InnoMedia iPBX-412 Quick Install Guide

InnoMedia

iPBX-412 Quick Install Guide

Version 1.0

March, 2009

March 2009 - InnoMedia

InnoMedia iPBX-412 Quick Install Guide

Table of Contents

INSTALL IPBX IN YOUR CORPORATE NETWORK...........................................................................4

ADDING PHONES TO IPBX............................................................................................................7

CONFIGURE SIP TRUNK LINES WITH AN ITSP ................................................................................8

VERIFYING COMMUNICATIONS ..................................................................................................9

PANEL LEDS.................................................................................................................................10

UPS LED ON WEB PAGE...............................................................................................................11

March 2009 - InnoMedia

InnoMedia iPBX-412 Quick Install Guide

Introduction

This document describes the ways to

− install iPBX in your corporate network

− create extension numbers, and assign devices to users

− configure SIP trunk lines with an ITSP

− verify communications

Figure 1. Hardware Interface

A. COM port

B. 12 FXO port for PSTN connection

C. 4FXS ports for legacy analog devices

D. 1 Audio In for MOH, 1 Audio Out for overhead paging

E. 2 USB host ports, for system restore/backup

F. 1 LANports for up to 256IP phones

G. 1 WANport

H. 1 UPS for battery backup

March 2009 - InnoMedia

InnoMedia iPBX-412 Quick Install Guide

Install iPBX in your corporate network

Step 1 - Connecting Panel Ports

Figure 2 iPBX Hardware interface port

1. Connect the power cord to the iPBX.

Connect the power cord to the iPBX and power on iPBX. The Power LED will

then turn ON.

2. Connecting the LAN Port

Connect iPBX LAN interface to the hub or switch that is connected to your

internal network using RJ-45 Ethernet cable. The LAN indicator LED should

glow, if the LAN port is successfully connected to the local network.

3. Connecting the WAN Port

Connect iPBX WAN interface to the Internet router or Internet access device

by a RJ45 Ethernet cable. The WAN indicator Led should glow, if the WAN

port is successfully connected to the Internet.

4. Connecting the FXS Ports

Connect analog devices such as phones, FAX, or low speed modem (such as

credit card reader) to the FXS ports of iPBX via RJ-11 cables.

5. Connecting the FXO Ports (only available at model iPBX-412).

Connect external PSTN lines to FXO ports on the back panel of the iPBX-412

via RJ11 cables.

March 2009 - InnoMedia

InnoMedia iPBX-412 Quick Install Guide

Step 2 – Check the administrative computer that configures iPBX

Figure 3 iPBX Network Placement (the picture is of model iPBX-412)

The iPBX configuration described in the Installation guide is for when the iPBX is

residing on a corporate network which is behind an existing corporate firewall. For

other placements of iPBX in the corporate network such as on DMZ or public network,

please refer to the Administration manual (which can be obtained from your

contact at InnoMedia).

1. The default LAN IP of iPBX is 172.16.1.1 with the Subnet Mask of 255.255.0.0. The

iPBX should be placed on the same LAN segment where your IP phones will

reside.

2. Configure your PC with appropriate IP address (i.e., 172.16.1.3) within the same

subnet as iPBX.

3. Connect iPBX LAN port to the administrative computer.

March 2009 - InnoMedia

InnoMedia iPBX-412 Quick Install Guide

Figure 4. Configuring the IP address of the administrative computer

Step 3 - Configuring Network – LAN

Start your web browser, and enter “http://172.16.1.1” in the Address field to connect

to the iPBX. The login page will appear. The default User Name is “admin” and the

Password is “123”. Click the <Login> button to enter the iPBX home page.

A static IP address should be manually assigned to the server to avoid unexpected IP

address changes, which may result in a loss of connectivity. You should avoid DHCP

for iPBX LAN IP obtaining if possible.

1. To change the LAN settings, go to the page at “Network ÆSettingsÆLAN.

2. Give an appropriate static private IP address and associated netmask value that

you will assign to iPBX. For example, LAN private IP address for iPBX is

“172.16.20.33” with associated netmask as “255.255.255.0”. In any case, you

should check the network configurations of your organization.

3. iPBX automatically reboots after you change the LAN IP address.

Step 4 - Configuring Network – Internet connection

1. Login to iPBX admin web console.

2. To change the WAN settings, go to the page at “NetworkÆSettingsÆInternet

Connection”.

March 2009 - InnoMedia

InnoMedia iPBX-412 Quick Install Guide

3. Choose one Internet connection type from the ‘Connection Type’ drop-down list,

such as PPPoE, DHCP Client or Static IP.

4. Enter the required information provided by your ISP in the corresponding fields or

use any of default values. Click the <Apply> button.

5. If the WAN is successfully configured to connect to the Internet, the “Connection

Status” should display “Connected”.

Step 5 - Configuring iPBX DHCP Server

IP-Phone and iPBX must connect to same subnet.

1. Go to the page of “Network

Settings

DHCP”.

2. Make sure the “Starting IP Address” and “Ending IP Address” are configured to a

proper range.

3. If you desire the iPBX to manage the IP address of only the IP Phones then check,

“Only for managed devices”. Otherwise if you need the iPBX to manage the IP

address for both IP Phone’s and computers on the LAN, then ensure that “Only for

managed devices” is unchecked.

4. Check the “Enabled” check box and click the <Apply> button.

5. When the above configurations take effect the iPBX will start to manage and

provision the connected IP phone devices.

Adding Phones to iPBX

Adding IP Phones to iPBX

There are two options to add IP Phones to iPBX.

Option A. Adding IP Phones in the auto discovery mode.

1. Connect IP Phones to local network and power them on. Be sure IP

Phones are at the same subnet with iPBX and WAN connection of IP

Phones are set to DHCP mode. (Please refer to the iPBX Web page

“System

Provisioning

Device Provisioning” for the latest certified

device model list)

March 2009 - InnoMedia

InnoMedia iPBX-412 Quick Install Guide

2. Go to the page of Telephony

Settings

Devices, and click the

<Discover> button and then the new devices will appear in device list

on the web page.

Option B. Adding IP Phones and configuring associated extensions in a batch mode.

Configuring IP Phones, users, and associated extensions can be done

through importing the corporate IP telephony plan file in CSV format.

Please refer the steps from the iPBX administrative guide.

Configuring Analog Phone connecting to iPBX FXS ports

1. Go to the page of Telephony

Settings

Analog phones

2. The extension numbers assigned to FXS ports are preconfigured at iPBX from 10 to

13. You may change the extension numbers according to your telephony plan.

Configure SIP trunk lines with an ITSP

1. To configure a VoIP trunk, go to the page of Telephony ÆSettings ÆVoIP Trunks.

a) Click the button “Profile Config”, the “Profile Configuration” screen will appear.

b) Click the “Profile1” tab, enter the SIP Server IP address provided by your ITSP in

the SIP Proxy “HOST” filed, and if ITSP happens to have a SIP Domain, then

enter that to “SIP DOMAIN” field as well.

c) Click the button <Apply> then finish.

2. To configure SIP account, back to the page of “TelephonyÆSettingsÆVoIP

Trunks”.

a) Click one VoIP trunk line from the list. The settings are displayed in the edit

section at the bottom of the page.

b) Enter “User ID”, “Auth ID”, “Auth Password”, select the profile you just

configured, and check the “Enabled” check box. Click <apply icon > to

activate this trunk line.

3. If VoIP Trunk registers successfully, the status icon of this VoIP trunk will become

Green.

March 2009 - InnoMedia

InnoMedia iPBX-412 Quick Install Guide

Verifying Communications

To monitor the on going call sessions, go to the page at TelephonyÆMonitorÆView

Mode”.

Default telephony plan of iPBX is listed in the following table.

Description Default Value

Extension number of Analog Phone (FXS) 10 to 13

Extension number of IP Phone 30

Outbound Code for PSTN 5*

Outbound Code for VoIP None

1. Making an Internal Call

Making calls between extensions.

For example, ext “10” calls ext “30”.

Note that to expedite the call setup, press “#” after dialing all the digits.

2. Making an Outbound Call

Making an outbound call from an IP Phone extension (or an Analog Phone

extension) to an external phone number.

For example, ext. “30” calls “4325400” or “5*4325400”.

Note that to expedite the call setup, press “#” after dialing all the digits.

3. Making an Inbound Call

Making an inbound call to an IP Phone extension (or Analog Phone

extension).

For example, “4325400” calls an iPBX trunk line (either VoIP trunk or PSTN trunk).

By default, the auto attendant is enabled. Hence the caller will hear the

voice prompt (“Hello, you have entered the Interactive Voice Response

service. If you know the extension number, please dial it now. For directory,

please dial 0.”), and then dial “30”. (You may change the auto attendant IVR

later.)

March 2009 - InnoMedia

InnoMedia iPBX-412 Quick Install Guide

Panel LEDs

The below table describes each LED indicator.

LED Blinking State State

Steady - Green The device power is on.PWR Off The device power is off.

the led will first be

green, then red, then

off, then steady green

System Booting

Steady green Running normally

Orange blinking On provisioning

Red blinking Provisioning failed

RUN

Red/Orange blinking Sip trunk register failed

Blinking – Green

(10 Base T)

Blinking – Yellow

(100 Base T)

PC or Voice Data is being transferred.

WAN

Off The device is not connected to a

broadband network.

Blinking – Green

(10 Base T)

Blinking – Yellow

(100 Base T)

PC Data is being transferred.LAN

Off The device is not connected to an

external PC.

Blinking – Green (once) The FXS module is internally initialized

and the unit is ready to make calls

after booting.

Steady-Green The connected telephone handset is

off the hook.

Blinking – Green (once) The connected telephone starts

ringing.

Steady- Orange The connected telephone is talking.

FXS

Off The connected telephone handset is

on the hook (not in use).

March 2009 - InnoMedia
