HunterDouglas 5-216 Manuel utilisateur

2

1

1

2

Open both fasteners of the bracket ring. Turn the

blind in the roll up direction until the front plate gets

out of the bracket ring.

Type 5-216

Push the blind against the bearing and slide it out

of the bracket.

... and slide it towards you.

Installation Instruction

Roller Blind

Motor Operation

Unfasten the locking ring.

Disconnect the motor. Lift the backside of the end

cap...

Removal

1

2

INSTRUCTIO

2

1

a

c

b

click

click

click

Slide the cover cap onto the bracket until it snaps.

The fasteners of the bracket ring must be open.

Fix the bracket with the screws provided

a recess b ceiling c wall

Place the blind with the bearing onto the bracket.

Push the blind against the bearing and lift the blind

up ...

Fix the blind by turning the locking ring against the

bearing.

Slide the end caps onto the brackets. Make sure that

the end caps snap onto the brackets.

Connect the motor and controls in accordance with

separately provided instructions.

... until the motor front plate ¿ts the bracket ring.

Turn the blind (10°) in the rolling off direction and

close both fasteners of the bracket ring. Make sure

that limit switches are accessible.

To adjust skewing, put the provided Allen key into

the screw of the leveller and turn it left or right to

move the blind up and down. Support lifting of large

heavy blinds with the palm of your hand.

Option: Leveller

Installation

Make sure that the opening for the Allen key is

pointing downwards before installing the brackets.

Change the orientation by loosening the 4 screws

(M5 x 8) and turning the leveller 90°. Fix the screws.
