OWNER'S

MANUAL

UTILITY TRAINER

STB-98010

IMPORTANT: Please read this manual before commencing

assembly of this product.

IMPEX®INC.

2801 S. Towne Ave, Pomona, CA 91766

Tel: 800-999-8899 Fax: (626) 961-9966

www.impex-fitness.com

support@impex-fitness.com

©IMPEX INC. www.impex-fitness.com1

TABLE OF CONTENTS

BEFORE YOU BEGIN....................................................................................…………1

IMPORTANT SAFETY NOTICES...................................................................……….. 2

EXERCISE GUIDELINES…………………………………………………………………. . 3

WARNING LABEL PLACEMENT.....….....................................................................…5

IMPORTANT ASSEMBLY INFORMATION..................................................................6

CARE AND MAINTENANCE, WEIGHT CAPACITY…………………………………….. 6

PARTS LIST…………………………………………………………………………………. 7

EXPLODED DIAGRAM………………………………………………………………………8

WARRANTY.................................................................................................…………...9

ORDERING PARTS.......................................................................................………….9

BEFORE YOU BEGIN

Thank you for selecting the STEEL BODY UTILITY TRAINER STB-98010 by

IMPEX®INC. For your safety and benefit, read this manual carefully before

using the equipment. As a manufacturer, we are committed to providing with

you complete customer satisfaction. If you have any questions, or find there

are missing or damaged parts, we guarantee you complete satisfaction

through direct assistance from our factory. To avoid unnecessary delays,

please call our TOLL-FREE customer service number. Our Customer

Service Agents will provide immediate assistance.

Toll-Free Customer Service Number

1-800-999-8899

Mon. – Fri. 9 a.m. – 5 p.m. PST

www.impex-fitness.com

support@impex-fitness.com

©IMPEX INC. www.impex-fitness.com2

IMPORTANT SAFETY NOTICE

This exercise equipment is built for optimal safety. However, certain precautions apply

whenever you operate a piece of exercise equipment. Be sure to read the entire manual

before you assemble or operate your equipment. In particular, note the following safety

precautions:

1. Keep children and pets away from the equipment at all times. DO NOT

leave children unattended in the same room with the equipment.

2. Only one person at a time should use the equipment.

3. If the user experiences dizziness, nausea, chest pain, or any other abnormal

symptoms, STOP the workout at once. CONSULT A PHYSICIAN

IMMEDIATELY.

4. Position the equipment on a clear, leveled surface. DO NOT use the equipment

near water or outdoors.

5. Keep hands away from all moving parts.

6. Always wear appropriate workout clothing when exercising. DO NOT wear

robes or other clothing that could become caught in the equipment. Running

or aerobic shoes are also required when using the equipment.

7. Use the equipment only for its intended use as described in this manual.

DO NOT use attachments not recommended by the manufacturer.

8. Do not place any sharp object around the equipment.

9. Disabled persons should not use the equipment.

10. Before using the equipment to exercise, always do stretching exercises to

properly warm up.

11. Never operate the equipment if the equipment is not functioning properly.

12. A spotter is recommended during exercise.

13. This equipment is designed and intended for home and consumer use only, not for

commercial use.

WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR

PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE

OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL

INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES

NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE

SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.

SAVE THESE INSTRUCTIONS.

©IMPEX INC. www.impex-fitness.com3

EXERCISE GUIDELINES

Building Muscle and Gaining Weight

Unlike aerobic exercise, which emphasizes endurance training, anaerobic exercise focuses on

strength training. A gradual weight gain can occur while building the size and strength of muscles.

While developing muscle mass, your body adapts to the stress placed upon it. You can modify your

diet to include foods such as meat, fish and vegetables. These foods help muscles recover and

replenish important nutrients after a strenuous workout.

Muscle Strength and Endurance

To achieve the greatest benefit from exercise, it is important to develop an exercise program that

allows you to work all of the major muscle groups equally.

To increase muscle strength, follow this principle:

Increasing resistance and maintaining the number of repetitions of an exercise results in increased

muscle strength.

To tone your body, follow this principle: Decreasing resistance plus increasing the number of

repetitions of an exercise results in increased body tone.

Once you feel comfortable with an exercise, you can change the resistance, the number of

repetitions, or the speed at which you do the exercise. It is not necessary to change all three

variables. For example, let’s say that you are training at 50 lb and performing the exercise 10 times in

3 minutes. When this becomes too easy, you may decide to move up to lifting 60 lb for the same

number of repetitions in the same amount of time. Lifting more weights fewer times most often

develops muscle strength. To gain both muscle strength and endurance, it is recommended that you

perform each exercise 15 to 20 reps per set.

Training Intensity

How hard you begin to train depends on your overall level of fitness. The soreness you experienced

can be lessened by decreasing the load you place on your muscles and by performing fewer sets. To

avoid injury, you should gradually work into an exercise program and set the load to your individual

fitness level. The load should increase as your fitness level increases.

Muscle soreness is common, especially when you first start exercising. If you are painfully sore for a

long time, it may be time to change your program. Eventually, your muscle system will become

accustomed to the stress and strain placed on it.

©IMPEX INC. www.impex-fitness.com4

Beginning a Strength Building Program

Warming Up

To begin strength training, it is important to stretch and perform light exercise for 5 to 10 minutes.

This helps prepare the body for more strenuous exercise by increasing circulation, raising your body

temperature and developing more oxygen to your muscles.

Workout

For each workout, keep in mind that muscle soreness that lasts for a long period is not desirable and

may mean that injury has occurred.

Cool Down

At the end of each workout, perform slow stretching exercises for 5 to 10 minutes. Ease into each

stretch only going as far as you can. This stage allows your muscles to wind down after training.

To provide a total workout program it is also recommended that 2 to 3 days of aerobic exercise be

performed in addition to the strength training.

Drinking Water

For the body to function properly, it must be properly hydrated. If you are exercising, you should

increase your fluid intake. The reason for this is that the water you take in will leave your system

through the sweating mechanism that cools your body during exercise. The water you lose through

exercise must be replaced so that the muscles can recover properly.

Rest Day

Although you may not feel like doing it, taking a rest day at least once a week is important because it

gives your body a chance to heal itself. Continuously working your muscles will result in over training,

which will not benefit you in the long run.

©IMPEX INC. www.impex-fitness.com5

WARNING LABEL PLACEMENT

The warning labels shown here have been placed on the Cross Brace. If the labels are missing or illegible, please

call customer service at 1-800-888-8899 for replacements. Apply the labels in the location shown.

©IMPEX INC. www.impex-fitness.com6

IMPORTANT ASSEMBLY INFORMATION

Tools required for assembling the bench: adjustable wrench and Allen wrench.

NOTE: It is strongly recommended that this equipment be assembled by two or more

people to avoid possible injury.

Ensure Carriage Bolts are inserted through the SQUARE holes on components that need to

be assembled. Attach washer only to end of the Carriage Bolt.

Use Allen Bolts or Hex Bolts inserted through the ROUND hole on components that need to

be assembled.

Always wait until all bolts are assembled onto the bench before tightening the bolts. Do not

tighten each bolt right after it is installed

Fasten Nuts and Bolts

Securely tighten all nuts and bolts after all

components have been assembled in current and

previous steps.

NOTE: Do not over tighten any component with

pivoting function.

Make sure all pivoting components are able to move

freely.

Do not tighten all nuts and bolts in this step.

CARE AND MAINTENANCE

1. Lubricate moving parts with WD-40 or light oil periodically.

2. Inspect and tighten all parts before using the equipment.

3. The equipment can be cleaned using a damp cloth and mild non-abrasive detergent.

DO NOT use solvents.

4. Examine the equipment regularly for signs of damages or wear.

5. Replace any defective components immediately and/or keep the equipment out of use until

repair.

6. Failure to examine regularly may affect the safety level of the equipment.

WEIGHT CAPACITY AND DIMENSION

1. Maximum user weight for Chin-up Bar: 350 lbs.

2. Maximum weight on Bar Catch: 500 lbs.

3. Maximum weight on Weight Storage Post: 100 lbs

4. Maximum weight on Dumbbell-Kettlebell Tray (#11): 270 lbs

5. Bar Catch heights ranges from 23” to 72” with 15 positions, 3 ½” for each adjustment.

6. Assembled dimension (L x W x H): 62” x 65” x 86 ¼”,

©IMPEX INC. www.impex-fitness.com7

STB-98010 PARTS LIST

PART

NO.

DESCRIPTION

SIZE

QUANTITY

Base Frame

Upright

Cross Brace

Side Cross Brace

Rear Upright

Weight Storage Post

Left Bar Catch

Right Bar Catch

Left Safety Catch

Right Safety Catch

Chin-up Bar

Left Support

Right Support

Dumbbell-Kettlebell Tray

Bracket

5 ½” x 2”

Bracket

7 ⅞” x 7 ⅞”

Rubber Bumper

2 ½” x 4 ⅛”

Rubber Bumper

9 ⅞” x 2 ½”

Rubber Bumper Plate

41 ⅜” x 6 ¾”

Grip

Ø ⅞” x 4 ¾”

End Cap

Ø 1”

Olympic Sleeve

Ø 2” x 8 ¼”

Spring Clip

Ø1 ⅞”

Base Frame End Cap

Socket Head Allen Bolt

M10 x 1”

Socket Head Allen Bolt

M10 x 3 ¾”

Socket Head Allen Bolt

M10 x 4”

Carriage Bolt

M10 x 2 ¾”

Aircraft Nut

M10

Washer

Ø 1 ½”

Washer

Ø ¾”

Bracket

4 ¾” x 2”

Allen Wrench (Tool)

©IMPEX INC. www.impex-fitness.com8

STB-98010 EXPLODED DIAGRAM

©IMPEX INC. www.impex-fitness.com9

IMPEX®INC.

LIMITED WARRANTY

IMPEX Inc. ("IMPEX") warrants this product to be free from defects in workmanship and material, under normal use

and service conditions, for a period of ten years on the Frames and two years on the parts from the date of

purchase. This warranty extends only to the original purchaser. IMPEX's obligation under this Warranty is limited

to replacing or repairing, at IMPEX's option.

All returns must be pre-authorized by IMPEX. Pre-authorization may be obtained by calling IMPEX

Customer Service Department at 1-800-999-8899. All freights on products returned to IMPEX must be

prepaid by the customer. This warranty does not extend to any product or damage to a product caused by or

attributable to freight damage, abuse, misuse, improper or abnormal usage. No other warranty beyond that

specifically set forth above is authorized by IMPEX.

IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in

connection with the use or performance of the product or other damages with respect to any economic loss,

loss of property, loss of revenues or profits, loss of enjoyments or use, costs of removal, installation or other

consequential damages or whatsoever natures. Some provinces do not allow the exclusion or limitation of

incidental or consequential damages. Accordingly, the above limitation may not apply to you.

The warranty extended hereunder is in lieu of any and all other warranties and any implied warranties of

merchantability or fitness for a particular purpose is limited in its scope and duration to the terms set forth

herein. Some provinces do not allow limitations on how long an implied warranty lasts. Accordingly, the

above limitation may not apply to you.

This warranty gives you specific legal right. You may also have other rights which vary from province to

province .

IMPEX®INC.

2801 S. Towne Ave.

Pomona, CA 91766

ORDERING REPLACEMENT PARTS

Replacement parts can be ordered by calling our Customer Service Department toll-free at 1-800-999-8899

during our regular business hours: Monday through Friday, 9 a.m. to 5 p.m. Pacific standard time.

support@impex-fitness.com

When ordering replacement parts, always give the following information.

1. Model

2. Description of Parts

3. Part Number

4. Date of Purchase

Table des matières

Autres manuels Impex Salle de sport à domicile

Impex

Impex MARCY DIAMOND ELITE MD-2080 Manuel utilisateur

Impex

Impex MARCY MCB-346 Manuel utilisateur

Impex

Impex Marcy Classic MCB-5693 Manuel utilisateur

Impex

Impex WM PRO Manuel utilisateur

Impex

Impex APEX TSA-499 Manuel utilisateur

Impex

Impex WM-1508 Manuel utilisateur

Impex

Impex MARCY MWM-1860 Manuel utilisateur

Impex

Impex MARCY TC-3508 Manuel utilisateur

Impex

Impex SB 650W Manuel utilisateur

Impex

Impex MARCY DIAMOND ELITE MD-2080 Manuel utilisateur

Impex

Impex MACH V Manuel utilisateur

Impex

Impex MARCY SM-4231 Manuel utilisateur

Impex

Impex Marcy Pro NS-607RW Instructions d'installation et d'utilisation

Impex

Impex Marcy Diamond MD-2109 Manuel utilisateur

Impex

Impex MARCY MWB-544 Manuel utilisateur

Impex

Impex APEX AX-2109.1 Manuel utilisateur

Impex

Impex MARCY MD-377 Manuel utilisateur

Impex

Impex MFB 400 Manuel utilisateur

Impex

Impex MARCY MWM-7041 Manuel utilisateur

Impex

Impex MD-4100 Manuel utilisateur

Impex

Impex MARCY PLATINUM MP 2100 Manuel utilisateur

Impex

Impex MWM-981 Manuel utilisateur

Impex

Impex MARCY MWM-8900 Manuel utilisateur

Impex

Impex POWERHOUSE SB 680 Manuel utilisateur

Manuels Salle de sport à domicile populaires d'autres marques

Horizon Fitness

Horizon Fitness OXFORD 6 Manuel utilisateur

Energetics

Energetics Multi Trainer 5.1 Manuel utilisateur

Matrix

Matrix MG-PL Series Manuel utilisateur

Reebok

Reebok Tbr2i Manuel d'utilisation et d'entretien

Weider

Weider 8300 Hard Drive Manuel utilisateur

Pure Fitness

Pure Fitness 8526HE Manuel utilisateur

Weider

Weider 8700 I Guide de démarrage rapide

Bowflex

Bowflex Sport 001-6961 Manuel utilisateur

NordicTrack

NordicTrack E8200 Competition Bench Guide de démarrage rapide

Weider

Weider WEMC10161 Manuel utilisateur

Body Solid

Body Solid GHYP-345 Manuel utilisateur

Evo

Evo TAHOE 5105 Manuel utilisateur

cardiobull

cardiobull RA17 Manuel utilisateur

ParaBody

ParaBody 40 Manuel utilisateur

JLL

JLL Ventus Pro Air Power Manuel utilisateur

Trojan

Trojan Colorado 370 Manuel utilisateur

Octane Fitness

Octane Fitness xRide xR650 Manuel utilisateur

Precor

Precor Discovery Series Manuel utilisateur
