IBM LTO Generation 3 Manuel utilisateur

IBM Storage Technology Division

reserved.

Presentation File

Name

The IBM Advantage

IBM LTO Generation 3

IBM Storage Technology Division

reserved.

Presentation File

Name

LTO Technology Overview

Product Overview

Drive Interfaces

Diagnostics and Error Reporting

Log Pages/Buffers

On-line Resources

IBM Storage Technology Division

reserved.

Presentation File

Name

LTO Technology

IBM Storage Technology Division

reserved.

Presentation File

Name

Generation 2 (IBM LTO Drive) 3 (IBM LTO Drive)

Capacity 200 GB 400 GB

Transfer 35 MB/S 80 MB/S

Channels 816

Attachment SCSI 3, FC(2Mb) SCSI 3, FC (2Mb)

Form Factor Full High Full High

Media Type MP MP

Thickness 8.8uM 8.0 uM

Tape Length 609 M 680 M

Write/Read 6.22 M/S 5.46 M/S

Seek Speed 8 M/S 8 M/S

Tracks 512 704

Linear

Density 188kb/in 245kb/in

IBM LTO

Specifications Product Overview

IBM Storage Technology Division

reserved.

Presentation File

Name

HAA

Roller Bearings/Guides

Cartridge

Tape Path

Product Overview

IBM Storage Technology Division

reserved.

Presentation File

Name

LP0 ............Leader pin attach point - 0 M

LP1 ............Fwd servo detect begins - 1M

LP2 ............Start calibration region - 5 M

LP3 .(BOT).User data region starts - 6 M

LP4 .(EOT).User data region ends - 596 M

LP5 ............Max user data region ends - 596.1M

LP6 ............Rev servo detection begins - 601.1M

LP7 ............Physical end of tape - 609 M

LP0 to LP1 .......Unused

LP1 to LP2 .......Forward servo acquisition

LP2 to LP3 .......Calibration region

LP3 to LP4 .......User data region

LP4 to LP5 .......Unused data area

LP5 to LP6 .......Reverse servo acquisition

LP6 to LP7 .......Unused

Logical Point Definitions Logical Area Usage

LP0LP1

LP2LP3

LP4

LP5

LP6LP7

FID

EW ...Early Warning

FID ...Format Identification Data Set

Regions on Tape

IBM Storage Technology Division

reserved.

Presentation File

Name

SERVO (Lateral Position)

11 nominal positions

ABC

Technology

Overview

IBM Storage Technology Division

reserved.

Presentation File

Name

SERVO (Longitudinal Position....LPOS)

Technology

Overview

IBM Storage Technology Division

reserved.

Presentation File

Name

Dual Actuator Head

Product Overview

IBM Storage Technology Division

reserved.

Presentation File

Name

^^ ^^

SERVO

^^ ^^

DATA

Technology

Overview
