Impex MARCY MWM-8026 Manuel utilisateur

NOTE:

Please read all

instructions carefully

before using this product

Table of Contents

Safety Notice

Important Assembly

Information

Care and Maintenance

Parts List

Warranty

Ordering Parts

Model

MWM-8026

Retain This

Manual for

Reference

160510

OWNER'S

MANUAL

FREE WEIGHT HOME GYM

MWM-8026

IMPORTANT: Please read this manual before commencing

assembly of this product.

IMPEX®INC.

2801 S. Towne Ave, Pomona, CA 91766

Tel: 800- 999-8899

www.impex-fitness.com

support@impex-fitness.com

©IMPEX INC. www.impex-fitness.com1

TABLE OF CONTENTS

BEFORE YOU BEGIN....................................................................................…………1

IMPORTANT SAFETY NOTICES...................................................................……….. 2

EXERCISE GUIDELINES…………………………………………………………………. 3

WARNING LABEL PLACEMENT.....….....................................................................…5

I MPORTANT ASSEMBLY INFORMATION...................................................................6

WEIGHT CAPACITY AND DIMENSION………..………………………………………….6

OPERATING NOTES, WEIGHT RESISTANCE CHART………………………………...7

CARE AND MAINTENANCE………………………………………………………………..8

PARTS LIST…………………………………………………………………………………. 9

EXPLODED DIAGRAM……………………………………………………………………...11

FREE AND TRAINING AREA………………………………………………………………12

WARRANTY.................................................................................................………….13

ORDERING PARTS.......................................................................................…………13

BEFORE YOU BEGIN

Thank you for selecting MARCY FREE WEIGHT HOME GYM MWM-8026 by

IMPEX®INC. For your safety and benefit, read this manual carefully before

using the equipment. As a manufacturer, we are committed to providing you

with complete customer satisfaction. If you have any questions, or find there

are missing or damaged parts, we guarantee you complete satisfaction

through direct assistance from our factory. To avoid unnecessary delays,

please call our TOLL-FREE customer service number. Our Customer

Service Agents will provide immediate assistance.

Toll-Free Customer Service Number

1-800-999-8899

Mon. – Fri. 9 a.m. – 5 p.m. PST

www.impex-fitness.com

support@impex-fitness.com

©IMPEX INC. www.impex-fitness.com2

IMPORTANT SAFETY NOTICE

This exercise equipment is built for optimum safety. However, certain precautions apply

whenever you operate a piece of exercise equipment. Be sure to read the entire manual

before you assemble or operate your equipment. In particular, note the following safety

precautions:

1. Keep children and pets away from the equipment at all times. DO NOT

leave children unattended in the same room with the equipment.

2. Only one person at a time should use the equipment.

3. If the user experiences dizziness, nausea, chest pain, or any other abnormal

symptoms, STOP the workout at once. CONSULT A PHYSICIAN

IMMEDIATELY.

4. Position the equipment on a clear, leveled surface. DO NOT use the equipment

near water or outdoors.

5. Keep hands away from all moving parts.

6. Always wear appropriate workout clothing when exercising. DO NOT wear

robes or other clothing that could become caught in the equipment. Running

or aerobic shoes are also required when using the equipment.

7. Use the equipment only for its intended use as described in this manual. DO

NOT use attachments not recommended by the manufacturer.

8. Do not place any sharp object around the equipment.

9. Disabled persons should not use the equipment.

10. Before using the equipment to exercise, always do stretching exercises to

properly warm up.

11. Never operate the equipment if the equipment is not functioning properly.

12. A spotter is recommended during exercise.

13. This equipment is designed and intended for home and consumer use only, not for

commercial use.

WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR

PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE

OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL

INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES

NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE

SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.

SAVE THESE INSTRUCTIONS.

©IMPEX INC. www.impex-fitness.com3

EXECISE GUIDELINES

Building Muscle and Gaining Weight

Unlike aerobic exercise, which emphasizes endurance training, anaerobic exercise focuses on

strength training. A gradual weight gain can occur while building the size and strength of muscles.

While developing muscle mass, your body adapts to the stress placed upon it. You can modify your

diet to include foods such as meat, fish and vegetables. These foods help muscles recover and

replenish important nutrients after a strenuous workout.

Muscle Strength and Endurance

To achieve the greatest benefit from exercise, it is important to develop an exercise program that

allows you to work all of the major muscle groups equally.

To increase muscle strength, follow this principle:

Increasing resistance and maintaining the number of repetitions of an exercise results in increased

muscle strength.

To tone your body, follow this principle: Decreasing resistance plus increasing the number of

repetitions of an exercise results in increased body tone.

Once you feel comfortable with an exercise, you can change the resistance, the number of

repetitions, or the speed at which you do the exercise. It is not necessary to change all three

variables. For example, let’s say that you are training at 23 kg (50 lb.) and performing the exercise 10

times in 3 minutes. When this becomes too easy, you may decide to move up to lifting 27 kg (60 lb.)

for the same number of repetitions in the same amount of time. Lifting more weights fewer times

most often develops muscle strength. To gain both muscle strength and endurance, it is

recommended that you perform each exercise 15 to 20 reps per set.

Training Intensity

How hard you begin to train depends on your overall level of fitness. The soreness you experienced

can be lessened by decreasing the load you place on your muscles and by performing fewer sets. To

avoid injury, you should gradually work into an exercise program and set the load to your individual

fitness level. The load should increase as your fitness level increases.

Muscle soreness is common, especially when you first start exercising. If you are painfully sore for a

long time, it may be time to change your program. Eventually, your muscle system will become

accustomed to the stress and strain placed on it.

©IMPEX INC. www.impex-fitness.com4

Beginning a Strength Building Program

Warming Up

To begin strength training, it is important to stretch and perform light exercise for 5 to 10 minutes.

This helps prepare the body for more strenuous exercise by increasing circulation, raising your body

temperature and developing more oxygen to your muscles.

Workout

For each workout, to keep in mind that muscle soreness that lasts for a long period is not desirable

and may mean that injury has occurred.

Cool Down

At the end of each workout, perform slow stretching exercises for 5 to 10 minutes. Ease into each

stretch only going as far as you can. This stage allows your muscles to wind down after training.

To provide a total workout program it is also recommended that 2 to 3 days of aerobic exercise is

performed in addition to the strength training.

Drinking Water

For the body to function properly, it must be properly hydrated. If you are exercising, you should

increase your fluid intake. The reason for this is that the water you take in will leave your system

through the sweating mechanism that cools your body during exercise. The water you lose through

exercise must be replaced so that the muscles can recover properly.

Rest Day

Although you may not feel like doing it, taking a rest day at least once a week is important because it

gives your body a chance to heal it self. Continuously working your muscles will result in over-

training, which will not benefit you in the long run.

©IMPEX INC. www.impex-fitness.com5

WARNING LABEL PLACEMENT

The warning labels shown here have been placed on the Rear Stabilizer and Upper Frame. If the labels are

missing or illegible, please call customer service at 1-800-888-8899 for replacements. Apply the labels in the

location shown.

©IMPEX INC. www.impex-fitness.com6

IMPORTANT ASSEMBLY INFORMATION

Tools required for assembling the bench: Two adjustable Wrenches and Allen wrenches.

NOTE: It is strongly recommended that this equipment be assembled by two or more

people to avoid possible injury.

Ensure Carriage Bolts are inserted through the SQUARE holes on components that need to

be assembled. Attach washer only to end of the Carriage Bolt.

Use Allen Bolts or Hex Boltsinserted through the ROUND hole on components that need to

be assembled.

Always wait until all bolts are assembled onto the bench before tightening the bolts. Do not

tighten each bolt right after it is installed

Fasten Nuts and Bolts

Securely tighten all nuts and bolts after all

components have been assembled in current and

previous steps.

NOTE: Do not over-tighten any component with

pivoting function.

Make sure all pivoting components are able to move

freely.

Do not tighten all nuts and bolts in this step.

WEIGHT CAPACITY AND DIMENSION

1. Maximum user weight: 300 lb.

2. Maximum weight on each side of Sliding Weight Post (#7): 140 lb (70lbs on each side)

3. Assembled dimensions: 52.5” x 41” x 81.75”

©IMPEX INC. www.impex-fitness.com7

OPERATION NOTES

Cable Tension Adjustment

Adjust the tension of the Cable System by moving the position of lower Pulley on the

two Double Floating Pulley Brackets.

If the tension is too loose, move the lower pulley up by one hole.

If the tension is too tight, move the lower pulley down by one hole.

Lower Pulley

MWM-8026 WEIGHT RESISTANCE CHART (LBS)

TOTAL Weight

Front Press

Butterfly

Lat Pull

Low Pulley

10 30 15 20 30

20 44 20 30 40

30 58 25 40 50

40 72 30 50 60

50 86 35 60 70

60 100 40 70 80

70 114 45 80 90

80 128 50 90 100

90 142 55 100 110

100 156 60 110 120

110 170 65 120 130

120 184 70 130 140

130 198 75 140 150

140 212 80 150 160

Load even weights on each side of Sliding Weight Post

Numbers are approximate. Actual weights may vary.

Values for Butterfly are for each arm.

©IMPEX INC. www.impex-fitness.com8

WARNING

Please ensure to step with both feet on the included foot- plate while performing lower pulley

exercises to avoid any unwanted movement of the exercise machine.

CARE AND MAINTENANCE

1. Lubricate moving parts with WD-40 or light oil periodically.

2. Inspect and tighten all parts before using the equipment.

3. The equipment can be cleaned using a damp cloth and mild non-abrasive detergent.

DO NOT use solvents.

4. Examine the equipment regularly for signs of damage or wear.

5. Replace any defective components immediately and/or keep the equipment out of use until

repair.

6. Failure to examine regularly may affect the safety level of the equipment.

©IMPEX INC. www.impex-fitness.com9

MWM-8026 PARTS LIST

PART NO

DESCRIPTION

SIZE

QUANTITY

Rear Stabilizer

Base Frame

Vertical Frame

Upper Frame

Front Press Base

Seat Support Bar

Sliding Weight Post

Left Butterfly

Right Butterfly

Seat Support Frame

Leg Developer

Weight Sliding Frame

Front Press Handle

Seat Pad

Backrest Board

Lat Bar

Foam Tube

Bracket

3 ⅞” x 1 ½”

Upper Cable (Red)

135 ¾”

Lower Cable (Green)

130”

Butterfly Cable

110 ¼”

Foam Roll

Cross Floating Pulley Bracket

Butterfly Swivel Pulley Bracket

Swivel Pulley Bracket Base

Bracket

4 ⅜” x 1 ½”

Floating Pulley Bracket

Bracket

5 ⅛” x 1 ¾”

Leg Developer Axle

Ø ⅝” x M10 x 2 ⅜”

Ankle Strap

Chain

10-Link

Lat Bar Han Grip

Front Press Handle Grip

Hook

Foam Roll End Cap

Olympic Sleeve

Ø 2” x 8 ¼”

Pulley

Pulley Assembly

Cable Retainer

Retainer Bushing

Ø ¾” x Ø ⅜”

Table des matières

Autres manuels Impex Salle de sport à domicile

Impex

Impex IGS-411 Manuel utilisateur

Impex

Impex MARCY SM-6001 Manuel utilisateur

Impex

Impex CB-339 Manuel utilisateur

Impex

Impex MARCY MWB-479 Manuel utilisateur

Impex

Impex MARCY TSA 5000 Manuel utilisateur

Impex

Impex WM 1402 Manuel utilisateur

Impex

Impex MARCY DIAMOND ELITE MD-2080 Manuel utilisateur

Impex

Impex MARCY MCB-346 Manuel utilisateur

Impex

Impex MARCY CLUB MKM-81010 Manuel utilisateur

Impex

Impex Marcy Diamond MD-8861 Manuel utilisateur

Impex

Impex MARCY MXM-5 Manuel utilisateur

Impex

Impex Iron Grip Sport IGS-10 Manuel utilisateur

Impex

Impex Marcy Diamond MD-2109 Manuel utilisateur

Impex

Impex IRONGRIP IGS-04 Manuel utilisateur

Impex

Impex MARCY MWB 716 Manuel utilisateur

Impex

Impex MD-860 Manuel utilisateur

Impex

Impex Marcy Platinum MP-4500 Manuel utilisateur

Impex

Impex MARCY SM-4231 Manuel utilisateur

Impex

Impex Marcy MWM-4965SC Manuel utilisateur

Impex

Impex Apex TC-3500 Manuel utilisateur

Impex

Impex IGS-8860 Manuel utilisateur

Impex

Impex GD-810 Manuel utilisateur

Impex

Impex CB-204 Manuel utilisateur

Impex

Impex Iron Grip Sport IGS-07 Manuel utilisateur

Manuels Salle de sport à domicile populaires d'autres marques

Horizon Fitness

Horizon Fitness OXFORD 6 Manuel utilisateur

Energetics

Energetics Multi Trainer 5.1 Manuel utilisateur

Matrix

Matrix MG-PL Series Manuel utilisateur

Reebok

Reebok Tbr2i Manuel d'utilisation et d'entretien

Weider

Weider 8300 Hard Drive Manuel utilisateur

Pure Fitness

Pure Fitness 8526HE Manuel utilisateur

Weider

Weider 8700 I Guide de démarrage rapide

Bowflex

Bowflex Sport 001-6961 Manuel utilisateur

NordicTrack

NordicTrack E8200 Competition Bench Guide de démarrage rapide

Weider

Weider WEMC10161 Manuel utilisateur

Body Solid

Body Solid GHYP-345 Manuel utilisateur

Evo

Evo TAHOE 5105 Manuel utilisateur

cardiobull

cardiobull RA17 Manuel utilisateur

ParaBody

ParaBody 40 Manuel utilisateur

JLL

JLL Ventus Pro Air Power Manuel utilisateur

Trojan

Trojan Colorado 370 Manuel utilisateur

Octane Fitness

Octane Fitness xRide xR650 Manuel utilisateur

Precor

Precor Discovery Series Manuel utilisateur
