Ikelite 6973.10 Manuel utilisateur

Product Registration

Please register your product within 15 days of purchase. Our product

registration database is the quickest way for us to contact you in the

event of a product update.

To register, send a photo of the above registration label to us via

[email protected] along with your name, address, and phone

number.

200DLM/A Underwater Housing for Canon EOS

M10

Product # 6973.10

Introduction

Thank you for your purchase of Ikelite products.

Our primary focus is to provide quality, professional grade products

for use in and under water. Our products are designed, manufactured,

and distributed from our sole facility in Indianapolis, USA where we

started in 1962.

We are available if you have any questions or want photo advice.

Send us an email 24 hours a day to [email protected]. We strive to

reply within 1 business day.

An electronic version of this instruction manual is available for

download via the product page on our website:

https://www.ikelite.com

In the Box

• Housing

• Rear o-ring # 0110 (installed)

• Front o-ring # 0132.36 (installed)

• .050” hex key # 0945.11

• 1/16” hex key # 0945.16

• Silicone lubricant 1cc tube

Important Notices

»This housing requires a compatible DLM lens port for

waterproof operation. The housing is not waterproof without a

DLM lens port attached.

»A bulkhead cap or sync cord must be attached to the housing

bulkhead for waterproof operation. Never submerge the

housing in water without either a sync cord or bulkhead cap

attached.

»Do not pull the shutter trigger without a camera installed. You

may accidentally detach or damage the control spring.

»Never leave a housing in a rinse tank, even if it is the only

system in the tank. Accidental damage may occur when the

user walks away from a housing while it is in the rinse tank.

»Do not use alcohol, cleaning agents, spray lubricants, Rain-X,

or other solvents on the housing or lens port. Use of an

incompatible chemical compound can damage the plastic and

o-rings, and may result in leaking.

»If you will be using the system in strong surf it is

recommended to draw a vacuum on the housing using the

optional vacuum kit (sold separately).

Contents

Product Registration 1

Introduction 2

In the Box 2

Important Notices 3

Getting to Know Your Housing 6

Tray Mounts 8

Setting Up Your Camera 8

Pre-Installation Checklist 8

Camera Settings 8

Exposure Settings 8

Setting Up Your Housing 9

Opening the Housing 9

Installing the Camera 9

Closing the Housing 10

Attaching a Lens Port 11

Installing the Lens and Port 11

Setting Up An External Strobe 14

About Fiber Optic Cords 14

Attaching a Fiber Optic Cord 15

Getting in the Water 15

Final Check 15

Entering the Water 16

Shooting Underwater 16

Learning about Underwater Photography 17

Maintaining Your Housing 17

Post-Dive 17

Lens Port 18

Storage 18

Servicing Recommendations 19

Lubricating Controls 19

Lubricating Push Buttons 20

Lubricating Control Shafts 21

Troubleshooting 22

Spare Parts 24

Limited Warranty 25

Service and Repairs 25

Getting to Know Your Housing

Shutter

Fiber optic

ports

Lid snap

Tray mounts

Lens

release

Port mount

Flash

switch

Movie

Front dial

Power

INFO

Viewnder

Rear o-ring

INFO

Left

Playback

Lid

snap

hook

Up / Erase

Down / Info

Right / Flash

INFO

Flash

Command

dial

Tray Mounts

This housing features two 1/4-20 threaded tray mounts on the bottom

of the housing. The spacing between the tray mounts is 3” (76.2 mm).

Optional tray with handles and mounting hardware are sold separately.

It is recommended to detach and thoroughly rinse the tray mounts,

tray, and mounting hardware, with fresh water routinely during

continuous use and prior to storage.

Setting Up Your Camera

Pre-Installation Checklist

1. Insert a fully charged camera battery.

2. Insert a properly formatted memory card.

3. Remove any attached lanyard or neck strap.

Camera Settings

• Set Flash ring to “On” when using an external strobe.

• Set AF assist beam to “Off” when using an external strobe.

• Set Red-eye reduc. to “Off” when using an external strobe.

Exposure Settings

Refer to the Cheat Sheets in the Photo School section of our website

for recommendations on exposure settings for a wide variety of

shooting situations:

https://www.ikelite.com/blogs/cheat-sheets

Setting Up Your Housing

Opening the Housing

1. Push the lid snap lock forward and lift the curved end away from

the housing.

Lock

2. Lid snaps are designed to provide enough force to compress the

o-ring for a proper seal. Keep rm pressure against the lid snap

while lifting it away.

3. Repeat with opposite lid snap.

4. Remove the housing back.

Installing the Camera

1. Remove any lanyard or neck strap which may be attached to the

camera.

2. Remove the camera mount plate from the housing.

3. Line the mount screw up with the camera’s tripod socket. Use a at

screwdriver to tighten the mount plate to the camera.

LENS

Mount screw

1/4-20 tripod

mount

Camera

tripod socket

4. Pull out on the housing control knobs to move the controls out of

the way.

5. Insert the mount plate into the slot on the inside bottom of the

housing. Push the camera all of the way forward until it stops.

6. Push housing control knobs in and check orientation with the

camera.

»The camera may be attached to a tripod using the 1/4-20

threaded mounting hole on the bottom of the mount plate.

Closing the Housing

1. Make sure the o-ring is clean and in its proper location on the back

of the housing. The rear housing o-ring does not require lubricant

to make a seal.

2. Place the back onto the housing front.

3. Make sure no controls or wires are interfering with the o-ring or the

back of the housing.
