USE AND CARE GUIDE

Questions, problems, missing parts?

Before returning to the store, call

Husky Customer Service

8 a.m – 7 p.m., EST, Monday-Friday

9 a.m – 6 p.m., EST, Saturday

Item #

Model # H61MWC10RPB

THANK YOU

We appreciate the trust and con dence you have placed in Husky through the purchase of this cabinet. We strive to continually

create quality products designed to enhance your home. Visit us online to see our full line of products available for your home

improvement needs. Thank you for choosing Husky!

1-888-HD-HUSKY

HUSKYTOOLS.COM

61 INCH 10-DRAWER MOBILE WORK CENTER

WITH FLIP-UP PEGBOARD AND SHELF

Table of Contents

Table of Contents..................................................2

Safety Information ...............................................2

Warranty ................................................................4

Specifications ........................................................4

Package Contents..................................................4

Hardware Included........................................................... 4

Assembly ...............................................................6

9............................... ................................ecnanetniaM

8..............................................................

Operation

Safety Information

1. Do not pull this unit, push it when moving.

2. Use the brakes when this product is not being

moved. This prevents the product from rolling.

3. Secure this product properly before moving it.

4. Do not tow the product with power equipment.

5. Do not alter this product in any manner. For

example, do not weld external lock bars or attach

electrical equipment.

Do not attach or mount this product

to a vehicle or mobile trailers. This may cause

personal injury or product damage. Mounting this

product to any vehicle or mobile trailers in any

warranty.

Do not stand on this product. You

may fall which may cause personal injury or

Be careful when opening more than

one drawer. The product may become unstable

and tip, which may cause personal injury or

product damage.

CAUTION: Keep the product on level surfaces.

The product may become unstable and tip if

stored or moved on an unlevel surface, which

may cause personal injury or product damage.

CAUTION:

Lock the drawers before moving

this product. The drawers could come open and

make the product unstable and tip, which may

cause

Replacement Parts ................................................10

product damage.

6. Before locking the cabinet, ensure the drawers are

completely closed in order for the lock bars to work properly.

Cordless Power Tool Battery Chargers ...............9

personal injury or product damage.

manner will void

7. Extension cord

Follow all manufacturers' Warnings and Operating

Instructions for your extension cord.

Only use a three-wire extension cord with all three prongs

intact. Never remove the round grounding prong.

Check the insulation and plugs of extension cord before

using. Do NOT use cord if it is worn or damaged.

□

Do not insert extension cord through hole without grommet

in place.

□

Extension cord must be connected to a 125 Volt GFCI

protected outlet with proper ground. If GFCI outlet is not

available, use an extension cord with GFCI protection

built in.

□

Do NOT overload extension cord.

Remove extension cord from the hole

before moving or transporting storage cabinet.

Only use an extension cord that is rated for outdoor use.

□Do NOT connect extension cord to outlet that also sup-

plies critical safety equipment with power.

8. Electrical Shock Hazard

□ Do not plug cord into outlet with wet hands.

□ Do not use this cabinet near a bathtub, a shower, or a

swimming pool.

□ Cabinet plugs must match the outlet.

□ Never modify the plug in any way.

□ Do not use any adapter plugs with earth (grounded) cabinet

power strips.

□

of electric shock.

□ Avoid body contact with earthed or grounded surfaces. There

is an increased risk of electric shock if your body is earthed or

grounded.

CAUTION: RISK OF ELECTRICAL SHOCK: This unit has

one power supply cord. Make sure the cord is

unplugged before any servicing or cleaning.

3 Please contact 1-888-HD-HUSKY

HUSKYTOOLS.COM

for further assistance.

NOTE : This equipment has been tested and found to

comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against

harmful interference in a residential installation. This

equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications.However, there

is no guarantee that interference will not occur in

a particular installation.

If this equipment does cause harmful interference to

radio or television reception, which can be determined

by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or

more of the following measures:

□Reorient or relocate the receiving antenna.

□Increase the separation between the equipment and

receiver.

□Connect the equipment into an outlet on a circuit

different from that to which the receiver is connected.

□Consult the dealer or an experienced radio/TV

technician for help.

NOTE : This device complies with Part 15 of the FCC

Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful

interference, and

(2) this device must accept any interference received,

including interference that may cause undesired

operation.

WARNING: Changes or modiﬁcations to this unit not

expressly approved by the party responsible for

compliance could void the user’s authority to operate

the equipment.

Specifications

Maximum weight per cabinet drawer 100 lbs.

130 lbs.

200 lbs.

50 lbs.

Package Contents

HARDWARE INCLUDED

NOTE: Hardware not shown to actual size.

Part Description

M6 x 16 bolt

Hex key

Quantity

AA BB

Warranty

The manufacturer warrants the product to be free from defects in materials and workmanship for a period of ﬁve (5) years from date of

purchase. This warranty applies only to the original consumer and only to products used in normal use and service. If this product is found to

be defective, the manufacturer’s only obligation, and your exclusive remedy, is the repair or replacement of the product at the manufacturer’s

mishandling.

This warranty shall not apply to any product that is found to have been improperly installed, set up, or used in any way not in accordance with

the instructions supplied with the product. This warranty shall not apply to a failure of the product as a result of an accident, misuse, abuse,

negligence, alteration, faulty installation, or any other failure not relating to faulty material or workmanship. This warranty shall not apply to

ar purpose,

consequential

or incidental loss or damage, including but not limited to any labor/expense costs involved in the replacement or repair of said product.

Contact the Customer Service Team at 1-888-HD-HUSKY or visit www.huskytools.com.

NOTE: Begin product assembly close to t nal

intended location of your cabinet. This product is

heavy and may be di cult to move after assembly.

Maximum pegboard capacity

Maximum capacity of shelf on pegboard

Maximum capacity of adjustable shelf in door area

2500 lbs.Total weight capacity

Part Description Quantity

Cabinet 1

Cabinet handle 1

L bracket

Pegboard shelf

Pegboard shelf bracket

Storage hook

1Bottle opener

Pegboard

Package Contents (continued)

NOTE:

The keys are inside top drawer.

5HUSKYTOOLS.COM

Please contact 1-888-HD-HUSKY for further assistance.

Attaching the pegboard

NOTE:

The holes in the cabinet are tapped and do not

require nuts.

□

CAUTION:

Two people are recommended for assembly.

Attaching the pegboard shelf

Remove bolts (AA) and connecting plates from pegboard (C).

Keep bolts (AA) to use in step 2. Connecting Plates are no

longer needed.

With the help of another person, carefully lift the pegboard (C)

up into the upright position as indicated.

Position the L-bracket (D) over the holes on the

pegboard (C) and the cabinet (A).

Attach the L-bracket (D) with 6 bolts (AA) and tighten with

the hex key (BB) provided.

Repeat this process for the other side of the pegboard (C) to

attach it to the cabinet.

Place the pegboard shelf (E) onto the brackets (F) and align

holes as shown in Step 1. Secure shelf (E) to bracket (F) with

1 bolt (AA) per bracket and tighten with the hex key (BB)

provided.

Position the pegboard shelf brackets (F) over the holes in the

top of the pegboard (C) as shown in Step 2. Secure with

1 bolt (AA) on each side and tighten with the hex key (BB)

provided.

Attach the pegboard shelf assembly to the pegboard (C)

using 1 bolt (AA) on each side as shown in Step 3.

NOTE:

The pegboard shelf can be installed in your

choice of locations on the pegboard: Left Side,

Right Side, or Center.

Assembly

Step 1

Step 2

Step 3

Attaching the cabinet handle

Position the cabinet handle (B) over the holes on the

cabinet (A).

Attach with the bolts (AA) and tighten with supplied

hex key (BB).

□

7Please contact 1-888-HD-HUSKY

HUSKYTOOLS.COM

for further assistance.

Attaching the storage hook

□Position the storage hook (G) over the holes on the

cabinet (A).

□Attach hook (G) using bolts (AA) and tighten with

supplied hex key (BB).

Attaching the bottle opener

CAUTION: Do not over tighten the bolts.

Attach with the bolts (AA) and tighten with supplied hex key (BB).

□Position the bottle opener (H) over the holes on the cabinet (A).

□

NOTE:

There are holes to mount handle on either side

of cabinet, but only one handle is provided.

Operation

Removing the drawers 2

Re-inserting the drawers

Fully extend the empty drawer.

□

elihwrevelesaelerenoonpuhsuP pulling down on

the other release lever.

□Gently pull the drawer outward until it is released

from the drawer slide.

Extend the drawer slides.

□

Insert the brackets on each side of the drawer into

the slots in the slides, being careful that they are

properly positioned.

□Once properly inserted, completely close the drawer

to set the slides in their proper positions.

□

3Usage of rubber grommet

When passing cords into the box, be sure to always

enter box from the rear. After head of cord is in place,

slightly pull back 2-3”to ensure weather resistant ”star

bursts”are facing toward the outside of box. Never

push the cord from inside box so that mating plug

points are exposed to the environment.

□BE SURE TO FOLLOW ALL ELECTRICAL SAFETY PRECAUTIONS.

9Please contact 1-888-HD-HUSKY

HUSKYTOOLS.COM

for further assistance.

Cordless Power Tool Battery Chargers

See Charger’s Owner’s Manual for proper use and care of charger and batteries.

Follow all Warnings and Instructions provided with your battery charger.

□

Place chargers and electrical connections inside cabinet.

□

Chargers are for use in dry locations only. Do NOT expose to liquid, vapor, or rain. Should your charger become wet,

Do NOT attempt to use. Unplug extension cord from supply before handling wet charger or cords.

□

Only use chargers and batteries that are intact and operating properly.

□

Do NOT touch metal prongs when plugging charger into extension cord.

□

Do NOT place or attempt to charge lead acid, car type batteries in storage cabinet.

□

□Periodically clean the drawer fronts, drawer trim, and other surfaces with a mild detergent and water.

□

Maintenance

1 Caster maintenance 2 Drawer maintenance

□Grease the casters annually using high-quality

bearing grease.

□Lu

bearing grease.

bricate the slides semi-annually with high-quality

Replacement Parts

For assistance with replacement parts please call 1-888-HD-HUSKY.

Drawer Liner 10

A Cabinet Handle 1

DLock 2

Badge

HDrawer Slide

Caster Bolt 24

Key 2

Part Description Quantity

Swivel Caster

Swivel Locking Caster

Caster Washer

Handle Bolt

Outlet Panel Cover

Outlet 1

Rubber Grommet

Storage Hook

4Storage Hook Bolt

2L Bracket

Pegboard Bolt

Pegboard Shelf Bracket

Pegboard Shelf 1

Pegboard Shelf Bolt

Adjustable Shelf in

Door Area

1Storage Bin

22Drawer End Cap

1Bottle Opener

2Bottle Opener Bolt

Table des matières

Autres manuels Husky Rangement des outils

Husky

Husky HOTC5209B11M Manuel utilisateur

Husky

Husky G4801S-US Manuel utilisateur

Husky

Husky HOTC8422BB1M Manuel utilisateur

Husky

Husky HMT406B Manuel utilisateur

Husky

Husky H46MWC9GBXD-TL Manuel utilisateur

Husky

Husky HPRO72TLOCKERBL Manuel utilisateur

Husky

Husky HBR902490W5R Manuel utilisateur

Husky

Husky HOUC3603B1QWK Manuel utilisateur

Husky

Husky H347TR Manuel utilisateur

Husky

Husky H46MWC9GBXD Manuel utilisateur

Husky

Husky H61MWC11WBB Manuel utilisateur

Husky

Husky H46MWC9GBV2 Manuel utilisateur

Husky

Husky HOTC5623BL2S Manuel utilisateur

Husky

Husky HOTC6214JX1M Manuel utilisateur

Husky

Husky HOLC5209BB1M Manuel utilisateur

Husky

Husky HBR782478W4 Manuel utilisateur

Husky

Husky HMT5212 Manuel utilisateur

Husky

Husky HOME2801B12 Manuel utilisateur

Husky

Husky H72CH9HD Manuel utilisateur

Husky

Husky H46X18MWC9RED Manuel utilisateur

Husky

Husky H5CH2R Manuel utilisateur

Husky

Husky UACT-H-360121 Manuel utilisateur

Husky

Husky H52CH6WBB Manuel utilisateur

Husky

Husky 7440946b Manuel utilisateur

Manuels Rangement des outils populaires d'autres marques

Ryobi

Ryobi RWB03 Manuel utilisateur

Scheppach

Scheppach ts 2100 Manuel utilisateur

Cornwell Tools

Cornwell Tools CTB360AKBK Manuel utilisateur

DIVERSIFIED WOODCRAFTS

DIVERSIFIED WOODCRAFTS SHAIN GSB-6024 Manuel utilisateur

Cassese

Cassese CS200 CART Manuel utilisateur

Kendall Howard

Kendall Howard ESDW-9630-1000 Manuel utilisateur

Lista

Lista Align Instructions de montage

Workzone

Workzone 99609 Manuel utilisateur

Stanley

Stanley STST83800-1 Manuel utilisateur

Homak

Homak PROFESSIONAL Series Manuel du système

Perel

Perel ROLLER SHUTTER STORAGE CABINET Manuel utilisateur

BGS technic

BGS technic 4107 Manuel utilisateur

Clarke

Clarke CWB1250 Manuel utilisateur

Ryobi

Ryobi RWB02 Manuel utilisateur

Sealey

Sealey PTB66004 Manuel utilisateur

General International

General International Excalibur 40-100 Manuel de la liste des pièces

Newpo

Newpo Light Duty Workbench Manuel de la liste des pièces

Kobalt

Kobalt 0827415 Manuel utilisateur
