Ikelite Wide Angle Port M67 Guide de démarrage rapide

Wide Angle Port M67 for Sony Cyber-shot

RX100 VI Housing

Item number 9306.02

Included in the Box

• Wide angle port

• O-ring # 0132.30 (installed)

• Vinyl cover # 0200 (installed)

• Silicone lubricant # 0184.1

Tools Recommended

• Rubber strap wrench # 0945.01 (not included)

Housing Compatibility

• Ikelite Underwater Housings for Sony Cyber-shot RX100

VI # 6116.18

Important Notices

»Do not use alcohol, cleaning agents, spray lubricants,

Rain-X, or other solvents on the housing or lens port.

Use of an incompatible chemical compound can

damage the plastic or component o-rings, which may

result in leaking.

»This port is not recommended for use with any models

of RX100-series housings except as listed above.

Installation and Use

Removing the Standard Port

Rotate the lens port counter-clockwise to remove. We

recommend using a rubber strap wrench (not included).

Store the port with o-ring in a dry, dust-free environment.

Installing the Wide Angle Port

Check that the o-ring is in its groove on the back of the

wide angle port.

Apply a very light, even coat of Ikelite silicone lubricant to

the exposed surface of the o-ring.

Align the threads of the wide angle port with the threads

of the opening in the front of the housing.

Facing the front of the housing, rotate the wide angle port

clockwise and tighten until snug.

Testing the Housing

Assemble the housing without a camera installed.

Submerge the housing in fresh water for several minutes.

Remove the housing from water and dry the outside of the

housing with a clean, lint-free cloth.

Look through the back of the housing for signs that water

has entered the housing. Signs include fogging or water

droplets.

We recommend making at least one dive without a

camera installed to ensure waterproof operation.

Maintenance and Storage

Post-Dive

Rinse the housing with wide angle port installed in clean,

fresh water.

NEVER leave your housing in the fresh water rinse tank.

Collisions with other gear can cause scratches or damage

to your equipment.

Dry the port and glass with a clean micro ber lens

cleaning cloth.

Attach the protective vinyl cover.

Stow the housing in a shaded place where it is protected

from impact or overheating. If no shade is available, we

recommend covering the housing with a towel or cloth.

Travel and Storage

Clean and dry the exterior of the wide angle port. DO NOT

use any type of alcohol or glass or surface cleaner on the

dome port.

Attach the protective vinyl cover.

Store in a cool, dry place.

Limited Warranty

This Ikelite product is warranted against any manufacturing

defects for a period of one (1) year from the original date

of purchase. To obtain warranty service, the product must

be returned to Ikelite postage paid. Ikelite will, at its sole

discretion, repair or replace such products, and will return

to customer postage paid. All other claims of any nature are

not covered. Except as mentioned above, no other warranty

expressed or implied applies to this Ikelite product.

Ikelite Underwater Systems

50 W 33rd St

Indianapolis, IN 46208 USA

(317) 923-4523

[email protected]
