Ikelite 75301 Manuel utilisateur

DL Macro Flat Port

Product # 75301

Included in the Box

• Flat port

• Securing thumbscrews (set of 3) # 9249.7 (installed)

• Vinyl cover # 0200 (installed)

• Silicone lubricant 1cc tube

Important Notices

»The port must be correctly aligned for waterproof

operation. Incorrect alignment will result in ooding.

»Do not snug or over-tighten the port thumbscrews.

»Never use alcohol, cleaning agents, spray lubricants,

Rain-X, or other solvents on the housing or lens port.

Use of an incompatible chemical compound can

damage the plastic or component o-rings, which may

result in leaking.

Installation and Use

Installing the Flat Port

Attach the lens to the camera.

Remove the vinyl cover from the dome port.

Check that the port sealing surface is clean and free of

debris.

Apply a very thin, even layer of lubricant to the exposed

portion of the housing’s front o-ring and to the lens port

sealing surface. Avoid dry spots or uneven build-up of

lubricant.

Loosen the three securing thumbscrews on the port until

they are clear from the inside of the port.

Align the port so that one thumbscrew is centered at the

top of the housing.

Press the port rmly towards the housing until the

base of the port is almost ush with the housing front. If

there is resistance, remove the port and check that the

thumbscrews are loosened and that the o-ring is properly

lubricated.

While holding the port rmly, gently tighten all three

thumbscrews. Do not snug or over-tighten.

»If the screws are difcult to turn the port is not installed

correctly.

Testing the Housing

Assemble the housing without a camera installed.

Submerge the housing in fresh water for several minutes.

Remove the housing from water and dry the outside of

the housing with a clean, lint-free cloth.

Look through the back of the housing for signs that water

has entered the housing. Signs include fogging or water

droplets.

»We recommend making at least one dive without a

camera installed to ensure waterproof operation.

Maintenance and Storage

Post-Dive

Rinse the housing with port installed in clean, fresh water.

Never leave your housing in the fresh water rinse tank.

Collisions with other gear can cause scratches or damage

to your equipment.

Dry the port with a clean microber lens cloth.

Attach the protective cover.

Stow the housing in a shaded place where it is protected

from impact or overheating. If no shade is available, we

recommend covering the housing with a towel or cloth.

Limited Warranty

This Ikelite product is warranted against any manufacturing

defects for a period of one (1) year from the original date

of purchase. To obtain warranty service, the product must

be returned to Ikelite postage paid. Ikelite will, at its sole

discretion, repair or replace such products, and will return

to customer postage paid. All other claims of any nature are

not covered. Except as mentioned above, no other warranty

expressed or implied applies to this Ikelite product.

Ikelite Underwater Systems

50 W 33rd St

Indianapolis, IN 46208 USA

(317) 923-4523

[email protected]
