Ikelite 6241.81 Manuel du propriétaire

Digital Housing

Supplemental Instructions

6241.81 Canon A810

Size and Weight

Width ......................5.8 in. (147mm) including controls

Height ....................4.6 in. (117mm) including controls

Depth ......................3.8 in. (97mm) including controls & lens port

Weight ....................1.1 lb. (499g)

Buoyancy ................Slightly positive in freshwater

Parts of the Housing

Front View

Back View

Shutter Button

On/Off Button

1. ovie Button

2. ?(Help) Button

3. (Auto) / Erase Up Button

4. ( acro) / Left Button

5. FUNC./ SET Button

6. (Flash) / Right Button

7. DISP. (Display) / Down Button

8. (Playback) Button

9. MENU Button

Lanyard

Latch

Zoom Lever

Tray ounts

ULTRA

compact

Made in USA

IKELITE

Lens Port

Initial Camera Settings

- Insert fully charged battery and formatted SD card.

- Set Date and Time.

- Set Shooting ode to “P” Program.

- Set ISO to 100 and White Balance to auto “AWB.”

- Set the Square to “Single Shot.”

- Set Resolution to “L” and “1280.”

- Set AF Frame to “Center” and Digital Zoom to “Off.”

- Set AF Point Zoom to “Off” and Servo AF to “Off.”

A strobe focusing light is recommended to assist AF underwater.

- Set Lamp Setting to “Off” and Red-Eye Correction to “Off.”

- Set Light etering to “Center Weighted.”

- Set Review to “5 Seconds” and Review Info to “Off.”

- Set Blink Detection and Grid Lines to “Off.”

- Set Flash to “On flash always fires.”

- In Power Saving, set Auto Power Down to “Off.”

- In Power Saving, set Display Off to “3 min.”

Note: Enable acro mode when shooting close-up subjects. If

overexposure occurs, back away from the subject and zoom in and/or

use “-” Exposure Compensation.

Ikelite W-20 Wide-Angle Conversion Lens 6420

The front of the lens port accepts the 6420 W-20 and other 67mm

threaded wide angle or macro lenses without the need for an adapter. An

external wide angle conversion lens increases angle of coverage so you

can get closer to the subject while still fitting everything in the frame.

Slight vignetting will occur at widest angle camera lens setting with these

lenses. Zoom in to eliminate, or crop the image in post processing.

Bayonet mount lenses cannot be used with this housing.

External Accessory Lenses

www.ikelite.com

6241.81_Canon A810_05-12

Ikelite Underwater Systems

50 West 33rd Street

Indianapolis, IN 46208 USA

Ikelite Technical Support

Email: [email protected]

Phone 317.923.4523

Fax 317.924.7988

AF35 Stro e Package 4035

The AutoFlash AF35 kit is a great compliment, and

an effortless, affordable way to add a flash to your

new Ikelite point and shoot camera system.

Everything you need to get started is in the box.

Just attach it to the bottom of your housing and

start taking pictures!

AF35 AutoFlash kit includes:

AF35 strobe - Flex arm - AutoFlash sensor

Handle with rubber grip - Tray (single or dual)

ounting hardware.

ikelite

AUTOFLASH

A full range of accessories is available to support your housing.

Please visit www.ikelite.com to see the most current information

about recommended accessories for your housing.
