IEI Technology NOVA-7800 Manuel utilisateur

October 22, 2003

NOVA-7800

Mobile CPU embedded board

With 10/100Mbps Ethernet,

VGA, Audio Version 1.1

User Manual

Version 1.2

The information in this document is subject to change without

prior notice in order to improve reliability, design and function

and does not represent a commitment on the part of the

manufacturer. In no event will the manufacturer be liable for

direct, indirect, special, incidental, or consequential damages

arising out of the use or inability to use the product or

documentation, even if advised of the possibility of such

damages.

This document contains proprietary information protected by

be reproduced by any mechanical, electronic, or other means in

any form without prior written permission of the manufacturer.

Trademarks

NOVA-7800 is registered trademarks of ICP Electronics Inc.,

IBM PC is a registered trademark of International Business

Machines Corporation. Intel is a registered trademark of Intel

Corporation. Award is registered trademarks of Award Software

International, Inc. Other product names mentioned herein are

used for identification purposes only and may be trademarks

and/or registered trademarks of their respective companies.

Support

Any questions regarding the content of this manual or related

issues can be e-mailed to us directly at: [email protected]

Table of Contents

CHAPTER 1. INTRODUCTION ........................................5

1.1 SPECIFICATIONS .......................................................... 6

1.2 PACKAGE CONTENTS...................................................... 8

CHAPTER 2. INSTALLATION..........................................9

2.1 NOVA-7800’S LAYOUT ................................................. 9

2.2 CLEAR CMOS SETUP................................................... 12

2.3 COMPACT FLASH SETTING ............................................. 12

2.4 AUDIO AMPLIFIER SELECT ............................................. 12

CHAPTER 3. CONNECTION ..........................................13

3.1 FLOPPY DISK DRIVE CONNECTOR ..................................... 14

3.2 VIDEO IN CONNECTOR................................................. 14

3.3 ULTRA ATA33/66/100 IDE DISK DRIVE CONNECTOR ........... 15

3.4 PARALLEL PORT ......................................................... 15

3.5 USB PORT CONNECTOR................................................ 16

3.6 SERIAL PORTS........................................................... 16

3.7 POWER CONNECTOR .................................................... 17

3.8 KEYBOARD CONNECTOR ................................................ 18

3.9 IRDA INFRARED INTERFACE PORT .................................... 18

3.10 FAN CONNECTOR ...................................................... 19

3.11 AUDIO CONNECTORS ................................................. 19

3.12 VGA CONNECTOR..................................................... 20

3.13 LAN RJ45 CONNECTOR.............................................. 20

3.14 COMPACT FLASH CONNECTOR--TYPEII ............................ 21

3.15 EXTERNAL SWITCHES AND INDICATORS ............................ 22

3.16 IEEE-1394 CONNECTOR ............................................ 22

3.17 CARDBUS/PCMCIA CONNECTOR ................................... 23

3.18 DIGITAL I/O ........................................................... 24

CHAPTER 4. AMI BIOS SETUP .....................................26

4.1 INTRODUCTION .......................................................... 26

4.2 STARTING SETUP........................................................ 26

4.3 SETUP SUMMARY ........................................................ 26

4.4 STANDARD CMOS SETUP SELECTIONS ............................. 28

4.5 ADVANCED CMOS SETUP SELECTIONS ............................. 30

4.6 ADVANCED CHIPSET SETUP SELECTIONS............................. 36

4.7 POWER MANAGEMENT SETUP SELECTIONS........................... 38

4.8 PCI / PLUG AND PLAY SETUP SELECTIONS .......................... 41

4.9 PERIPHERAL SETUP SELECTIONS ...................................... 43

4.10 HARDWARE MONITOR SETUP SELECTIONS ......................... 46

APPENDIX A. WATCHDOG TIMER ..................................47

APPENDIX B. DIGITAL I/O ............................................49

APPENDIX C. ADDRESS MAPPING .................................50

IO ADDRESS MAP ............................................................ 50

1ST MB MEMORY ADDRESS MAP........................................... 51

IRQ MAPPING TABLE ........................................................ 51

DMA CHANNEL ASSIGNMENTS ............................................. 51

APPENDIX D. HOW TO USE WAKE-UP FUNCTION .........52

APPENDIX E. HOW TO USE VIDEO-IN FUNCTION ........53

Chapter 1. Introduction

Thank you for choosing the NOVA-7800 Mobile Intel®Celeron®

and Pentium III®(Micro-FCBGA) with Multimedia & LAN

Ethernet Embedded Little Board. This board comes equipped

with low power mobile Pentium®III, or Celeron Processor with

the Intel advanced chipset 815E especially designed to fit the

needs of the system manufacturers, integrators, or VARs that

want to build a low power consumption system.

In addition, the NOVA-7800 provides on-chip VGA which

provides up to 1600x1200 in resolution.

An advanced high performance super I/O chip – W83627 is

used in the NOVA-7800 board, providing two UARTs that are

compatible with the NS16C550. The parallel port and FDD

interface are compatible with IBM PC/AT architectures.

The NOVA-7800 has one Fast Ethernet Multifunction PCI

Controller working as a LAN controller, which is fully a

integrated 10BASE-T/100BASE-TX LAN solution that provides

high performance networking functions as well as low power

consumption features.

This CPU board has a built-in Compact Flash Disk Socket,

CardBus, FireWire for embedded applications.

For multimedia applications, NOVA-7800 provides many

functions such as IEEE 1394 ,5.1 channel Audio and video in.

1.1 Specifications

•CPU : Intel Mobile CPU( Micro-FCBGA )

•DMA channels : 7

•Interrupt levels : 15

•Chipset : Intel 815E

•Memory : One 168 pin DIMM sockets. The memory

capability is up to 512MB/133MHz.

•Ultra ATA/33/66/100 IDE Interface : One PCI

Enhanced IDE channels (2 IDE devices). The south bridge

ICH2 supports Ultra ATA/33/66/100 IDE interface. To

support Ultra ATA66/100 Hard disk, a specific cable

(maximum length -- 45 cm) is available.

•Floppy disk drive interface : Single 2.88 MB, 1.44MB,

1.2MB, 720KB, or 360KB floppy disk drive.

•Serial ports : Two high-speed 16C550 compatible UARTs

with 16-byte FIFO buffer. Up to 115Kbps in speed.

•Parallel Port : One IEEE1284 compatible Bi-directional

ports. Supports SPP/ECP/EPP.

•IrDA :Supports Serial Infrared(SIR) and Amplitude Shift

Keyed IR(ASKIR) interface.

•USB : Supports two USB 1.1 compatible ports.

•Audio : Onboard CMI8738 chipset, supports 5.1 channel

sound that include LINEOUT, REAR, and CENTER/BASS.

•Watchdog timer :

 Software programmable – enable/disabled.

 Timer interval is 1 ~ 255 second.

 System Reset will be generated while time out.

•VGA Controller : Embedded VGA controller, screen

Resolution : up to 1600x1200 in 256 Colors at 85Hz Refresh.

•Intel 82801BA embedded LAN : IEEE 802.3u Auto-

Negotiation support for 10BASE-T/100BASE-TX. Fast back-

to-back transmission support with minimum interframe

spacing. Connected to your LAN through RJ45 connector.

•Keyboard Controller : 8042 compatible for keyboard and

PS/2 mouse

•4 Digital Inputs and 4 Digital Outputs.

•4 Channels of composite video input.

•FireWire : The TSB43AA22 provides the digital and analog

transceiver functions to implement a two-port mode in a

cable-based IEEE 1394. Provides two P1394a fully compliant

cable ports at 100/200/400 megabits per second (Mbits/s).

•CardBus : Compliant with CardBus/PCMCIA PC Card 95/97

standard specification.

•Power Consumption : 5V/3.5A and 12V/0.18A, as running

by PIII 800MHz and 256MB.

•Operating Temperature : 0°~ 60°C ( CPU needs cooler)

1.2 Package Contents

In addition to this User's Manual, the NOVA-7800 package

includes the following items:

•NOVA-7800 Mobile CPU bases Single board computer.

•One FDD cable.

•One HDD cable.

•Keyboard / Mouse adapter Y cable.

•One RS-232 serial port and one Printer port cable.

•One AUDIO ports cable.

•Two 4 Channels of composite video cable.

•One CPU cooler.

•One IEEE-1394 cable.

Chapter 2. Installation

This chapter describes how to install the NOVA-7800. At first,

the layout of NOVA-7800 is shown and then comes the

unpacking information that you should be careful is described.

Jumpers and switches setting for the NOVA-7800’s

configuration, such as CPU type selection, system clock setting,

and watch dog timer, are also included.

2.1 NOVA-7800’s Layout
