InFocus LP 740TM Manuel de référence

INTRODUCTION

The In Focus LP 740™ is a multimedia projector that packs SXGA

graphics (1280x1024) with 16.7 million colors. It generates crisp,

clear images using a new and innovative reflective technology.

The LP 740 is ideal for high-performance business, engineering

and imaging applications that demand exceptional resolution

and color quality.

NOTE: You can resize your

640x480, 800x600, or

1024x768 images to 1280x1024

by pressing the Resize button on

the keypad or remote.

Image Resolution

The SXGA resolution of the 740’s projected image is 1280x1024. If

your computer’s screen resolution is higher than 1280x1024, reset

it to a lower resolution before you connect the 740.

Compatibility

The projector is compatible with a wide variety of computers and

video devices, including:

•IBM, SUN, SGI, and selected HP and DEC workstations, up to

1280x1024 resolution.

•IBM-compatible computers, including laptops, up to 1280x1024

resolution.

•Apple Macintosh and PowerBook computers up to 1280x1024

resolution.

•Most standard VCRs, camcorders and laser disc players.

Unpacking the Projector

The projector comes with the items shown in Figure 1. Check to

make sure all are included. Contact your In Focus dealer imme-

diately if anything is missing.

If you are experienced in setting up presentation systems, use the

LP 740 Quick Start card that was included in the shipping box. For

complete details on connecting and operating the projector, refer

to this User’s Guide. User’s Guides are also available for down-

load from our website at www.infocus.com.

Introduction

NOTE: The contents of your

shipping box may vary depending

on the projector configuration

you’ve ordered.

FIGURE 1

Shipping box contents

1. LP 740 projector with lens cap 6. SGI adapters

2. power cord 7. S-video cable

3. LP 740 User’s Guide 8. computer cable

4. remote control and batteries 9. video cable

5. SUN adapters 10. audio cable

FIGURE 2

Side view of projector

FIGURE 3

Back view of projector

lens cap foot adjuster buttons

speakers

keypad

handle

L R

Computer

Data Out Data In

Audio Out

Audio In

Remote RS-232

Video

Computer

L R

S C

Audio In

Video In

L R

power

cord

connector vent fan

connector panel IR receiver

Introduction

Usage Guidelines

•Do not look directly into the projection lens when the projector

is turned on. The bright light may harm your eyes.

•Do not block the grills on the projector. Restricting the air flow

can cause it to overheat and turn off. If this happens, you must

wait a minute before attempting to turn it back on.

•Handle the projector as you would any product with glass

components. Be especially careful not to drop it.

•Avoid leaving the projector in direct sunlight or extreme cold

for extended periods of time. If this happens, allow it to reach

room temperature before use.

•This projector is not intended for use in a mainframe computer

room as defined in the Standard for the Protection of Electronic

Computer/Data Processing Equipment, ANSI/NFPA 75.

•Transport the projector in a vendor-approved hard or soft case.

Part numbers for these cases are listed on page 34. Call your In

Focus dealer to order.

If You Need Assistance

The first place to look for help is in this manual. Be sure to check

the guidelines in “Troubleshooting” on page 29.

If this manual doesn’t answer your question, call your In Focus

dealer. You can also call In Focus Customer Service directly at

1-800-799-9911. Call between 5 a.m. and 5 p.m. PST, Monday

through Friday. In Europe, call In Focus in The Netherlands at

(31) 23-5540310. In Singapore, call (65) 740-6435. Or, send us an

e-mail at techsupport@infocus.com

Our World Wide Web address is http://www.infocus.com.

Warranty

This product is backed by a limited one-year warranty. The

details of the warranty are printed at the back of this manual.

Longer term warranties can be purchased from your In Focus

dealer. Refer to page 34 for part numbers.
