ICRealtime IC720 Manuel utilisateur

INSTRUCTION MANUAL

Features and Specifications

a. Overview 1

b. Features 2

c. IC720 App 2

d. Specifications 3-4

e. Dimensions 5

Camera Installation

a. Ceiling Installation 6-8

b. Corner/Pole Mount 9-11

Web GUI | IC720 Management

a. Network Connection 12

b. Logging In, and Main Interface 13-14

c. Connecting IC720 to an NVR 15-16

Appendices

a. Toxic or Hazardous Elements 17

TABLE OF CONTENTS

IC REALTIME

1 | FEATURES AND SPECIFICATIONS

This section outlines the primary features of the IC Realtime IC720

Camera. It also outlines basic Architectural and Engineering

specifications.

1a. OVERVIEW

This IC Realtime series product is an excellent situational awareness

IP Camera – the camera designed to see everything with no blind

spots. It adopts a dual lens design, and is powered by a robust

Qualcomm, Snapdragon 800 series processor, enabling it to maintain

reliable, 24/7 operation. Utilizing both H.264 video compression

and AAC audio compression technology enables the highest quality

of recorded audio/video, while maintaining the lowest bitrate

utilization.

The IC720 series camera is an HD, dual lens 12 MegaPixel IP Camera

with an integrated microphone. The dual lens design of the camera

allows for video capture in a full 360 degree vertical and 360 degree

horizontal format. This camera is fully suited for full operation as a

standalone device.

The 12MP recording resolution and extreme wide angle lens design

makes this IPC well equipped for installation in various institutions

ranging from residential, commercial, governmental, and enterprise

environments.

IC REALTIME

1b. FEATURES

IC Realtime IC720 series IP Cameras all support the following features:

HD, 360 x 360 Video Monitoring: This IP Camera uses two SONY

IMX172 (12MP) sensors.

Secure Archiving: Audio Video data is compressed and packaged

into a secure, and watermarked video format. This bolsters archived

video integrit y, and prevents vicious data manipulation. Video is

also watermarked with special data for evidentiary purposes.

Compression Format: H.264 video and AAC audio enables high

qualit y video recording while maintaining the lowest file sizes

possible.

SD Card Storage: As a standalone device, the IPC can hold a 32GB

micro SD card suitable for storing video direct from the camera.

1c. IC720 APP

Network Operation: Full system control (including live view,

playback, backup,VPT Z control, and system configuration) is available

with over the network. Client software is available for both Mac and

PC systems.

VPTZ Control: This IPC includes a special dewarping algorithm,

enabling users to ‘Virtually’ Pan/Tilt/Zoom across a high resolution

image, in order to get the highest visibilit y and situational awareness

from the camera.

Field of View 360 x 360 degree - No Blind Spots!

Optical Conguration 2 x Fish Eye Lens; Back-to-Back

Lens All Glass, FOV=188º, f/2.8

Image Sensor

2 x SONY IMX172

Type 1/2.3’’, 12 Megapixel, CMOS

Effective Pixels: 4000 x 3000

Resolution and FPS

2048 x 2048 @ 22 FPS per sensor (8MP)

2560 x 2560 @ 20 FPS per sensor (12.5MP)

2780 x 2780 @ 10 FPS per sensor (15.4MP)

Image Signal Processing Auto White Balance, Auto Gain, Noise Reduction

Platform Qualcomm Snapdragon 800

Video Compression H.264

Bit Rate Min: 4Mbit/s ~ 12Mbit/s ~ (Low ~ High Quality:

Recommended 8 Mbit/s)

IR CUT Electromagnetic IR-CUT

switch

IR Illumination External IR Illuminator

Microphone Built in

Audio Compression G.711u

Bit Rate 16-64Kbps

Ethernet RJ-45 (10/100 Base-T)

Protocol HTTP, HTTPS, RTSP, TCP,

UDP

ONVIF Profile S

Max Users 3

1.d SPECIFICATIONS

CAMERA

DAY/NIGHTAUDIONETWORK

IC REALTIME

NVR IC Realtime NVR-8128; NVR-8256

Memory Slot Micro SD (up to 32GB

Power Supply 12VDC, PoE

Power Consumption ~8 Watts

Mount Wall, Ceiling, Corner, Pole

Size 4.2’’ x 11.7’’ x 2.9’’ (108mm x 293mm x 73mm)

Weight ~3 lbs

Protection For Indoor use only

Working environment 40-95 degrees F / 10-35 degrees C; 10%-80%

STORAGEPOWEROTHER

1.d SPECIFICATIONS (Continued)

The ‘front’ of the IC720 Camera. Ceiling mount orientation.

1.e DIMENSIONAL VIEWS

Bottom view of the IC720 Camera. The cable harness extends out of the center.

IC REALTIME

2 | CAMERA INSTALLATION
