Thank you for your purchase of Ikelite equipment. Please read this

instruction manual completely before attempting to operate or dive

with this product.

4302 iTT Adapter

Instruction Manual

O-ring

Knurled Ring

Waterproof Cap

Nikonos Connector

Ikelite Bulkhead

White Dot

The Ikelite iTT Adapter is for use with Non-Ikelite housings with a TT

hotshoe & Nikonos-style bulkhead. The hotshoe must have all 5 wires

connected. Refer to housing specifications or contact housing

manufacturer for connector sty e and wiring information.

The Adapter offers both TT and Manual operation. Exposure

compensation is not provided through the Adapter, but can be accessed

via the camera’s menus.

The Ikelite iTT Adapter is compatible with the following Digital

Cameras; Nikon D40, D50, D70, D70s, D80, D200, D300, D300s, D700,

D3000, D5000, D60, D90, and Fuji S5 Pro.

The Ikelite iTT Adapter is NOT compatible with the following Nikon

Cameras; D-100, D-1X, D-2X, D-2H.

- Make sure all components are dry.

- Clean and lightly lubricate the threads and o-ring on the male Nikonos

connector. Use ON Y Ikelite lube. Other brand lubricants can cause the

o-ring to swell and not seat properly. Check o-ring for cracks or nicks.

- Properly align the Adapter’s male Nikonos connector and insert it into the

housing’s Nikonos-style bulkhead.

- Hand tighten the knurled ring on the Nikonos connector until there is no

in-out movement between connector and housing bulkhead.

Connecting Adapter to Housing Bulkhead

General Information

Nikonos Connector

Knurled Ring

Ikeli te Sync Cord

Knurled Ring

Adapter Knurled Ring

To Housing

Bu khead

Connecting Adapter to Housing Bulkhead (continued)

Diagram 1

Connecting DS Substrobes

Use ON Y with Ikelite DS Substrobes. If using an older DS50 or DS125

strobe, see strobe compatibility below.

- Make sure all components are dry.

- Remove the waterproof cap from the Ikelite bulkhead on the black

delrin pod. ightly lubricate bulkhead threads.

- Clean and lightly lubricate the o-ring on the male Ikelite connector.

Check o-ring for cracks or nicks.

- Note the positioning of the receptacles and pins. Properly align the

end of the Ikelite sync cord connector and insert it into the adapter’s

bulkhead (page 3).

-Hold the adapter’s knurled ring when tightening the sync cord.

- Hand tighten the knurled ring on the sync cord until there is no

in-out movement between sync cord connector and adapter

bulkhead.

Sing e or Dua Ike ite sync cords can be attached.

Dua strobe use requires dua sync cord.

Two strobes cannot be operated by independent adapters.

DS50 Substrobes

Substrobes with Serial Number below 63,850 can Not be updated to

operate correctly with the latest TT conversion circuitry.

Substrobes with Serial Number between 63,850 and 69,999 require an

update to operate with the latest TT conversion circuitry.

DS125 Substrobes

Substrobes with Serial Number below 2,500 can Not be updated to

operate correctly with the latest TT conversion circuitry.

Substrobes with Serial Number between 2,500 and 4,999 require an

update to operate with the latest TT conversion circuitry.

Strobe Compatibility

Switching between TTL and Manual

- The knurled ring on the iTT Adapter’s black delrin pod has a

white dot (see illustration on front page).

- The knurled ring can be rotated clockwise or counter-clockwise to

align the knurled ring’s white dot with the white dot on the label

next to TT or Manual.

-The DS Substrobe must be set to TTL mode for the iTTL adapter

to provide TTL operation.

Housing Bulkhead Compatibility

Over the years various housing manufacturers have introduced a variety

of "Nikonos-style" bulkheads with variations on the original contact

design. The plug end on this iTT Adapter has been designed to

prevent damage by some European housings with rigid contacts in place

of the traditional spring-loaded style.

This design may exhibit intermittency with some more traditional

Nikonos-style bulkheads. Two gold plated pins have been provided to

eliminate this intermittency. These pins should only be used in

conjunction with bulkheads featuring two spring-loaded contacts.

To see if your housing has spring-loaded contacts, use an open-ended

paper clip to gently push down on the contacts shown in diagram 2,

page 6. Very little pressure is needed to check the contacts. If the

contacts ARE spring-loaded, proceed to “Troubleshooting/Inserting Pins”

on page 7 for inserting the included gold plated pins.

These pins are specifically recommended for use with the Nikonos-style

bulkhead featured on Nauticam housings.

If your housing does NOT feature spring-loaded contacts, DO NOT

insert the included pins into your plug end. Doing so may cause

damage to your plug and/or bulkhead.

Troubleshooting/Inserting Pins

- If intermittent or loss of TT operation occurs, insert the 2 gold plated

pins into the Nikonos Connector End corresponding receptacles as

shown below. With the Index Recess at the bottom,

the pins should be at the 10 and 2 o’clock positions. Once the pins

are installed they cannot be removed.

- Connect the Adapter to the housing bulkhead, page 3.

Gold Plated Pins properly inserted in Receptacles

Nikonos Connector End

Index Recess

Gold Plated Pins

Nikonos Housing Bulkhead

Diagram 2

Spring-loaded Contacts

This Ikelite product is warranted against any manufacturing defects for a

period of one (1) year from the original date of purchase. Defective

products should be returned to Ikelite postage paid. Ikelite will, at its sole

discretion, repair or replace such products, and will return to customer

postage paid. All other claims of any nature are not covered. Except as

mentioned above, no other warranty expressed or implied applies to this

Ikelite product.

Limited Warranty

Ikelite is most interested in performing any service to ensure that all

products perform as intended. Evidence of purchase date must be

provided to obtain warranty service.

No prior authorization is required. You may return directly to us or

through your dealer. Please include a brief description of the problem,

any relevant email correspondence, and/or instructions on what you

want us to do. Always include name, shipping address, email address,

and phone number inside of the package. Send postage paid to:

Ike ite Underwater Systems

Attention: Service Department

50 West 33 Street

Indianapo is, IN 46208 USA

No reimbursements for postage paid will be issued.

You may also want to insure the package.

Returning Products For Service

Returning Products for Service (outside the nited States)

For the separate international customs documentation form that you

complete to accompany the shipment, please state or designate that the

enclosed products were originally manufactured in the USA and are

being returned to the manufacturer for repair service. Value of the

equipment listed for customs purposes should be zero.

Ikelite nderwater Systems

50 West 33rd Street

Indianapolis, IN 46208 SA

www.ikelite.com

4302_iTT _Adapter_03-1212

Ikelite Technical Support

Email: [email protected]

Phone 317-923-4523

Fax 317-924-7988

Technical Support
