Product Registration

Please register your product at ikelite.com within 15 days of purchase.

Our product registration database is the best way for us to get a hold

of you in the event of a product update or recall.

Underwater Housing for Sony Cyber-shot RX100

Mark III, Mark IV, Mark V

Product Number 6116.15

About this Product

Thank you for your purchase of Ikelite equipment. Please read this

instruction manual completely before attempting to operate or dive

with this product. Please visit ikelite.com to register your product to

receive information on any updates, notices, or recalls pertaining to

your equipment.

Included in the Box

• Housing # 6116.15

• Port cover # 0200

• Silicone lubricant 1cc tube

Specications

• 200 ft (60m) depth rating

• Controls for all camera functions except Flash switch and

Viewnder switch

• Slightly negative buoyancy in fresh water

• 1/4-20 thread tray mounting with 3 in (76mm) spacing

• Weight 2.6 lb (1180 g)

• Dimensions 6.8 x 5 x 5.4 in (173 x 127 x 137 mm)

• 3.0-inch diameter glass lens port

Important Notices

»Never leave a housing in a rinse tank, even if it is the only

system in the tank. The vast majority of catastrophic oods

happen when the user walks away from a housing while it is in

the rinse tank.

»To prevent salt build-up and sticking controls, submerge the

empty housing in clean, freshwater. Operate the controls

several times each while underwater to ush out any residue.

»Do not use alcohol, cleaning agents, spray lubricants, Rain-X,

or other solvents on the housing or lens port. Use of an

incompatible chemical compound can damage the plastic and

o-rings, and may result in leaking.

Contents

Product Registration 1

About this Product 2

Included in the Box 2

Important Notices 3

Getting to Know Your Housing 5

Getting to Know Your Housing - cont. 6

Setting Up Your Camera 7

Pre-Installation Checklist & Initial Camera Settings 7

Setting Up Your Housing 7

Opening the Housing 7

Inserting the Camera 8

Closing the Housing 9

Final Check 10

Entering the Water 10

Setting Up An External Strobe 11

About the Built-In Flash 11

Attaching a Fiber Optic Cord 11

Maintenance 12

Post-Dive 12

Travel and Storage 13

Troubleshooting 13

Limited Warranty 15

Service and Repairs 15

Tray Mounts

Lens Port

Fiber Optic Ports

Lid Snap

Shutter

Control Ring

On/Off Button

Zoom Lever

Mode Dial

Getting to Know Your Housing

Accessory Port

Hole Plug

MOVIE

O-Ring

Camera Mounting Plate

Lanyard

Lid Hook

Camera Mounting Tray

Getting to Know Your Housing - cont.

UP Cursor/Display

MENU/SET Button

Button

Control Wheel

Accessory Port

Your housing features one 1/2-20 threaded Accessory Port which

may be used for attachment of factory optional or aftermarket housing

accessories. Visit ikelite.com for an updated list of factory optional

accessories.

Use the following steps to replace an Accessory Port Hole Plug with

an accessory tting:

1. Remove the Hole Plug using an 11/16 inch open end wrench.

2. Check the accessory tting o-ring sealing area. If an o-ring is

not present, use the Hole Plug o-ring. Lightly lubricate o-ring with

Ikelite Lubricant. Use ONLY Ikelite lubricant. Other manufacturer

lubricants can cause the o-ring to swell. Check o-ring and o-ring

sealing area. Both should be clean and free of hair, sand, or other

debris.

3. Carefully screw in and tighten accessory tting. The accessory port

features a 1/2-20 threaded hole. Make sure your tting is the same

thread pattern. DO NOT cross-thread. DO NOT overtighten.

NOTICE: Your Ikelite housing warranty DOES NOT extend to

cover the attachment of aftermarket housing accessories by 3rd

parties. Warranty DOES cover factory optional accessories attached

by certied Ikelite service technicians.

Setting Up Your Camera

Pre-Installation Checklist & Initial Camera Settings

1. Insert a fully charged camera battery.

2. Insert a properly formatted memory card.

3. Set Mode Dial to “A” Aperture Priority. Manually adjust aperture

setting to achieve the best exposure for your shooting conditions.

The shutter speed will be locked at 1/30th second. If a faster shutter

speed is desired, set Mode Dial to “M” Manual mode to manually

adjust both aperture and shutter speed settings.

4. Set Drive Mode to “Single Shooting” and Flash Mode to “Fill

Flash.”

5. Set Red Eye Reduction to “Off.”

6. Set Focus Mode to “Single-shot AF” and Focus Area to “Center.”

7. Set AF Illuminator to “Off”, ISO to “200” and ND Filter to “Off.”

8. Set Metering Mode to “Center.”

9. Set Function for VF Close to “Not Power Off.”

All camera user settings not listed should be set to the user’s

preference. Adjust settings as necessary for each shooting

situation.

Setting Up Your Housing

Opening the Housing

1. Push the lid snap lock forward and start to lift the curved end away

from the housing.

2. Lid snaps are designed to provide enough force to compress the

o-ring for a proper seal. Keep rm pressure against the lid snap

while lifting it away.

Lid Snap Lock

3. Repeat with remaining lid snaps.

4. Remove the housing back.

Inserting the Camera

RX100 III IMPORTANT NOTE: If using the Sony RX100 III model

camera, add the small 1/16” thick rubber washer (included in box) to

the rear housing dial. Remove the adhesive backing on the washer

before application.

1. Remove any lanyard or neck strap which may be attached to the

camera.

2. Remove the camera mounting plate from the housing.

3. Line the mounting screw up with the camera’s tripod socket. Use

a coin or at head screwdriver to tighten the mounting plate to the

camera.

Camera Tripod

Socket

Mounting Screw

Mounting Plate

1/4-20 Tripod

Attachment Hole

4. Pull out on the housing control knobs to move them out of the way.

5. Insert the mounting plate into the slot on the inside bottom of the

housing. Push the camera all of the way forward until the back of

the mounting plate is ush with the back of the housing mount.

6. RAISE the ash, if using! Once the camera is closed in the

housing, the ash CANNOT be raised. DO NOT raise the ash

BEFORE placing the camera in the housing.

Closing the Housing

1. Make sure the o-ring is clean and in its proper location on the back

of the housing. The main o-ring does not require lubricant to make

a seal.

2. Place the back onto the housing front.

3. Make sure no controls or wires are interfering with the o-ring or the

back of the housing.
