Ikelite 4402 Manuel utilisateur

Thank you for your purchase of Ikelite equipment. Please read these instructions completely

before attempting to operate or dive with this product.

This ount provides an easy way to add fiber optic ports to almost any existing housing. Simply

cut to size and adhere to the top of the housing above the camera's built-in flash. Provides two

ports for the attachment of one or two fiber optic cords. For best results, use in conjunction with

your housing's flash deflector to avoid backscatter.

4402 Universal Fiber Optic Mount

Attaching Universal Fiber Optic Mount to a Housing

1. Insert one end of a compatible fiber optic cord into one of the two circular port openings in the

ount on the velcro side. Insert the other end of the compatible fiber optic cord into the

functioning strobe that you intend to trigger.

2. Hold the ount over the housing where you intend to attach it. Choose an area that will allow

good adhesion and allow the Fiber Optic Cord to easily see the camera flash.

3. With the camera inside the housing, fire the camera flash several times to make sure the

strobe is properly triggered. A properly charged strobe will fire along with each camera flash.

4. Remove the fiber optic cord from the ount. Using scissors, trim any excess Velcro material

from the ount which could interfere with housing controls or functions. Note: Only trim what

is necessary to assure good adhesion to the housing - Diagram A.

Velcro with adhesive backing Universal Fiber Optic ount

Contents

Diagram A Diagram B

Cut away excess Velcro that

may interfere with camera controls

or functions BEFORE attaching

to camera housing

Fiber Optic Cord

Adhesive

Backing

Velcro

Port ount

Ikelite Un erwater Systems

50 West 33r Street

In ianapolis, IN 46208 USA

www.ikelite.com

Universal ount Optical Port Kit_01-0813

Ikelite Underwater Systems

Service Department

50 West 33rd St.

Indianapolis, IN 46208 USA

Email: [email protected]

Phone: 317-923-4523

This Ikelite product is warranted against any manufacturing defects for a period of one (1)

year from the original date of purchase. Defective products should be returned to Ikelite

postage paid. Ikelite will, at its sole discretion, repair or replace such products, and will return

to customer postage paid. All other claims of any nature are not covered. Except as

mentioned above, no other warranty expressed or implied applies to this Ikelite product.

Customer Support

Limite Warranty

Evidence of purchase date must be provided to obtain warranty service.

No prior authorization is required. You may return directly to us or through your dealer.

Please include a brief description of the problem, any relevant email correspondence, and/or

instructions. Always include name, shipping address, email address, and phone number

inside of the package. Send postage paid to:

Ikelite Under ater Systems

Attention: Service Department

50 West 33 Street

Indianapolis, IN 46208 USA

No reimbursements for postage paid will be issued.

Note: Ikelite does not repair this item. A 4402 ount sent in for service that is found to be

defective will be replaced.

Returning Pro ucts for Service

- Ikelite 4501 Fiber Optic Coiled Cord

- INON Optical D Cable "Non-wireless type" L-Connector

- Sea&Sea Fiber Optic Cable (L-type) Product No. 50107

- Olympus UW Fiber Optic Cable PTCB-E02

- Nauticam Optical Fiber Cable No. 26211 Nauticam to INON

- Nauticam Optical Fiber Cable No. 26212 Nauticam to Sea&Sea

Compatible Fiber Optic Cor s

5. Remove the adhesive backing from the Velcro and attach the ount to the housing area

determined in step 2 - Diagram B.

6. Re-attach fiber optic cord and test fire strobe.

Attaching Ports Mount to a Housing (continue )
