INFINITY CLASSIA™

A higher truth, beautifully expressed.

INFH1383 Classia 2A 12/20/07 2:54 PM Page 1

INFH1383 Classia 2A 12/20/07 2:55 PM Page 2

INTRODUCING THE

INFINITY CLASSIA™SERIES.

Infinity Classia loudspeakers share a

heritage of technological and design

excellence dating back 40 years.

In multichannel home theater systems

and stereo systems alike, they bring real

power and exceptional sonic fidelity to

both movies and music, elevating the

home entertainment experience to a

new level of realism.

Infinity Classia loudspeakers deliver

the resonance-free, full-spectrum

performance needed to accurately

reproduce today’s high-definition

digital sources.And their graceful,

low-profile design, inspired by the

Infinity Cascade™Series, makes them

an ideal complement for today’s high-

definition flat-panel monitors.

Infinity Cascade

INFH1383 Classia 2A 12/20/07 2:55 PM Page 3

INFH1383 Classia 2A 12/20/07 2:55 PM Page 4

PERFORMANCE IN THE

INFINITY®TRADITION.

Infinity Classia speakers were developed

with high-definition programming in

mind, delivering audio performance that

enhances today’s stunning video images.

A complete 5.1- or 7.1-channel system

won’t just surround you with clear, precise

ultrahigh-frequency effects, distinct

center-channel dialogue and the kind of

bass you feel, as well as hear – it may

actually improve your perception of the

video itself. And Infinity Classia systems

are likely to uncover subtleties even in

music you know by heart. Available in

high-gloss black or real-wood cherry

veneer, these speakers are an elegant,

captivating choice for people who take

their movies and music seriously –

and who can handle the truth.

INFH1383 Classia 2A 12/20/07 2:55 PM Page 5

PATENTED,PROPRIETARY,

REVOLUTIONARY,REMARKABLE:

THE INFINITY CLASSIA

TECHNOLOGIES.

CMMD®TRANSDUCERS

All Infinity Classia transducers

feature patented Infinity CMMD®

technology. Manufactured of a

ceramic compound bonded to a

metallic substrate, they are at once

strong, rigid and fast – everything

the ideal diaphragm should be.

Delivering accurate pistonic response

across the full frequency range

of the driver, CMMD transducers

produce a dramatically natural,

distortion-free sound.

Magnified cross section of CMMD alumina layers.

INFH1383 Classia 2A 12/20/07 2:55 PM Page 6

Crossover design can be optimized with shortened

signal paths,yielding cleaner sound reproduction.

The sophisticated Infinity 72-point frequency-

response measurement,conducted in one of our

four anechoic chambers,allows for accurate analysis

of a speaker’s total performance before the

listening tests even begin.

With the Constant Acoustic Impedance (CAI)

waveguide,the full effect of the CMMD

tweeter can be realized,resulting in cleaner,

more uniform sound throughout your

listening environment.

The C255ES offers selectable

monopole/bipole/dipole settings.

SPECIAL AUDIO EFFECTS.

In addition to bookshelf and

floorstanding loudspeakers, the

Series includes the uniquely versatile

C255ES surround speaker. Wall-

mountable, with selectable monopole,

bipole or dipole configurations, the

C255ES is capable of reproducing

two discrete audio channels at

once. So it can act as a single-point

2-channel loudspeaker in smaller

rooms, or upgrade a 5-channel home

theater to 7 channels all by itself.

TUNED BASS RESPONSE.

The Infinity Bass Optimization System™

delivers deeper, more detailed

low frequencies by reducing the

exaggerated bass peaks that some

listening rooms produce. Add the

optional R.A.B.O.S.

™kit to more

precisely calibrate bass response

for your particular room.

The Infinity R.A.B.O.S. kit.

CAI™WAVEGUIDES.

Acoustic waveguides can improve

a loudspeaker’s on- and off-axis

high-frequency response. But Infinity

Classia Series speakers feature

patented Infinity Constant Acoustic

Impedance™(CAI™) waveguides, which

create more dynamic headroom by

increasing the sensitivity of the high

frequencies.That allows for a simpler,

more effective crossover design,

enabling a seamless sonic transition

between the tweeter and the lower-

frequency transducers in both two-

and three-way designs.

40KHZRESPONSE.

The audio portion of today’s

high-definition digital sources is

pushing consumer audio beyond

the limits of the human ear. But

Infinity Classia speakers feature

high-frequency drivers that extend

to 40kHz, delivering nuances you

may never have experienced before

in recorded audio.

All models utilize heavy-duty,gold-plated binding

posts to ensure long-term signal transfer and

easy connection to any system. The C336 is

also bi-wirable.

Ultrathick baffles provide a rigid,

stable platform for the drivers while

simultaneously minimizing unwanted edge

diffractions off the baffle.

HIGH-GLOSS BLACK REAL-WOOD CHERRY VENEER

The C255ES allows you to connect each side

separately,giving you two discrete speakers

from a single enclosure.

WIRELESS LOWS.

Deep, realistic bass is an essential

element of the cinematic experience.

But it’s just as essential in dupli-

cating live musical performances.

The Infinity PSW310W powered

subwoofer features 2.4GHz technology

for an effortless, wireless connection

to your system, and easy placement

anywhere in your listening room.

INFH1383 Classia 2A 12/20/07 2:55 PM Page 7

PSW310W

Frequency Ranges 32Hz – 150Hz (–3dB)

28Hz (–6dB)

Maximum Amplifier Output 400 Watts RMS

(20Hz – 150Hz with

no more than 0.1%THD)

Crossover Frequencies 50Hz – 150Hz,

24dB/octave,

continuously adjustable or

LFE input

Drivers 10" (250mm) CMMD,

dual 10" CMMD passive

radiators

Dimensions 17-1/2" x 14" x 14-3/4"

(H x W x D) (445mm x 356mm x 375mm)

Weight 49.8 lb (22.6kg)

WIRELESS POWERED SUBWOOFER

Add an Infinity sub to maximize bass impact and excitement.

C205 C336 CC225 C255ES

Bookshelf Speaker Floorstanding Speaker Center Speaker Surround Speaker

Frequency Ranges 60Hz – 30kHz (–3dB) 40Hz – 30kHz (–3dB) 55Hz – 30kHz (–3dB) 60Hz – 30kHz (–3dB)

55Hz – 40kHz (–6dB) 35Hz – 40kHz (–6dB) 50Hz – 40kHz (–6dB) 50Hz – 40kHz (–6dB)

Recommended 10 – 125 Watts 10 – 250 Watts 10 – 150 Watts 10 – 150 Watts

Amplifier Power Range

Sensitivity 88dB 91dB 90dB 87dB

(2.83V @1 meter)

Nominal Impedance 8 Ohms 8 Ohms 8 Ohms 8 Ohms

Crossover Frequencies 2.0kHz; 24dB/octave 500Hz,2.8kHz; 24dB/octave 2.0kHz; 24dB/octave 2.3kHz; 24dB/octave

Low-Frequency Driver(s) 5-1/4" (133mm) CMMD,

®Triple 6-1/2" (165mm) CMMD,

®Dual 5-1/4" (133mm) CMMD,

magnetically shielded magnetically shielded magnetically shielded magnetically shielded

Mid-Frequency Driver N/A 4" (100mm) CMMD, N/A N/A

magnetically shielded

High-Frequency Driver(s) 1" (25mm) CMMD, 1" (25mm) CMMD, 1" (25mm) CMMD, Dual 1" (25mm) CMMD,

magnetically shielded magnetically shielded magnetically shielded magnetically shielded

Dimensions (H x W x D) 15-1/8" x 7-1/2" x 9-1/4" 48-1/2" x 8-1/2" x 10-1/2" 6-7/8" x 31-3/4" x 5" 11-3/4" x 13-1/4" x 6-1/2"

(384mm x 190mm x 235mm) (1232mm x 216mm x 267mm) (175mm x 806mm x 127mm) (298mm x 337mm x 165mm)

Weight 10.8 lb (4.9kg) 56.1 lb (25.4kg) 16 lb (7.3kg) 9.1 lb (4.1kg)

Designed, edited and digitally produced by the Harman Consumer Group Marketing & Design Center,Woodbury, NY

250 Crossways Park Drive,Woodbury, NY 11797 USA • 516.674.4INF • Fax 516.682.3523 • www.infinitysystems.com

Infinity and CMMD (patent nos. 6,327,372 and 6,404,897) are trademarks of Harman International Industries, Incorporated, registered in the United States and/or other countries.

Infinity Classia, Infinity Cascade, Constant Acoustic Impedance, CAI, Bass Optimization System and R.A.B.O.S. are trademarks of Harman International Industries, Incorporated.

Features, specifications and appearance are subject to change without notice.

SPECIFICATIONS
