch any components of this card when the

card is power-on. Always disconnect power when the system is not in use.

3. Disconnect power when you change any hardware devices. For instance,

when you connect a jumper or install any cards, a surge of power may

damage the electronic components or the whole system.

Table des matières

Autres manuels Intel Matériel informatique

Intel

Intel 945G - Bulk Single Unit Atx Exp Manuel utilisateur

Intel

Intel Atom C2000 Manuel utilisateur

Intel

Intel Dialogic D/240SC-T1 Manuel utilisateur

Intel

Intel 925 - Pentium D 925 3.0GHz 800MHz 4MB-Cache Socket 775... Manuel utilisateur

Intel

Intel RS2WC040 Manuel d'installation

Intel

Intel 810A3 Mode d’emploi

Intel

Intel RS25SB008 Manuel d'installation

Intel

Intel 2ND GENERATION CORE PROCESSOR FAMILY DESKTOP - THERMAL MECHANICAL S AND DESIGN GUIDELINES... Manuel utilisateur

Intel

Intel 2ND GENERATION INTEL CORE PROCESSOR FAMILY MOBILE - SPECIFICATION UPDATE... Manuel utilisateur

Intel

Intel AXXRMFBU4 Manuel utilisateur

Intel

Intel NUC11PAQi7 Manuel utilisateur

Intel

Intel E2160 - Cpu Pentium Dual-Core 1.80Ghz Fsb800Mhz 1M Lga775... Mode d’emploi

Intel

Intel Xeon X5570 Manuel utilisateur

Intel

Intel PD6730 Instructions d'installation et d'utilisation

Intel

Intel Core 2 Duo Processor Manuel utilisateur

Intel

Intel SRCU41L - RAID Controller Manuel utilisateur

Intel

Intel SL7PG - Xeon 3.4 GHz/800MHz/1MB Cache CPU... Manuel utilisateur

Intel

Intel 80C186XL Manuel utilisateur

Intel

Intel XL710-Q2 Manuel utilisateur

Intel

Intel Xeon Processor E5-2600 Manuel utilisateur

Intel

Intel Mobileye EyeCAN Kit Manuel utilisateur

Intel

Intel Quark SoC X1000 Mode d’emploi

Intel

Intel Core 2 Quad Q9400 Guide de référence

Intel

Intel NUC7CJYHN Manuel utilisateur

Manuels Matériel informatique populaires d'autres marques

EMC2

EMC2 VNX Series Manuel du propriétaire

Panasonic

Panasonic DV0PM20105 Manuel utilisateur

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuel utilisateur

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuel utilisateur

Raidon

Raidon iT2300 Manuel utilisateur

National Instruments

National Instruments PXI-8186 Manuel utilisateur

Hauppauge

Hauppauge WinTV-HVR-2250 Manuel utilisateur

Kontron

Kontron CP6002 Manuel utilisateur

Manhattan

Manhattan 702843 Manuel utilisateur

Aphex

Aphex 230 Manuel utilisateur

AMD

AMD Phenom II Manuel d'exploitation

dbx

dbx Zone Pro 1260 Manuel utilisateur

Galaxy

Galaxy GHDX2-2430S-24F4D Manuel utilisateur

Kontron

Kontron DIMM-PC/MD Manuel utilisateur

ST X-NUCLEO-SAFEA1B Mode d'emploi

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuel utilisateur

Advantech

Advantech ASMB-935 Series Manuel utilisateur

Jupiter

Jupiter RAM PACK Manuel utilisateur
